Wrapper Function for ggstatsplot::ggbetweenstats and ggstatsplot::grouped_ggbetweenstats to generate dot-style comparisons of continuous variables between groups with statistical annotations and significance testing.
Usage
jjdotplotstats(
data,
dep,
group,
grvar,
typestatistics = "parametric",
effsizetype = "biased",
centralityplotting = FALSE,
centralitytype = "parametric",
mytitle = "",
xtitle = "",
ytitle = "",
originaltheme = FALSE,
resultssubtitle = FALSE,
testvalue = 0,
bfmessage = FALSE,
conflevel = 0.95,
k = 2,
testvalueline = FALSE,
centralityparameter = "mean",
centralityk = 2,
plotwidth = 650,
plotheight = 450
)Arguments
- data
The data as a data frame.
- dep
A continuous numeric variable for which the distribution will be displayed across different groups using dot plots.
- group
A categorical variable that defines the groups for comparison. Each level will be displayed as a separate group in the dot plot.
- grvar
Optional grouping variable to create separate dot plots for each level of this variable (grouped analysis).
- typestatistics
Choose the appropriate statistical test: Parametric (t-test) assumes normal distribution and equal variances; Nonparametric (Mann-Whitney U) makes no distribution assumptions; Robust uses trimmed means to handle outliers; Bayesian provides evidence strength via Bayes factors.
- effsizetype
Effect size quantifies practical significance: Cohen's d shows standardized difference between groups (small=0.2, medium=0.5, large=0.8); Hedge's g corrects for small samples; Eta/Omega-squared show proportion of variance explained (small=0.01, medium=0.06, large=0.14).
- centralityplotting
Display lines showing the central tendency (mean, median, or trimmed mean) for each group. Helps visualize group differences at a glance.
- centralitytype
Type of central tendency to display: Mean is the average but sensitive to outliers; Median is the middle value and robust to outliers; Trimmed mean excludes extreme values; Bayesian provides probabilistic estimate.
- mytitle
Main title for the plot. Leave blank for automatic title generation based on your variables.
- xtitle
Label for the horizontal axis showing the continuous variable values. Leave blank to use variable name.
- ytitle
Label for the vertical axis showing the group categories. Leave blank to use variable name.
- originaltheme
Use the original ggstatsplot theme instead of jamovi's default theme. The original theme may be more suitable for publications.
- resultssubtitle
Display statistical test results (p-value, effect size, confidence interval) as a subtitle below the plot. Recommended for most analyses.
- testvalue
Reference value for hypothesis testing (usually 0 for group comparisons). Can be changed to test against a specific clinically meaningful value.
- bfmessage
Display Bayes Factor interpretation (evidence strength) when using Bayesian analysis. BF > 3 indicates moderate evidence, BF > 10 strong evidence.
- conflevel
Confidence level for intervals (0.95 = 95 percent confidence interval). This represents the probability that the true population parameter lies within the calculated interval. 95 percent is standard for most analyses.
- k
Number of decimal places for statistical results (p-values, effect sizes). More decimal places show greater precision but may not be clinically meaningful.
- testvalueline
Display a vertical reference line at the test value. Useful for showing clinically significant thresholds or normal reference ranges.
- centralityparameter
Which central tendency measure to show as a vertical line on the plot. Mean is sensitive to outliers; median is more robust for skewed data.
- centralityk
Decimal places for central tendency values displayed on the plot. Should match the precision meaningful for your measurement scale.
- plotwidth
Width of the plot in pixels. Larger values provide more detail but may not fit well in reports. Default: 650 pixels.
- plotheight
Height of the plot in pixels. Adjust based on number of groups to ensure readability. Default: 450 pixels.
