Use this when you have one tumour burden number per patient: either a percent change from baseline you have already calculated (one row per patient), or a single measurement recorded at each visit (one row per patient per visit). It draws waterfall and spider plots, assigns each patient a best response from their largest shrinkage from baseline, and reports ORR and DCR with exact binomial confidence intervals, group comparison, time to response and duration of response. When a time variable is supplied, progression is measured against the patient's smallest recorded burden (nadir), not against baseline. Categories are named CR, PR, SD and PD and the thresholds are adapted from RECIST v1.1, but this is NOT a RECIST v1.1 implementation: because it never sees individual lesions it cannot sum target lesions, detect a new lesion, or judge non-target progression, and it cannot apply the 4-week confirmation rule itself (you may supply your own confirmation column). If your data list each lesion separately, use the lesion-level RECIST v1.1 analysis. It will be available in upcoming releases.
Usage
waterfall(
data,
patientID = NULL,
responseVar = NULL,
timeVar = NULL,
groupVar = NULL,
inputType = "percentage",
sortBy = "response",
sortDirection = "conventional",
showBaseline = TRUE,
confirmationVar = NULL,
ongoingVar = NULL,
responseCategoryVar = NULL,
showCategoryLabels = FALSE,
showSpiderLabels = FALSE,
annotationVars = NULL,
showThresholds = TRUE,
labelOutliers = FALSE,
showMedian = FALSE,
showCI = FALSE,
minResponseForLabel = 50,
colorBy = "recist",
colorScheme = "jamovi",
barAlpha = 1,
barWidth = 0.7,
showWaterfallPlot = TRUE,
showSpiderPlot = FALSE,
spiderColorBy = "response",
spiderColorScheme = "classic",
timeUnitLabel = "generic",
generateCopyReadyReport = FALSE,
showClinicalSignificance = FALSE,
showConfidenceIntervals = TRUE,
enableGuidedMode = FALSE,
showExplanations = FALSE,
showResponseDuration = FALSE,
seed = 123
)Arguments
- data
The data as a data frame.
- patientID
Variable containing patient identifiers (e.g., PT001, Patient_1, Study_ID). Each patient should have a unique identifier for proper analysis.
- responseVar
Response variable: either raw tumor measurements (mm, cm, sum of diameters) or pre-calculated percentage changes from baseline. For raw measurements: requires time variable with baseline at time = 0. For percentages: negative values = tumor shrinkage (good response), positive values = tumor growth (poor response). Example: -30 means 30 percent decrease.
- timeVar
Time point of measurement (e.g., months from baseline, days from treatment start). Required for spider plot and raw measurement processing. Baseline should be time = 0.
- groupVar
Optional grouping variable for coloring bars by patient groups (e.g., treatment arms, disease subtypes). When specified, overrides RECIST category coloring to show group-based colors.
- inputType
Specify data format: 'raw' for actual tumor measurements (requires time variable) or 'percentage' for pre-calculated percentage changes from baseline
- sortBy
Sort the waterfall plot by best response or patient ID.
- sortDirection
Direction for the response sort. 'conventional' places the highest (worst) response on the left and the lowest (best, most negative) on the right, following the standard oncology waterfall convention.
- showBaseline
Draw a horizontal reference line at 0 percent change to mark the baseline.
- confirmationVar
Optional categorical variable indicating response confirmation status (e.g., Confirmed vs Unconfirmed CR/PR). A distinct marker is drawn at each bar tip according to the level of this variable.
- ongoingVar
Optional variable flagging patients still on treatment / with an ongoing response. Truthy values (TRUE, non-zero, or text matching yes/y/true/on/ongoing/1) draw an upward arrow at the bar tip.
- responseCategoryVar
Optional per-patient RECIST category (CR/PR/SD/PD). When supplied it overrides the category computed from the percentage value, so a patient with target-lesion shrinkage can still be classified PD (e.g., a new lesion). Affects both bar coloring and response metrics (ORR/DCR).
- showCategoryLabels
Print the response category (CR, PR, SD, PD) above each waterfall bar, so the category can be read directly instead of being mapped back from the bar colour.
- showSpiderLabels
Label the end of every spider trajectory with its patient ID, so an outlying line can be traced to a patient without reading a large legend.
- annotationVars
Optional patient-level variables drawn as coloured tracks beneath the waterfall bars, aligned to the same patient ordering. One row of tiles per variable. Use for biomarker status, mutation, prior therapy, treatment arm or any covariate you want read off against each patient's response.
- showThresholds
Show +20 percent and -30 percent RECIST v1.1 thresholds as dashed lines. Helps identify Progressive Disease (PD) and Partial Response (PR) cutoffs.
- labelOutliers
Label responses exceeding the specified threshold.
- showMedian
Show median response as a horizontal line.
- showCI
Show confidence interval around median response.
- minResponseForLabel
Minimum response value for labels to be displayed.
- colorBy
Coloring method: RECIST categories or patient groups (requires Group Variable).
- colorScheme
Color scheme for waterfall plot. 'Colorful' provides distinct colors for group-based coloring.
- barAlpha
Transparency of bars in waterfall plot.
- barWidth
Width of bars in waterfall plot.
- showWaterfallPlot
Display the waterfall plot showing best response for each patient.
- showSpiderPlot
Display spider plot showing response trajectories over time (requires time variable).
- spiderColorBy
Coloring method for spider plot: Response status or patient groups. For backward compatibility, defaults to response status coloring.
- spiderColorScheme
Color scheme for spider plot lines and points.
- timeUnitLabel
Label to use for the spider plot time axis. Does not rescale data; only affects axis labeling.
- generateCopyReadyReport
Generate publication-ready result sentences with statistical details
- showClinicalSignificance
Display clinical significance interpretations for ORR and DCR
- showConfidenceIntervals
Calculate and display exact binomial confidence intervals for ORR and DCR
- enableGuidedMode
Enable step-by-step guidance for new users
- showExplanations
Display comprehensive explanation of what this analysis does, when to use it, data requirements, and key assumptions/limitations
- showResponseDuration
Show a censoring-aware time-to-response (TTR) and duration-of-response (DoR) table. DoR is summarized with the Kaplan-Meier median (accounting for responders still in response at last follow-up), which the naive median understates.
- seed
Random seed for the reproducible bootstrap confidence interval of the median response (used when 'Show Confidence Interval' is enabled). Change it to draw a different bootstrap sample; the default (123) reproduces the previous fixed behaviour.
Value
A results object containing:
results$guidedAnalysis | a html | ||||
results$todo | a html | ||||
results$todo2 | a html | ||||
results$clinicalSummary | a html | ||||
results$aboutAnalysis | a html | ||||
results$summaryTable | a table | ||||
results$personTimeTable | a table | ||||
results$clinicalMetrics | a table | ||||
results$waterfallplot | an image | ||||
results$copyReadyReport | a html | ||||
results$clinicalSignificance | a html | ||||
results$clinicalGlossary | a html | ||||
results$enhancedClinicalMetrics | a table | ||||
results$groupComparisonTable | a table | ||||
results$groupComparisonTest | a table | ||||
results$spiderplot | an image | ||||
results$naturalLanguageSummary | a html | ||||
results$explanations | a html | ||||
results$responseDurationTable | a table | ||||
results$addResponseCategory | an output | ||||
results$notices | a html |
Tables can be converted to data frames with asDF or as.data.frame. For example:
results$summaryTable$asDF
as.data.frame(results$summaryTable)
