ClinicoPath Descriptives 04: Data Quality Assessment for Clinical Research
Source:vignettes/clinicopath-descriptives-04-data-quality-exploration.Rmd
clinicopath-descriptives-04-data-quality-exploration.RmdIntroduction
Data quality assessment is fundamental to reliable clinical research. This vignette demonstrates comprehensive data exploration and quality assessment techniques using ClinicoPathDescriptives, including missing data analysis, distribution assessment, outlier detection, and fraud detection using Benford’s law.
Data Quality Framework
Quality Dimensions
- Completeness: Presence of missing data
- Consistency: Logical relationships between variables
- Accuracy: Conformance to expected patterns
- Validity: Adherence to defined formats and ranges
- Integrity: Referential and business rule compliance
library(ClinicoPath)
library(dplyr)
library(tidyr)
library(ggplot2)
library(knitr)
# Load the dataset
data(histopathology)
# Initial data overview
cat("Dataset Dimensions:", dim(histopathology), "\n")
#> Dataset Dimensions: 250 38
cat("Variables:", ncol(histopathology), "\n")
#> Variables: 38
cat("Observations:", nrow(histopathology), "\n\n")
#> Observations: 250
# Variable types overview
str(histopathology, give.attr = FALSE)
#> spc_tbl_ [250 × 38] (S3: spec_tbl_df/tbl_df/tbl/data.frame)
#> $ ID : num [1:250] 1 2 3 4 5 6 7 8 9 10 ...
#> $ Name : chr [1:250] "Tonisia" "Daniyah" "Naviana" "Daerion" ...
#> $ Sex : chr [1:250] "Male" "Female" "Male" "Male" ...
#> $ Age : num [1:250] 27 36 65 51 58 53 33 26 25 68 ...
#> $ Race : chr [1:250] "White" "White" "White" "White" ...
#> $ PreinvasiveComponent: chr [1:250] "Present" "Absent" "Absent" "Absent" ...
#> $ LVI : chr [1:250] "Present" "Absent" "Absent" "Present" ...
#> $ PNI : chr [1:250] "Absent" "Absent" "Absent" "Absent" ...
#> $ LastFollowUpDate : chr [1:250] "2019.10.22 00:00:00" "2019.06.22 00:00:00" "2019.08.22 00:00:00" "2019.03.22 00:00:00" ...
#> $ Death : chr [1:250] "YANLIŞ" "DOĞRU" "DOĞRU" "YANLIŞ" ...
#> $ Group : chr [1:250] "Control" "Treatment" "Control" "Treatment" ...
#> $ Grade : num [1:250] 2 2 1 3 2 2 1 2 3 3 ...
#> $ TStage : num [1:250] 4 4 4 4 1 4 2 3 4 4 ...
#> $ Anti-X-intensity : num [1:250] 3 2 2 3 3 3 2 2 1 2 ...
#> $ Anti-Y-intensity : num [1:250] 1 1 2 3 3 2 2 2 1 3 ...
#> $ LymphNodeMetastasis : chr [1:250] "Present" "Absent" "Absent" "Absent" ...
#> $ Valid : chr [1:250] "YANLIŞ" "DOĞRU" "YANLIŞ" "DOĞRU" ...
#> $ Smoker : chr [1:250] "YANLIŞ" "YANLIŞ" "DOĞRU" "YANLIŞ" ...
#> $ Grade_Level : chr [1:250] "high" "low" "low" "high" ...
#> $ SurgeryDate : chr [1:250] "2019.07.08 00:00:00" "2019.03.18 00:00:00" "2019.05.18 00:00:00" "2018.10.24 00:00:00" ...
#> $ DeathTime : chr [1:250] "Within1Year" "Within1Year" "Within1Year" "Within1Year" ...
#> $ int : chr [1:250] "2019-07-08 UTC--2019-10-22 UTC" "2019-03-18 UTC--2019-06-22 UTC" "2019-05-18 UTC--2019-08-22 UTC" "2018-10-24 UTC--2019-03-22 UTC" ...
#> $ OverallTime : num [1:250] 3.5 3.1 3.1 4.9 3.3 9.3 6.3 9 5.8 9.9 ...
#> $ Outcome : num [1:250] 0 1 1 0 0 0 1 1 1 0 ...
#> $ Mortality5yr : chr [1:250] "Alive" "Dead" "Dead" "Alive" ...
#> $ Rater 1 : num [1:250] 0 1 1 0 0 0 1 1 1 0 ...
#> $ Rater 2 : num [1:250] 0 0 0 0 0 0 0 0 0 0 ...
#> $ Rater 3 : num [1:250] 1 1 1 0 1 1 1 1 1 1 ...
#> $ Rater A : num [1:250] 3 2 3 3 2 3 1 1 2 1 ...
#> $ Rater B : num [1:250] 3 2 3 3 2 3 1 1 2 1 ...
#> $ New Test : num [1:250] 0 0 0 0 0 0 1 0 0 0 ...
#> $ Golden Standart : num [1:250] 0 0 0 0 0 0 0 0 0 0 ...
#> $ MeasurementA : num [1:250] -1.63432 0.37071 0.01585 -1.23584 -0.00141 ...
#> $ MeasurementB : num [1:250] 0.611 0.554 0.742 0.622 0.527 ...
#> $ Disease Status : chr [1:250] "Ill" "Ill" "Healthy" "Ill" ...
#> $ Measurement1 : num [1:250] 0.387 0.829 0.159 2.447 0.847 ...
#> $ Measurement2 : num [1:250] 1.8654 0.5425 0.0701 2.4071 0.5564 ...
#> $ Outcome2 : chr [1:250] "DOD" "DOOC" "AWD" "AWOD" ...Phase 1: Completeness Assessment
Missing Data Analysis
# Calculate missing data percentages
missing_summary <- histopathology %>%
summarise_all(~sum(is.na(.))) %>%
pivot_longer(everything(), names_to = "Variable", values_to = "Missing_Count") %>%
mutate(
Missing_Percentage = round(Missing_Count / nrow(histopathology) * 100, 1),
Data_Quality = case_when(
Missing_Percentage == 0 ~ "Complete",
Missing_Percentage <= 5 ~ "Excellent",
Missing_Percentage <= 10 ~ "Good",
Missing_Percentage <= 20 ~ "Acceptable",
TRUE ~ "Poor"
)
) %>%
arrange(desc(Missing_Percentage))
# Display missing data summary
kable(missing_summary %>% filter(Missing_Count > 0),
caption = "Missing Data Summary",
col.names = c("Variable", "Missing Count", "Missing %", "Quality Rating"))| Variable | Missing Count | Missing % | Quality Rating |
|---|---|---|---|
| OverallTime | 2 | 0.8 | Excellent |
| Name | 1 | 0.4 | Excellent |
| Sex | 1 | 0.4 | Excellent |
| Age | 1 | 0.4 | Excellent |
| Race | 1 | 0.4 | Excellent |
| PreinvasiveComponent | 1 | 0.4 | Excellent |
| LVI | 1 | 0.4 | Excellent |
| PNI | 1 | 0.4 | Excellent |
| LastFollowUpDate | 1 | 0.4 | Excellent |
| Death | 1 | 0.4 | Excellent |
| Group | 1 | 0.4 | Excellent |
| Grade | 1 | 0.4 | Excellent |
| TStage | 1 | 0.4 | Excellent |
| Anti-X-intensity | 1 | 0.4 | Excellent |
| Anti-Y-intensity | 1 | 0.4 | Excellent |
| LymphNodeMetastasis | 1 | 0.4 | Excellent |
| Valid | 1 | 0.4 | Excellent |
| Smoker | 1 | 0.4 | Excellent |
| Grade_Level | 1 | 0.4 | Excellent |
| SurgeryDate | 1 | 0.4 | Excellent |
| Outcome | 1 | 0.4 | Excellent |
| Mortality5yr | 1 | 0.4 | Excellent |
| Rater 1 | 1 | 0.4 | Excellent |
Completeness by Variable Type
# Analyze completeness by variable groups
demographic_vars <- c("Age", "Sex", "Race")
pathology_vars <- c("Grade", "TStage", "LVI", "PNI", "LymphNodeMetastasis")
biomarker_vars <- c("MeasurementA", "MeasurementB", "Anti-X-intensity", "Anti-Y-intensity")
outcome_vars <- c("Outcome", "Death", "OverallTime", "Mortality5yr")
# Function to calculate completeness for variable groups
assess_completeness <- function(data, vars, group_name) {
if(all(vars %in% names(data))) {
completeness <- data %>%
select(all_of(vars)) %>%
summarise_all(~sum(!is.na(.))) %>%
pivot_longer(everything(), names_to = "Variable", values_to = "Complete_Count") %>%
mutate(
Group = group_name,
Completeness_Rate = round(Complete_Count / nrow(data) * 100, 1)
)
return(completeness)
}
return(NULL)
}
# Assess each variable group
completeness_by_group <- bind_rows(
assess_completeness(histopathology, demographic_vars, "Demographics"),
assess_completeness(histopathology, pathology_vars, "Pathology"),
assess_completeness(histopathology, biomarker_vars, "Biomarkers"),
assess_completeness(histopathology, outcome_vars, "Outcomes")
) %>%
filter(!is.null(.))
# Summary by group
group_summary <- completeness_by_group %>%
group_by(Group) %>%
summarise(
Variables = n(),
Mean_Completeness = round(mean(Completeness_Rate), 1),
Min_Completeness = round(min(Completeness_Rate), 1),
.groups = 'drop'
)
kable(group_summary,
caption = "Data Completeness by Variable Group",
col.names = c("Variable Group", "Variables", "Mean Completeness (%)", "Min Completeness (%)"))| Variable Group | Variables | Mean Completeness (%) | Min Completeness (%) |
|---|---|---|---|
| Biomarkers | 4 | 99.8 | 99.6 |
| Demographics | 3 | 99.6 | 99.6 |
| Outcomes | 4 | 99.5 | 99.2 |
| Pathology | 5 | 99.6 | 99.6 |
Phase 2: Distribution Assessment
Continuous Variables Analysis
# Analyze distributions of continuous variables
continuous_vars <- c("Age", "OverallTime", "MeasurementA", "MeasurementB")
# Check which variables exist in the dataset
available_vars <- continuous_vars[continuous_vars %in% names(histopathology)]
if(length(available_vars) > 0) {
tryCatch({
summarydata(
data = histopathology,
vars = available_vars,
date_vars = NULL,
grvar = NULL
)
}, error = function(e) {
cat("Error with summarydata:", conditionMessage(e), "\n")
cat("Available continuous variables:", paste(available_vars, collapse = ", "), "\n")
cat("Variable types:\n")
print(sapply(histopathology[available_vars], class))
})
} else {
cat("No continuous variables found in dataset\n")
}
#> Error with summarydata: 'names' attribute [38] must be the same length as the vector [0]
#> Available continuous variables: Age, OverallTime, MeasurementA, MeasurementB
#> Variable types:
#> Age OverallTime MeasurementA MeasurementB
#> "numeric" "numeric" "numeric" "numeric"Categorical Variables Analysis
# Analyze categorical variable distributions
categorical_vars <- c("Sex", "Grade", "TStage", "Group", "LVI", "PNI")
# Check which categorical variables exist in the dataset
available_cat_vars <- categorical_vars[categorical_vars %in% names(histopathology)]
if(length(available_cat_vars) > 0) {
tryCatch({
reportcat(
data = histopathology,
vars = available_cat_vars
)
}, error = function(e) {
cat("Error with reportcat:", conditionMessage(e), "\n")
cat("Available categorical variables:", paste(available_cat_vars, collapse = ", "), "\n")
})
} else {
cat("No categorical variables found in dataset\n")
}
#> Error with reportcat: 'names' attribute [38] must be the same length as the vector [0]
#> Available categorical variables: Sex, Grade, TStage, Group, LVI, PNIVariable Relationship Overview
# Hierarchical overview of key variables
vartree_vars <- c("Group", "Grade", "TStage", "LVI", "PNI", "LymphNodeMetastasis", "Outcome")
available_vartree_vars <- vartree_vars[vartree_vars %in% names(histopathology)]
if(length(available_vartree_vars) > 0) {
tryCatch({
vartree(
data = histopathology,
vars = available_vartree_vars,
percvar = NULL,
percvarLevel = NULL,
summaryvar = NULL,
prunebelow = NULL,
pruneLevel1 = NULL,
pruneLevel2 = NULL,
follow = NULL,
followLevel1 = NULL,
followLevel2 = NULL,
excl = FALSE,
vp = TRUE,
horizontal = FALSE,
sline = TRUE,
varnames = FALSE,
nodelabel = TRUE,
pct = FALSE
)
}, error = function(e) {
cat("Error with vartree:", conditionMessage(e), "\n")
cat("Available variables for tree:", paste(available_vartree_vars, collapse = ", "), "\n")
})
} else {
cat("No variables found for variable tree\n")
}
#> Error with vartree: 'names' attribute [38] must be the same length as the vector [0]
#> Available variables for tree: Group, Grade, TStage, LVI, PNI, LymphNodeMetastasis, OutcomePhase 3: Consistency and Logic Checks
Temporal Consistency
# Check date consistency (if dates are properly formatted)
date_vars <- histopathology %>%
select(contains("Date")) %>%
names()
if(length(date_vars) > 0) {
cat("Date variables found:", paste(date_vars, collapse = ", "), "\n")
# Basic date analysis
tryCatch({
reportcat(
data = histopathology,
vars = date_vars[1:min(2, length(date_vars))]
)
}, error = function(e) {
cat("Error with date variables reportcat:", conditionMessage(e), "\n")
cat("Date variables:", paste(date_vars, collapse = ", "), "\n")
})
}
#> Date variables found: LastFollowUpDate, SurgeryDate
#> <div id="dfieexombw" style="padding-left:0px;padding-right:0px;padding-top:10px;padding-bottom:10px;overflow-x:auto;overflow-y:auto;width:auto;height:auto;">
#> <style>@import url("https://fonts.googleapis.com/css2?family=Lato:ital,wght@0,100;0,200;0,300;0,400;0,500;0,600;0,700;0,800;0,900;1,100;1,200;1,300;1,400;1,500;1,600;1,700;1,800;1,900&display=swap");
#> #dfieexombw table {
#> font-family: Lato, system-ui, 'Segoe UI', Roboto, Helvetica, Arial, sans-serif, 'Apple Color Emoji', 'Segoe UI Emoji', 'Segoe UI Symbol', 'Noto Color Emoji';
#> -webkit-font-smoothing: antialiased;
#> -moz-osx-font-smoothing: grayscale;
#> }
#>
#> #dfieexombw thead, #dfieexombw tbody, #dfieexombw tfoot, #dfieexombw tr, #dfieexombw td, #dfieexombw th {
#> border-style: none;
#> }
#>
#> #dfieexombw p {
#> margin: 0;
#> padding: 0;
#> }
#>
#> #dfieexombw .gt_table {
#> display: table;
#> border-collapse: collapse;
#> line-height: normal;
#> margin-left: auto;
#> margin-right: auto;
#> color: #333333;
#> font-size: 16px;
#> font-weight: normal;
#> font-style: normal;
#> background-color: #FFFFFF;
#> width: auto;
#> border-top-style: solid;
#> border-top-width: 3px;
#> border-top-color: #FFFFFF;
#> border-right-style: none;
#> border-right-width: 2px;
#> border-right-color: #D3D3D3;
#> border-bottom-style: solid;
#> border-bottom-width: 2px;
#> border-bottom-color: #A8A8A8;
#> border-left-style: none;
#> border-left-width: 2px;
#> border-left-color: #D3D3D3;
#> }
#>
#> #dfieexombw .gt_caption {
#> padding-top: 4px;
#> padding-bottom: 4px;
#> }
#>
#> #dfieexombw .gt_title {
#> color: #333333;
#> font-size: 24px;
#> font-weight: initial;
#> padding-top: 4px;
#> padding-bottom: 4px;
#> padding-left: 5px;
#> padding-right: 5px;
#> border-bottom-color: #FFFFFF;
#> border-bottom-width: 0;
#> }
#>
#> #dfieexombw .gt_subtitle {
#> color: #333333;
#> font-size: 85%;
#> font-weight: initial;
#> padding-top: 3px;
#> padding-bottom: 5px;
#> padding-left: 5px;
#> padding-right: 5px;
#> border-top-color: #FFFFFF;
#> border-top-width: 0;
#> }
#>
#> #dfieexombw .gt_heading {
#> background-color: #FFFFFF;
#> text-align: left;
#> border-bottom-color: #FFFFFF;
#> border-left-style: none;
#> border-left-width: 1px;
#> border-left-color: #D3D3D3;
#> border-right-style: none;
#> border-right-width: 1px;
#> border-right-color: #D3D3D3;
#> }
#>
#> #dfieexombw .gt_bottom_border {
#> border-bottom-style: solid;
#> border-bottom-width: 0px;
#> border-bottom-color: #D3D3D3;
#> }
#>
#> #dfieexombw .gt_col_headings {
#> border-top-style: solid;
#> border-top-width: 0px;
#> border-top-color: #D3D3D3;
#> border-bottom-style: solid;
#> border-bottom-width: 2px;
#> border-bottom-color: #D3D3D3;
#> border-left-style: none;
#> border-left-width: 1px;
#> border-left-color: #D3D3D3;
#> border-right-style: none;
#> border-right-width: 1px;
#> border-right-color: #D3D3D3;
#> }
#>
#> #dfieexombw .gt_col_heading {
#> color: #333333;
#> background-color: #FFFFFF;
#> font-size: 80%;
#> font-weight: bolder;
#> text-transform: uppercase;
#> border-left-style: none;
#> border-left-width: 1px;
#> border-left-color: #D3D3D3;
#> border-right-style: none;
#> border-right-width: 1px;
#> border-right-color: #D3D3D3;
#> vertical-align: bottom;
#> padding-top: 5px;
#> padding-bottom: 6px;
#> padding-left: 5px;
#> padding-right: 5px;
#> overflow-x: hidden;
#> }
#>
#> #dfieexombw .gt_column_spanner_outer {
#> color: #333333;
#> background-color: #FFFFFF;
#> font-size: 80%;
#> font-weight: bolder;
#> text-transform: uppercase;
#> padding-top: 0;
#> padding-bottom: 0;
#> padding-left: 4px;
#> padding-right: 4px;
#> }
#>
#> #dfieexombw .gt_column_spanner_outer:first-child {
#> padding-left: 0;
#> }
#>
#> #dfieexombw .gt_column_spanner_outer:last-child {
#> padding-right: 0;
#> }
#>
#> #dfieexombw .gt_column_spanner {
#> border-bottom-style: solid;
#> border-bottom-width: 2px;
#> border-bottom-color: #D3D3D3;
#> vertical-align: bottom;
#> padding-top: 5px;
#> padding-bottom: 5px;
#> overflow-x: hidden;
#> display: inline-block;
#> width: 100%;
#> }
#>
#> #dfieexombw .gt_spanner_row {
#> border-bottom-style: hidden;
#> }
#>
#> #dfieexombw .gt_group_heading {
#> padding-top: 8px;
#> padding-bottom: 8px;
#> padding-left: 5px;
#> padding-right: 5px;
#> color: #333333;
#> background-color: #FFFFFF;
#> font-size: 80%;
#> font-weight: bolder;
#> text-transform: uppercase;
#> border-top-style: solid;
#> border-top-width: 2px;
#> border-top-color: #D3D3D3;
#> border-bottom-style: solid;
#> border-bottom-width: 2px;
#> border-bottom-color: #D3D3D3;
#> border-left-style: none;
#> border-left-width: 1px;
#> border-left-color: #D3D3D3;
#> border-right-style: none;
#> border-right-width: 1px;
#> border-right-color: #D3D3D3;
#> vertical-align: middle;
#> text-align: left;
#> }
#>
#> #dfieexombw .gt_empty_group_heading {
#> padding: 0.5px;
#> color: #333333;
#> background-color: #FFFFFF;
#> font-size: 80%;
#> font-weight: bolder;
#> border-top-style: solid;
#> border-top-width: 2px;
#> border-top-color: #D3D3D3;
#> border-bottom-style: solid;
#> border-bottom-width: 2px;
#> border-bottom-color: #D3D3D3;
#> vertical-align: middle;
#> }
#>
#> #dfieexombw .gt_from_md > :first-child {
#> margin-top: 0;
#> }
#>
#> #dfieexombw .gt_from_md > :last-child {
#> margin-bottom: 0;
#> }
#>
#> #dfieexombw .gt_row {
#> padding-top: 7px;
#> padding-bottom: 7px;
#> padding-left: 5px;
#> padding-right: 5px;
#> margin: 10px;
#> border-top-style: solid;
#> border-top-width: 1px;
#> border-top-color: #F6F7F7;
#> border-left-style: none;
#> border-left-width: 1px;
#> border-left-color: #D3D3D3;
#> border-right-style: none;
#> border-right-width: 1px;
#> border-right-color: #D3D3D3;
#> vertical-align: middle;
#> overflow-x: hidden;
#> }
#>
#> #dfieexombw .gt_stub {
#> color: #333333;
#> background-color: #FFFFFF;
#> font-size: 80%;
#> font-weight: bolder;
#> text-transform: uppercase;
#> border-right-style: solid;
#> border-right-width: 2px;
#> border-right-color: #D3D3D3;
#> padding-left: 5px;
#> padding-right: 5px;
#> }
#>
#> #dfieexombw .gt_stub_row_group {
#> color: #333333;
#> background-color: #FFFFFF;
#> font-size: 100%;
#> font-weight: initial;
#> text-transform: inherit;
#> border-right-style: solid;
#> border-right-width: 2px;
#> border-right-color: #D3D3D3;
#> padding-left: 5px;
#> padding-right: 5px;
#> vertical-align: top;
#> }
#>
#> #dfieexombw .gt_row_group_first td {
#> border-top-width: 2px;
#> }
#>
#> #dfieexombw .gt_row_group_first th {
#> border-top-width: 2px;
#> }
#>
#> #dfieexombw .gt_summary_row {
#> color: #333333;
#> background-color: #FFFFFF;
#> text-transform: inherit;
#> padding-top: 8px;
#> padding-bottom: 8px;
#> padding-left: 5px;
#> padding-right: 5px;
#> }
#>
#> #dfieexombw .gt_first_summary_row {
#> border-top-style: solid;
#> border-top-color: #D3D3D3;
#> }
#>
#> #dfieexombw .gt_first_summary_row.thick {
#> border-top-width: 2px;
#> }
#>
#> #dfieexombw .gt_last_summary_row {
#> padding-top: 8px;
#> padding-bottom: 8px;
#> padding-left: 5px;
#> padding-right: 5px;
#> border-bottom-style: solid;
#> border-bottom-width: 2px;
#> border-bottom-color: #D3D3D3;
#> }
#>
#> #dfieexombw .gt_grand_summary_row {
#> color: #333333;
#> background-color: #FFFFFF;
#> text-transform: inherit;
#> padding-top: 8px;
#> padding-bottom: 8px;
#> padding-left: 5px;
#> padding-right: 5px;
#> }
#>
#> #dfieexombw .gt_first_grand_summary_row {
#> padding-top: 8px;
#> padding-bottom: 8px;
#> padding-left: 5px;
#> padding-right: 5px;
#> border-top-style: double;
#> border-top-width: 6px;
#> border-top-color: #D3D3D3;
#> }
#>
#> #dfieexombw .gt_last_grand_summary_row_top {
#> padding-top: 8px;
#> padding-bottom: 8px;
#> padding-left: 5px;
#> padding-right: 5px;
#> border-bottom-style: double;
#> border-bottom-width: 6px;
#> border-bottom-color: #D3D3D3;
#> }
#>
#> #dfieexombw .gt_striped {
#> background-color: #FAFAFA;
#> }
#>
#> #dfieexombw .gt_table_body {
#> border-top-style: solid;
#> border-top-width: 2px;
#> border-top-color: #D3D3D3;
#> border-bottom-style: solid;
#> border-bottom-width: 2px;
#> border-bottom-color: #D3D3D3;
#> }
#>
#> #dfieexombw .gt_footnotes {
#> color: #333333;
#> background-color: #FFFFFF;
#> border-bottom-style: none;
#> border-bottom-width: 2px;
#> border-bottom-color: #D3D3D3;
#> border-left-style: none;
#> border-left-width: 2px;
#> border-left-color: #D3D3D3;
#> border-right-style: none;
#> border-right-width: 2px;
#> border-right-color: #D3D3D3;
#> }
#>
#> #dfieexombw .gt_footnote {
#> margin: 0px;
#> font-size: 90%;
#> padding-top: 4px;
#> padding-bottom: 4px;
#> padding-left: 5px;
#> padding-right: 5px;
#> }
#>
#> #dfieexombw .gt_sourcenotes {
#> color: #333333;
#> background-color: #FFFFFF;
#> border-bottom-style: none;
#> border-bottom-width: 2px;
#> border-bottom-color: #D3D3D3;
#> border-left-style: none;
#> border-left-width: 2px;
#> border-left-color: #D3D3D3;
#> border-right-style: none;
#> border-right-width: 2px;
#> border-right-color: #D3D3D3;
#> }
#>
#> #dfieexombw .gt_sourcenote {
#> font-size: 12px;
#> padding-top: 4px;
#> padding-bottom: 4px;
#> padding-left: 5px;
#> padding-right: 5px;
#> }
#>
#> #dfieexombw .gt_left {
#> text-align: left;
#> }
#>
#> #dfieexombw .gt_center {
#> text-align: center;
#> }
#>
#> #dfieexombw .gt_right {
#> text-align: right;
#> font-variant-numeric: tabular-nums;
#> }
#>
#> #dfieexombw .gt_font_normal {
#> font-weight: normal;
#> }
#>
#> #dfieexombw .gt_font_bold {
#> font-weight: bold;
#> }
#>
#> #dfieexombw .gt_font_italic {
#> font-style: italic;
#> }
#>
#> #dfieexombw .gt_super {
#> font-size: 65%;
#> }
#>
#> #dfieexombw .gt_footnote_marks {
#> font-size: 75%;
#> vertical-align: 0.4em;
#> position: initial;
#> }
#>
#> #dfieexombw .gt_asterisk {
#> font-size: 100%;
#> vertical-align: 0;
#> }
#>
#> #dfieexombw .gt_indent_1 {
#> text-indent: 5px;
#> }
#>
#> #dfieexombw .gt_indent_2 {
#> text-indent: 10px;
#> }
#>
#> #dfieexombw .gt_indent_3 {
#> text-indent: 15px;
#> }
#>
#> #dfieexombw .gt_indent_4 {
#> text-indent: 20px;
#> }
#>
#> #dfieexombw .gt_indent_5 {
#> text-indent: 25px;
#> }
#>
#> #dfieexombw .katex-display {
#> display: inline-flex !important;
#> margin-bottom: 0.75em !important;
#> }
#>
#> #dfieexombw div.Reactable > div.rt-table > div.rt-thead > div.rt-tr.rt-tr-group-header > div.rt-th-group:after {
#> height: 0px !important;
#> }
#> </style>
#> <table class="gt_table" data-quarto-disable-processing="false" data-quarto-bootstrap="false">
#> <thead>
#> <tr class="gt_heading">
#> <td colspan="4" class="gt_heading gt_title gt_font_normal" style>.</td>
#> </tr>
#> <tr class="gt_heading">
#> <td colspan="4" class="gt_heading gt_subtitle gt_font_normal gt_bottom_border" style>250 rows x 2 cols</td>
#> </tr>
#> <tr class="gt_col_headings">
#> <th class="gt_col_heading gt_columns_bottom_border gt_left" rowspan="1" colspan="1" scope="col" id="type"></th>
#> <th class="gt_col_heading gt_columns_bottom_border gt_left" rowspan="1" colspan="1" scope="col" id="name">Column</th>
#> <th class="gt_col_heading gt_columns_bottom_border gt_center" rowspan="1" colspan="1" scope="col" id="value">Plot Overview</th>
#> <th class="gt_col_heading gt_columns_bottom_border gt_right" rowspan="1" colspan="1" scope="col" id="n_missing">Missing</th>
#> </tr>
#> </thead>
#> <tbody class="gt_table_body">
#> <tr><td headers="type" class="gt_row gt_left"><svg aria-hidden="true" role="img" viewBox="0 0 512 512" style="height:20px;width:20px;vertical-align:-0.125em;margin-left:auto;margin-right:auto;font-size:inherit;fill:#4e79a7;overflow:visible;position:relative;"><path d="M40 48C26.7 48 16 58.7 16 72v48c0 13.3 10.7 24 24 24H88c13.3 0 24-10.7 24-24V72c0-13.3-10.7-24-24-24H40zM192 64c-17.7 0-32 14.3-32 32s14.3 32 32 32H480c17.7 0 32-14.3 32-32s-14.3-32-32-32H192zm0 160c-17.7 0-32 14.3-32 32s14.3 32 32 32H480c17.7 0 32-14.3 32-32s-14.3-32-32-32H192zm0 160c-17.7 0-32 14.3-32 32s14.3 32 32 32H480c17.7 0 32-14.3 32-32s-14.3-32-32-32H192zM16 232v48c0 13.3 10.7 24 24 24H88c13.3 0 24-10.7 24-24V232c0-13.3-10.7-24-24-24H40c-13.3 0-24 10.7-24 24zM40 368c-13.3 0-24 10.7-24 24v48c0 13.3 10.7 24 24 24H88c13.3 0 24-10.7 24-24V392c0-13.3-10.7-24-24-24H40z"/></svg></td>
#> <td headers="name" class="gt_row gt_left" style="font-weight: bold;"><div style='max-width: 150px;'>
#> <details style='font-weight: normal !important;'>
#> <summary style='font-weight: bold !important;'>LastFollowUpDate</summary>
#> 2019.06.22 00:00:00, 2019.03.22 00:00:00, 2018.12.22 00:00:00, 2019.07.22 00:00:00, 2019.08.22 00:00:00, 2019.02.22 00:00:00, 2019.05.22 00:00:00, 2019.11.22 00:00:00, 2019.01.22 00:00:00, 2019.04.22 00:00:00, 2019.10.22 00:00:00 and 2019.09.22 00:00:00
#> </details></div></td>
#> <td headers="value" class="gt_row gt_center"><?xml version='1.0' encoding='UTF-8' ?><svg xmlns='http://www.w3.org/2000/svg' xmlns:xlink='http://www.w3.org/1999/xlink' width='141.73pt' height='34.02pt' viewBox='0 0 141.73 34.02'><g class='svglite'><defs> <style type='text/css'><![CDATA[ .svglite line, .svglite polyline, .svglite polygon, .svglite path, .svglite rect, .svglite circle { fill: none; stroke: #000000; stroke-linecap: round; stroke-linejoin: round; stroke-miterlimit: 10.00; } .svglite text { white-space: pre; } .svglite g.glyphgroup path { fill: inherit; stroke: none; } ]]></style></defs><rect width='100%' height='100%' style='stroke: none; fill: none;'/><defs> <clipPath id='cpMC4wMHwxNDEuNzN8MC4wMHwzNC4wMg=='> <rect x='0.00' y='0.00' width='141.73' height='34.02' /> </clipPath></defs><g clip-path='url(#cpMC4wMHwxNDEuNzN8MC4wMHwzNC4wMg==)'></g><defs> <clipPath id='cpMS4wMHwxNDAuNzR8Mi45OXwyMy42MQ=='> <rect x='1.00' y='2.99' width='139.74' height='20.62' /> </clipPath></defs><g clip-path='url(#cpMS4wMHwxNDAuNzR8Mi45OXwyMy42MQ==)'><rect x='132.88' y='3.93' width='7.86' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #DDEAF7;' /><rect x='123.34' y='3.93' width='9.54' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #CFE0F2;' /><rect x='112.68' y='3.93' width='10.66' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #C2D6EC;' /><rect x='102.01' y='3.93' width='10.66' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #B4CCE7;' /><rect x='90.79' y='3.93' width='11.22' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #A6C2E2;' /><rect x='79.56' y='3.93' width='11.22' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #98B9DD;' /><rect x='67.78' y='3.93' width='11.79' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #89AFD7;' /><rect x='54.87' y='3.93' width='12.91' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #7AA6D2;' /><rect x='41.96' y='3.93' width='12.91' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #6B9CCD;' /><rect x='29.06' y='3.93' width='12.91' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #5A93C8;' /><rect x='15.59' y='3.93' width='13.47' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #488AC2;' /><rect x='1.00' y='3.93' width='14.59' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #3181BD;' /></g><g clip-path='url(#cpMC4wMHwxNDEuNzN8MC4wMHwzNC4wMg==)'><text x='1.00' y='30.18' style='font-size: 8.00px; font-family: "Arial";' textLength='48.06px' lengthAdjust='spacingAndGlyphs'>12 categories</text></g></g></svg></td>
#> <td headers="n_missing" class="gt_row gt_right">0.4%</td></tr>
#> <tr><td headers="type" class="gt_row gt_left gt_striped"><svg aria-hidden="true" role="img" viewBox="0 0 512 512" style="height:20px;width:20px;vertical-align:-0.125em;margin-left:auto;margin-right:auto;font-size:inherit;fill:#4e79a7;overflow:visible;position:relative;"><path d="M40 48C26.7 48 16 58.7 16 72v48c0 13.3 10.7 24 24 24H88c13.3 0 24-10.7 24-24V72c0-13.3-10.7-24-24-24H40zM192 64c-17.7 0-32 14.3-32 32s14.3 32 32 32H480c17.7 0 32-14.3 32-32s-14.3-32-32-32H192zm0 160c-17.7 0-32 14.3-32 32s14.3 32 32 32H480c17.7 0 32-14.3 32-32s-14.3-32-32-32H192zm0 160c-17.7 0-32 14.3-32 32s14.3 32 32 32H480c17.7 0 32-14.3 32-32s-14.3-32-32-32H192zM16 232v48c0 13.3 10.7 24 24 24H88c13.3 0 24-10.7 24-24V232c0-13.3-10.7-24-24-24H40c-13.3 0-24 10.7-24 24zM40 368c-13.3 0-24 10.7-24 24v48c0 13.3 10.7 24 24 24H88c13.3 0 24-10.7 24-24V392c0-13.3-10.7-24-24-24H40z"/></svg></td>
#> <td headers="name" class="gt_row gt_left gt_striped" style="font-weight: bold;"><div style='max-width: 150px;'>
#> <details style='font-weight: normal !important;'>
#> <summary style='font-weight: bold !important;'>SurgeryDate</summary>
#> 2018.10.19 00:00:00, 2018.12.12 00:00:00, 2017.05.24 00:00:00, 2018.03.23 00:00:00, 2018.06.02 00:00:00, 2018.06.10 00:00:00, 2018.06.21 00:00:00, 2018.07.04 00:00:00, 2018.07.27 00:00:00, 2018.08.08 00:00:00, 2018.08.21 00:00:00, 2018.08.24 00:00:00, 2018.10.01 00:00:00, 2018.10.20 00:00:00, 2018.11.11 00:00:00, 2018.11.16 00:00:00, 2018.11.19 00:00:00, 2018.11.26 00:00:00, 2018.12.04 00:00:00, 2018.12.22 00:00:00, 2018.12.31 00:00:00, 2019.01.17 00:00:00, 2019.02.27 00:00:00, 2019.03.01 00:00:00, 2019.05.02 00:00:00, 2014.03.15 00:00:00, 2014.07.21 00:00:00, 2014.08.10 00:00:00, 2014.09.22 00:00:00, 2014.10.08 00:00:00, 2014.10.10 00:00:00, 2014.12.05 00:00:00, 2014.12.15 00:00:00, 2015.01.02 00:00:00, 2015.01.31 00:00:00, 2015.05.07 00:00:00, 2015.05.11 00:00:00, 2015.05.16 00:00:00, 2015.06.27 00:00:00, 2015.06.29 00:00:00, 2015.09.20 00:00:00, 2015.09.30 00:00:00, 2016.01.26 00:00:00, 2016.02.22 00:00:00, 2016.02.23 00:00:00, 2016.02.28 00:00:00, 2016.03.06 00:00:00, 2016.04.01 00:00:00, 2016.04.05 00:00:00, 2016.04.19 00:00:00, 2016.04.21 00:00:00, 2016.06.07 00:00:00, 2016.06.08 00:00:00, 2016.07.14 00:00:00, 2016.08.11 00:00:00, 2016.08.27 00:00:00, 2016.09.05 00:00:00, 2016.10.15 00:00:00, 2016.10.16 00:00:00, 2016.10.22 00:00:00, 2016.10.30 00:00:00, 2016.11.02 00:00:00, 2016.11.05 00:00:00, 2016.11.07 00:00:00, 2016.11.17 00:00:00, 2016.11.18 00:00:00, 2016.11.26 00:00:00, 2016.11.28 00:00:00, 2016.12.12 00:00:00, 2016.12.21 00:00:00, 2016.12.22 00:00:00, 2016.12.26 00:00:00, 2017.01.07 00:00:00, 2017.01.11 00:00:00, 2017.01.29 00:00:00, 2017.01.30 00:00:00, 2017.01.31 00:00:00, 2017.02.25 00:00:00, 2017.04.11 00:00:00, 2017.04.14 00:00:00, 2017.04.24 00:00:00, 2017.05.12 00:00:00, 2017.05.16 00:00:00, 2017.05.28 00:00:00, 2017.05.31 00:00:00, 2017.06.09 00:00:00, 2017.06.16 00:00:00, 2017.06.29 00:00:00, 2017.06.30 00:00:00, 2017.07.07 00:00:00, 2017.07.11 00:00:00, 2017.07.27 00:00:00, 2017.08.11 00:00:00, 2017.08.13 00:00:00, 2017.08.19 00:00:00, 2017.09.07 00:00:00, 2017.09.27 00:00:00, 2017.10.02 00:00:00, 2017.10.07 00:00:00, 2017.10.08 00:00:00, 2017.10.15 00:00:00, 2017.10.20 00:00:00, 2017.10.28 00:00:00, 2017.11.11 00:00:00, 2017.11.23 00:00:00, 2017.11.27 00:00:00, 2017.12.04 00:00:00, 2017.12.19 00:00:00, 2017.12.20 00:00:00, 2017.12.28 00:00:00, 2018.01.11 00:00:00, 2018.01.21 00:00:00, 2018.01.22 00:00:00, 2018.01.25 00:00:00, 2018.02.03 00:00:00, 2018.02.09 00:00:00, 2018.02.10 00:00:00, 2018.02.24 00:00:00, 2018.03.04 00:00:00, 2018.03.13 00:00:00, 2018.03.14 00:00:00, 2018.03.18 00:00:00, 2018.03.21 00:00:00, 2018.03.24 00:00:00, 2018.03.25 00:00:00, 2018.03.27 00:00:00, 2018.03.28 00:00:00, 2018.03.31 00:00:00, 2018.04.09 00:00:00, 2018.04.18 00:00:00, 2018.04.20 00:00:00, 2018.04.29 00:00:00, 2018.05.07 00:00:00, 2018.05.08 00:00:00, 2018.05.12 00:00:00, 2018.05.13 00:00:00, 2018.05.19 00:00:00, 2018.05.24 00:00:00, 2018.05.26 00:00:00, 2018.05.30 00:00:00, 2018.06.01 00:00:00, 2018.06.03 00:00:00, 2018.06.04 00:00:00, 2018.06.05 00:00:00, 2018.06.18 00:00:00, 2018.06.29 00:00:00, 2018.07.01 00:00:00, 2018.07.02 00:00:00, 2018.07.11 00:00:00, 2018.07.13 00:00:00, 2018.07.18 00:00:00, 2018.07.20 00:00:00, 2018.07.26 00:00:00, 2018.08.02 00:00:00, 2018.08.04 00:00:00, 2018.08.07 00:00:00, 2018.08.10 00:00:00, 2018.08.11 00:00:00, 2018.08.12 00:00:00, 2018.08.13 00:00:00, 2018.08.17 00:00:00, 2018.08.19 00:00:00, 2018.08.23 00:00:00, 2018.08.27 00:00:00, 2018.08.30 00:00:00, 2018.09.02 00:00:00, 2018.09.04 00:00:00, 2018.09.08 00:00:00, 2018.09.11 00:00:00, 2018.09.14 00:00:00, 2018.09.16 00:00:00, 2018.10.02 00:00:00, 2018.10.03 00:00:00, 2018.10.04 00:00:00, 2018.10.09 00:00:00, 2018.10.13 00:00:00, 2018.10.14 00:00:00, 2018.10.17 00:00:00, 2018.10.18 00:00:00, 2018.10.23 00:00:00, 2018.10.24 00:00:00, 2018.10.25 00:00:00, 2018.11.09 00:00:00, 2018.11.15 00:00:00, 2018.11.17 00:00:00, 2018.11.22 00:00:00, 2018.11.27 00:00:00, 2018.11.30 00:00:00, 2018.12.16 00:00:00, 2018.12.29 00:00:00, 2019.01.11 00:00:00, 2019.01.12 00:00:00, 2019.01.13 00:00:00, 2019.01.18 00:00:00, 2019.01.22 00:00:00, 2019.01.24 00:00:00, 2019.02.04 00:00:00, 2019.02.05 00:00:00, 2019.02.08 00:00:00, 2019.02.09 00:00:00, 2019.02.15 00:00:00, 2019.02.16 00:00:00, 2019.02.19 00:00:00, 2019.03.04 00:00:00, 2019.03.12 00:00:00, 2019.03.18 00:00:00, 2019.03.22 00:00:00, 2019.03.26 00:00:00, 2019.03.31 00:00:00, 2019.04.07 00:00:00, 2019.04.19 00:00:00, 2019.05.15 00:00:00, 2019.05.17 00:00:00, 2019.05.18 00:00:00, 2019.05.23 00:00:00, 2019.05.24 00:00:00, 2019.05.25 00:00:00, 2019.06.24 00:00:00, 2019.07.08 00:00:00, 2019.08.05 00:00:00, 2019.08.16 00:00:00 and 2019.08.22 00:00:00
#> </details></div></td>
#> <td headers="value" class="gt_row gt_center gt_striped"><?xml version='1.0' encoding='UTF-8' ?><svg xmlns='http://www.w3.org/2000/svg' xmlns:xlink='http://www.w3.org/1999/xlink' width='141.73pt' height='34.02pt' viewBox='0 0 141.73 34.02'><g class='svglite'><defs> <style type='text/css'><![CDATA[ .svglite line, .svglite polyline, .svglite polygon, .svglite path, .svglite rect, .svglite circle { fill: none; stroke: #000000; stroke-linecap: round; stroke-linejoin: round; stroke-miterlimit: 10.00; } .svglite text { white-space: pre; } .svglite g.glyphgroup path { fill: inherit; stroke: none; } ]]></style></defs><rect width='100%' height='100%' style='stroke: none; fill: none;'/><defs> <clipPath id='cpMC4wMHwxNDEuNzN8MC4wMHwzNC4wMg=='> <rect x='0.00' y='0.00' width='141.73' height='34.02' /> </clipPath></defs><g clip-path='url(#cpMC4wMHwxNDEuNzN8MC4wMHwzNC4wMg==)'></g><defs> <clipPath id='cpMS4wMHwxNDAuNzR8Mi45OXwyMy42MQ=='> <rect x='1.00' y='2.99' width='139.74' height='20.62' /> </clipPath></defs><g clip-path='url(#cpMS4wMHwxNDAuNzR8Mi45OXwyMy42MQ==)'><rect x='140.17' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #DDEAF7;' /><rect x='139.61' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #DCE9F7;' /><rect x='139.05' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #DCE9F6;' /><rect x='138.49' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #DBE8F6;' /><rect x='137.93' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #DAE8F6;' /><rect x='137.37' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #DAE7F6;' /><rect x='136.81' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #D9E7F5;' /><rect x='136.25' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #D8E6F5;' /><rect x='135.69' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #D8E6F5;' /><rect x='135.12' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #D7E5F5;' /><rect x='134.56' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #D6E5F4;' /><rect x='134.00' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #D6E4F4;' /><rect x='133.44' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #D5E4F4;' /><rect x='132.88' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #D4E3F4;' /><rect x='132.32' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #D3E3F3;' /><rect x='131.76' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #D3E2F3;' /><rect x='131.20' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #D2E2F3;' /><rect x='130.63' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #D1E1F3;' /><rect x='130.07' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #D1E1F2;' /><rect x='129.51' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #D0E0F2;' /><rect x='128.95' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #CFE0F2;' /><rect x='128.39' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #CFDFF2;' /><rect x='127.83' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #CEDFF1;' /><rect x='127.27' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #CDDEF1;' /><rect x='126.71' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #CDDEF1;' /><rect x='126.14' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #CCDEF0;' /><rect x='125.58' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #CBDDF0;' /><rect x='125.02' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #CBDDF0;' /><rect x='124.46' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #CADCF0;' /><rect x='123.90' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #C9DCEF;' /><rect x='123.34' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #C9DBEF;' /><rect x='122.78' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #C8DBEF;' /><rect x='122.22' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #C7DAEF;' /><rect x='121.66' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #C7DAEE;' /><rect x='121.09' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #C6D9EE;' /><rect x='120.53' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #C5D9EE;' /><rect x='119.97' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #C5D8EE;' /><rect x='119.41' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #C4D8ED;' /><rect x='118.85' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #C3D7ED;' /><rect x='118.29' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #C2D7ED;' /><rect x='117.73' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #C2D6ED;' /><rect x='117.17' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #C1D6EC;' /><rect x='116.60' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #C0D5EC;' /><rect x='116.04' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #C0D5EC;' /><rect x='115.48' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #BFD4EB;' /><rect x='114.92' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #BED4EB;' /><rect x='114.36' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #BED3EB;' /><rect x='113.80' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #BDD3EB;' /><rect x='113.24' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #BCD2EA;' /><rect x='112.68' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #BCD2EA;' /><rect x='112.11' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #BBD1EA;' /><rect x='111.55' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #BAD1EA;' /><rect x='110.99' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #BAD0E9;' /><rect x='110.43' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #B9D0E9;' /><rect x='109.87' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #B8CFE9;' /><rect x='109.31' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #B7CFE9;' /><rect x='108.75' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #B7CEE8;' /><rect x='108.19' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #B6CEE8;' /><rect x='107.62' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #B5CDE8;' /><rect x='107.06' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #B5CDE8;' /><rect x='106.50' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #B4CCE7;' /><rect x='105.94' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #B3CCE7;' /><rect x='105.38' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #B3CBE7;' /><rect x='104.82' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #B2CBE7;' /><rect x='104.26' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #B1CAE6;' /><rect x='103.70' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #B1CAE6;' /><rect x='103.14' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #B0C9E6;' /><rect x='102.57' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #AFC9E5;' /><rect x='102.01' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #AFC8E5;' /><rect x='101.45' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #AEC8E5;' /><rect x='100.89' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #ADC7E5;' /><rect x='100.33' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #ACC7E4;' /><rect x='99.77' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #ACC6E4;' /><rect x='99.21' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #ABC6E4;' /><rect x='98.65' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #AAC5E4;' /><rect x='98.08' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #AAC5E3;' /><rect x='97.52' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #A9C4E3;' /><rect x='96.96' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #A8C4E3;' /><rect x='96.40' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #A8C3E3;' /><rect x='95.84' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #A7C3E2;' /><rect x='95.28' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #A6C3E2;' /><rect x='94.72' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #A5C2E2;' /><rect x='94.16' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #A5C2E2;' /><rect x='93.59' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #A4C1E1;' /><rect x='93.03' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #A3C1E1;' /><rect x='92.47' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #A3C0E1;' /><rect x='91.91' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #A2C0E0;' /><rect x='91.35' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #A1BFE0;' /><rect x='90.79' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #A1BFE0;' /><rect x='90.23' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #A0BEE0;' /><rect x='89.67' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #9FBEDF;' /><rect x='89.11' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #9EBDDF;' /><rect x='88.54' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #9EBDDF;' /><rect x='87.98' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #9DBCDF;' /><rect x='87.42' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #9CBCDE;' /><rect x='86.86' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #9CBBDE;' /><rect x='86.30' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #9BBBDE;' /><rect x='85.74' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #9ABADE;' /><rect x='85.18' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #9ABADD;' /><rect x='84.62' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #99B9DD;' /><rect x='84.05' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #98B9DD;' /><rect x='83.49' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #97B8DD;' /><rect x='82.93' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #97B8DC;' /><rect x='82.37' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #96B7DC;' /><rect x='81.81' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #95B7DC;' /><rect x='81.25' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #95B6DB;' /><rect x='80.69' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #94B6DB;' /><rect x='80.13' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #93B6DB;' /><rect x='79.56' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #92B5DB;' /><rect x='79.00' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #92B5DA;' /><rect x='78.44' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #91B4DA;' /><rect x='77.88' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #90B4DA;' /><rect x='77.32' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #90B3DA;' /><rect x='76.76' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #8FB3D9;' /><rect x='76.20' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #8EB2D9;' /><rect x='75.64' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #8DB2D9;' /><rect x='75.08' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #8DB1D9;' /><rect x='74.51' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #8CB1D8;' /><rect x='73.95' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #8BB0D8;' /><rect x='73.39' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #8AB0D8;' /><rect x='72.83' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #8AAFD8;' /><rect x='72.27' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #89AFD7;' /><rect x='71.71' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #88AED7;' /><rect x='71.15' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #88AED7;' /><rect x='70.59' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #87ADD6;' /><rect x='70.02' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #86ADD6;' /><rect x='69.46' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #85ADD6;' /><rect x='68.90' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #85ACD6;' /><rect x='68.34' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #84ACD5;' /><rect x='67.78' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #83ABD5;' /><rect x='67.22' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #82ABD5;' /><rect x='66.66' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #82AAD5;' /><rect x='66.10' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #81AAD4;' /><rect x='65.53' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #80A9D4;' /><rect x='64.97' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #7FA9D4;' /><rect x='64.41' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #7FA8D4;' /><rect x='63.85' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #7EA8D3;' /><rect x='63.29' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #7DA7D3;' /><rect x='62.73' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #7CA7D3;' /><rect x='62.17' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #7CA6D3;' /><rect x='61.61' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #7BA6D2;' /><rect x='61.05' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #7AA5D2;' /><rect x='60.48' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #79A5D2;' /><rect x='59.92' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #79A5D2;' /><rect x='59.36' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #78A4D1;' /><rect x='58.80' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #77A4D1;' /><rect x='58.24' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #76A3D1;' /><rect x='57.68' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #76A3D0;' /><rect x='57.12' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #75A2D0;' /><rect x='56.56' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #74A2D0;' /><rect x='55.99' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #73A1D0;' /><rect x='55.43' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #73A1CF;' /><rect x='54.87' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #72A0CF;' /><rect x='54.31' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #71A0CF;' /><rect x='53.75' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #709FCF;' /><rect x='53.19' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #6F9FCE;' /><rect x='52.63' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #6F9ECE;' /><rect x='52.07' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #6E9ECE;' /><rect x='51.50' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #6D9ECE;' /><rect x='50.94' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #6C9DCD;' /><rect x='50.38' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #6B9DCD;' /><rect x='49.82' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #6B9CCD;' /><rect x='49.26' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #6A9CCD;' /><rect x='48.70' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #699BCC;' /><rect x='48.14' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #689BCC;' /><rect x='47.58' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #679ACC;' /><rect x='47.01' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #679ACB;' /><rect x='46.45' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #6699CB;' /><rect x='45.89' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #6599CB;' /><rect x='45.33' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #6498CB;' /><rect x='44.77' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #6398CA;' /><rect x='44.21' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #6398CA;' /><rect x='43.65' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #6297CA;' /><rect x='43.09' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #6197CA;' /><rect x='42.53' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #6096C9;' /><rect x='41.96' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #5F96C9;' /><rect x='41.40' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #5E95C9;' /><rect x='40.84' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #5E95C9;' /><rect x='40.28' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #5D94C8;' /><rect x='39.72' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #5C94C8;' /><rect x='39.16' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #5B93C8;' /><rect x='38.60' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #5A93C8;' /><rect x='38.04' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #5993C7;' /><rect x='37.47' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #5892C7;' /><rect x='36.91' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #5792C7;' /><rect x='36.35' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #5791C6;' /><rect x='35.79' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #5691C6;' /><rect x='35.23' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #5590C6;' /><rect x='34.67' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #5490C6;' /><rect x='34.11' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #538FC5;' /><rect x='33.55' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #528FC5;' /><rect x='32.98' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #518EC5;' /><rect x='32.42' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #508EC5;' /><rect x='31.86' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #4F8EC4;' /><rect x='31.30' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #4E8DC4;' /><rect x='30.74' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #4D8DC4;' /><rect x='30.18' y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #4C8CC4;' /><rect x='29.06' y='3.93' width='1.12' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #4C8CC3;' /><rect x='27.93' y='3.93' width='1.12' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #4B8BC3;' /><rect x='26.81' y='3.93' width='1.12' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #4A8BC3;' /><rect x='25.69' y='3.93' width='1.12' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #498AC3;' /><rect x='24.57' y='3.93' width='1.12' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #488AC2;' /><rect x='23.44' y='3.93' width='1.12' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #4789C2;' /><rect x='22.32' y='3.93' width='1.12' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #4689C2;' /><rect x='21.20' y='3.93' width='1.12' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #4589C1;' /><rect x='20.08' y='3.93' width='1.12' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #4488C1;' /><rect x='18.95' y='3.93' width='1.12' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #4388C1;' /><rect x='17.83' y='3.93' width='1.12' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #4187C1;' /><rect x='16.71' y='3.93' width='1.12' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #4087C0;' /><rect x='15.59' y='3.93' width='1.12' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #3F86C0;' /><rect x='14.47' y='3.93' width='1.12' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #3E86C0;' /><rect x='13.34' y='3.93' width='1.12' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #3D85C0;' /><rect x='12.22' y='3.93' width='1.12' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #3C85BF;' /><rect x='11.10' y='3.93' width='1.12' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #3B85BF;' /><rect x='9.98' y='3.93' width='1.12' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #3A84BF;' /><rect x='8.85' y='3.93' width='1.12' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #3984BF;' /><rect x='7.73' y='3.93' width='1.12' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #3783BE;' /><rect x='6.61' y='3.93' width='1.12' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #3683BE;' /><rect x='5.49' y='3.93' width='1.12' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #3582BE;' /><rect x='4.36' y='3.93' width='1.12' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #3482BE;' /><rect x='2.68' y='3.93' width='1.68' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #3281BD;' /><rect x='1.00' y='3.93' width='1.68' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #3181BD;' /></g><g clip-path='url(#cpMC4wMHwxNDEuNzN8MC4wMHwzNC4wMg==)'><text x='1.00' y='30.18' style='font-size: 8.00px; font-family: "Arial";' textLength='52.52px' lengthAdjust='spacingAndGlyphs'>222 categories</text></g></g></svg></td>
#> <td headers="n_missing" class="gt_row gt_right gt_striped">0.4%</td></tr>
#> </tbody>
#>
#>
#> </table>
#> </div>
#>
#> SUMMARY OF CATEGORICAL VARIABLES
#>
#> character(0)
#>
#> LastFollowUpDate has 250 observations and 12 levels.
#> 2018.12.22 00:00:00: n = 23, 9.24% of valid cases.
#> 2019.01.22 00:00:00: n = 19, 7.63% of valid cases.
#> 2019.02.22 00:00:00: n = 21, 8.43% of valid cases.
#> 2019.03.22 00:00:00: n = 24, 9.64% of valid cases.
#> 2019.04.22 00:00:00: n = 19, 7.63% of valid cases.
#> 2019.05.22 00:00:00: n = 20, 8.03% of valid cases.
#> 2019.06.22 00:00:00: n = 26, 10.44% of valid cases.
#> 2019.07.22 00:00:00: n = 23, 9.24% of valid cases.
#> 2019.08.22 00:00:00: n = 23, 9.24% of valid cases.
#> 2019.09.22 00:00:00: n = 14, 5.62% of valid cases.
#> 2019.10.22 00:00:00: n = 17, 6.83% of valid cases.
#> 2019.11.22 00:00:00: n = 20, 8.03% of valid cases.
#> Missing values: 1.
#>
#> SurgeryDate has 250 observations and 222 levels.
#> (Other): n = 124, 49.8% of valid cases.
#> 2014.03.15 00:00:00: n = 1, 0.4% of valid cases.
#> 2014.07.21 00:00:00: n = 1, 0.4% of valid cases.
#> 2014.08.10 00:00:00: n = 1, 0.4% of valid cases.
#> 2014.09.22 00:00:00: n = 1, 0.4% of valid cases.
#> 2014.10.08 00:00:00: n = 1, 0.4% of valid cases.
#> 2014.10.10 00:00:00: n = 1, 0.4% of valid cases.
#> 2014.12.05 00:00:00: n = 1, 0.4% of valid cases.
#> 2014.12.15 00:00:00: n = 1, 0.4% of valid cases.
#> 2015.01.02 00:00:00: n = 1, 0.4% of valid cases.
#> 2015.01.31 00:00:00: n = 1, 0.4% of valid cases.
#> 2015.05.07 00:00:00: n = 1, 0.4% of valid cases.
#> 2015.05.11 00:00:00: n = 1, 0.4% of valid cases.
#> 2015.05.16 00:00:00: n = 1, 0.4% of valid cases.
#> 2015.06.27 00:00:00: n = 1, 0.4% of valid cases.
#> 2015.06.29 00:00:00: n = 1, 0.4% of valid cases.
#> 2015.09.20 00:00:00: n = 1, 0.4% of valid cases.
#> 2015.09.30 00:00:00: n = 1, 0.4% of valid cases.
#> 2016.01.26 00:00:00: n = 1, 0.4% of valid cases.
#> 2016.02.22 00:00:00: n = 1, 0.4% of valid cases.
#> 2016.02.23 00:00:00: n = 1, 0.4% of valid cases.
#> 2016.02.28 00:00:00: n = 1, 0.4% of valid cases.
#> 2016.03.06 00:00:00: n = 1, 0.4% of valid cases.
#> 2016.04.01 00:00:00: n = 1, 0.4% of valid cases.
#> 2016.04.05 00:00:00: n = 1, 0.4% of valid cases.
#> 2016.04.19 00:00:00: n = 1, 0.4% of valid cases.
#> 2016.04.21 00:00:00: n = 1, 0.4% of valid cases.
#> 2016.06.07 00:00:00: n = 1, 0.4% of valid cases.
#> 2016.06.08 00:00:00: n = 1, 0.4% of valid cases.
#> 2016.07.14 00:00:00: n = 1, 0.4% of valid cases.
#> 2016.08.11 00:00:00: n = 1, 0.4% of valid cases.
#> 2016.08.27 00:00:00: n = 1, 0.4% of valid cases.
#> 2016.09.05 00:00:00: n = 1, 0.4% of valid cases.
#> 2016.10.15 00:00:00: n = 1, 0.4% of valid cases.
#> 2016.10.16 00:00:00: n = 1, 0.4% of valid cases.
#> 2016.10.22 00:00:00: n = 1, 0.4% of valid cases.
#> 2016.10.30 00:00:00: n = 1, 0.4% of valid cases.
#> 2016.11.02 00:00:00: n = 1, 0.4% of valid cases.
#> 2016.11.05 00:00:00: n = 1, 0.4% of valid cases.
#> 2016.11.07 00:00:00: n = 1, 0.4% of valid cases.
#> 2016.11.17 00:00:00: n = 1, 0.4% of valid cases.
#> 2016.11.18 00:00:00: n = 1, 0.4% of valid cases.
#> 2016.11.26 00:00:00: n = 1, 0.4% of valid cases.
#> 2016.11.28 00:00:00: n = 1, 0.4% of valid cases.
#> 2016.12.12 00:00:00: n = 1, 0.4% of valid cases.
#> 2016.12.21 00:00:00: n = 1, 0.4% of valid cases.
#> 2016.12.22 00:00:00: n = 1, 0.4% of valid cases.
#> 2016.12.26 00:00:00: n = 1, 0.4% of valid cases.
#> 2017.01.07 00:00:00: n = 1, 0.4% of valid cases.
#> 2017.01.11 00:00:00: n = 1, 0.4% of valid cases.
#> 2017.01.29 00:00:00: n = 1, 0.4% of valid cases.
#> 2017.01.30 00:00:00: n = 1, 0.4% of valid cases.
#> 2017.01.31 00:00:00: n = 1, 0.4% of valid cases.
#> 2017.02.25 00:00:00: n = 1, 0.4% of valid cases.
#> 2017.04.11 00:00:00: n = 1, 0.4% of valid cases.
#> 2017.04.14 00:00:00: n = 1, 0.4% of valid cases.
#> 2017.04.24 00:00:00: n = 1, 0.4% of valid cases.
#> 2017.05.12 00:00:00: n = 1, 0.4% of valid cases.
#> 2017.05.16 00:00:00: n = 1, 0.4% of valid cases.
#> 2017.05.24 00:00:00: n = 2, 0.8% of valid cases.
#> 2017.05.28 00:00:00: n = 1, 0.4% of valid cases.
#> 2017.05.31 00:00:00: n = 1, 0.4% of valid cases.
#> 2017.06.09 00:00:00: n = 1, 0.4% of valid cases.
#> 2017.06.16 00:00:00: n = 1, 0.4% of valid cases.
#> 2017.06.29 00:00:00: n = 1, 0.4% of valid cases.
#> 2017.06.30 00:00:00: n = 1, 0.4% of valid cases.
#> 2017.07.07 00:00:00: n = 1, 0.4% of valid cases.
#> 2017.07.11 00:00:00: n = 1, 0.4% of valid cases.
#> 2017.07.27 00:00:00: n = 1, 0.4% of valid cases.
#> 2017.08.11 00:00:00: n = 1, 0.4% of valid cases.
#> 2017.08.13 00:00:00: n = 1, 0.4% of valid cases.
#> 2017.08.19 00:00:00: n = 1, 0.4% of valid cases.
#> 2017.09.07 00:00:00: n = 1, 0.4% of valid cases.
#> 2017.09.27 00:00:00: n = 1, 0.4% of valid cases.
#> 2017.10.02 00:00:00: n = 1, 0.4% of valid cases.
#> 2018.03.23 00:00:00: n = 2, 0.8% of valid cases.
#> 2018.06.02 00:00:00: n = 2, 0.8% of valid cases.
#> 2018.06.10 00:00:00: n = 2, 0.8% of valid cases.
#> 2018.06.21 00:00:00: n = 2, 0.8% of valid cases.
#> 2018.07.04 00:00:00: n = 2, 0.8% of valid cases.
#> 2018.07.27 00:00:00: n = 2, 0.8% of valid cases.
#> 2018.08.08 00:00:00: n = 2, 0.8% of valid cases.
#> 2018.08.21 00:00:00: n = 2, 0.8% of valid cases.
#> 2018.08.24 00:00:00: n = 2, 0.8% of valid cases.
#> 2018.10.01 00:00:00: n = 2, 0.8% of valid cases.
#> 2018.10.19 00:00:00: n = 3, 1.2% of valid cases.
#> 2018.10.20 00:00:00: n = 2, 0.8% of valid cases.
#> 2018.11.11 00:00:00: n = 2, 0.8% of valid cases.
#> 2018.11.16 00:00:00: n = 2, 0.8% of valid cases.
#> 2018.11.19 00:00:00: n = 2, 0.8% of valid cases.
#> 2018.11.26 00:00:00: n = 2, 0.8% of valid cases.
#> 2018.12.04 00:00:00: n = 2, 0.8% of valid cases.
#> 2018.12.12 00:00:00: n = 3, 1.2% of valid cases.
#> 2018.12.22 00:00:00: n = 2, 0.8% of valid cases.
#> 2018.12.31 00:00:00: n = 2, 0.8% of valid cases.
#> 2019.01.17 00:00:00: n = 2, 0.8% of valid cases.
#> 2019.02.27 00:00:00: n = 2, 0.8% of valid cases.
#> 2019.03.01 00:00:00: n = 2, 0.8% of valid cases.
#> 2019.05.02 00:00:00: n = 2, 0.8% of valid cases.
#> Missing values: 1.
#>
#> <table class="gt_table" data-quarto-disable-processing="false"
#> data-quarto-bootstrap="false">
#>
#> <tr class="gt_heading">
#> <td colspan="4" class="gt_heading gt_title gt_font_normal" style>.
#>
#> <tr class="gt_heading">
#> <td colspan="4" class="gt_heading gt_subtitle gt_font_normal
#> gt_bottom_border" style>250 rows x 2 cols
#>
#> <tr class="gt_col_headings">
#> <th class="gt_col_heading gt_columns_bottom_border gt_left"
#> rowspan="1" colspan="1" scope="col" id="type">
#> <th class="gt_col_heading gt_columns_bottom_border gt_left"
#> rowspan="1" colspan="1" scope="col" id="name">Column
#> <th class="gt_col_heading gt_columns_bottom_border gt_center"
#> rowspan="1" colspan="1" scope="col" id="value">Plot Overview
#> <th class="gt_col_heading gt_columns_bottom_border gt_right"
#> rowspan="1" colspan="1" scope="col" id="n_missing">Missing
#>
#>
#> <tbody class="gt_table_body">
#> <td headers="type" class="gt_row gt_left"><svg aria-hidden="true"
#> role="img" viewBox="0 0 512 512"
#> style="height:20px;width:20px;vertical-align:-0.125em;margin-left:auto;margin-right:auto;font-size:inherit;fill:#4e79a7;overflow:visible;position:relative;"><path
#> d="M40 48C26.7 48 16 58.7 16 72v48c0 13.3 10.7 24 24 24H88c13.3 0
#> 24-10.7 24-24V72c0-13.3-10.7-24-24-24H40zM192 64c-17.7 0-32 14.3-32
#> 32s14.3 32 32 32H480c17.7 0 32-14.3 32-32s-14.3-32-32-32H192zm0
#> 160c-17.7 0-32 14.3-32 32s14.3 32 32 32H480c17.7 0 32-14.3
#> 32-32s-14.3-32-32-32H192zm0 160c-17.7 0-32 14.3-32 32s14.3 32 32
#> 32H480c17.7 0 32-14.3 32-32s-14.3-32-32-32H192zM16 232v48c0 13.3 10.7
#> 24 24 24H88c13.3 0 24-10.7 24-24V232c0-13.3-10.7-24-24-24H40c-13.3
#> 0-24 10.7-24 24zM40 368c-13.3 0-24 10.7-24 24v48c0 13.3 10.7 24 24
#> 24H88c13.3 0 24-10.7 24-24V392c0-13.3-10.7-24-24-24H40z"/>
#> <td headers="name" class="gt_row gt_left" style="font-weight:
#> bold;"><div style='max-width: 150px;'>
#> <details style='font-weight: normal !important;'>
#> <summary style='font-weight: bold !important;'>LastFollowUpDate
#> 2019.06.22 00:00:00, 2019.03.22 00:00:00, 2018.12.22 00:00:00,
#> 2019.07.22 00:00:00, 2019.08.22 00:00:00, 2019.02.22 00:00:00,
#> 2019.05.22 00:00:00, 2019.11.22 00:00:00, 2019.01.22 00:00:00,
#> 2019.04.22 00:00:00, 2019.10.22 00:00:00 and 2019.09.22 00:00:00
#>
#> <td headers="value" class="gt_row gt_center"><?xml version='1.0'
#> encoding='UTF-8' ?><svg xmlns='http://www.w3.org/2000/svg'
#> xmlns:xlink='http://www.w3.org/1999/xlink' width='141.73pt'
#> height='34.02pt' viewBox='0 0 141.73 34.02'><g class='svglite'> <style
#> type='text/css'><![CDATA[ .svglite line, .svglite polyline, .svglite
#> polygon, .svglite path, .svglite rect, .svglite circle { fill: none;
#> stroke: #000000; stroke-linecap: round; stroke-linejoin: round;
#> stroke-miterlimit: 10.00; } .svglite text { white-space: pre; }
#> .svglite g.glyphgroup path { fill: inherit; stroke: none; } ]]><rect
#> width='100%' height='100%' style='stroke: none; fill: none;'/>
#> <clipPath id='cpMC4wMHwxNDEuNzN8MC4wMHwzNC4wMg=='> <rect x='0.00'
#> y='0.00' width='141.73' height='34.02' /> <g
#> clip-path='url(#cpMC4wMHwxNDEuNzN8MC4wMHwzNC4wMg==)'> <clipPath
#> id='cpMS4wMHwxNDAuNzR8Mi45OXwyMy42MQ=='> <rect x='1.00' y='2.99'
#> width='139.74' height='20.62' /> <g
#> clip-path='url(#cpMS4wMHwxNDAuNzR8Mi45OXwyMy42MQ==)'><rect x='132.88'
#> y='3.93' width='7.86' height='18.75' style='stroke-width: 1.07;
#> stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill:
#> #DDEAF7;' /><rect x='123.34' y='3.93' width='9.54' height='18.75'
#> style='stroke-width: 1.07; stroke: none; stroke-linecap: butt;
#> stroke-linejoin: miter; fill: #CFE0F2;' /><rect x='112.68' y='3.93'
#> width='10.66' height='18.75' style='stroke-width: 1.07; stroke: none;
#> stroke-linecap: butt; stroke-linejoin: miter; fill: #C2D6EC;' /><rect
#> x='102.01' y='3.93' width='10.66' height='18.75' style='stroke-width:
#> 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter;
#> fill: #B4CCE7;' /><rect x='90.79' y='3.93' width='11.22'
#> height='18.75' style='stroke-width: 1.07; stroke: none;
#> stroke-linecap: butt; stroke-linejoin: miter; fill: #A6C2E2;' /><rect
#> x='79.56' y='3.93' width='11.22' height='18.75' style='stroke-width:
#> 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter;
#> fill: #98B9DD;' /><rect x='67.78' y='3.93' width='11.79'
#> height='18.75' style='stroke-width: 1.07; stroke: none;
#> stroke-linecap: butt; stroke-linejoin: miter; fill: #89AFD7;' /><rect
#> x='54.87' y='3.93' width='12.91' height='18.75' style='stroke-width:
#> 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter;
#> fill: #7AA6D2;' /><rect x='41.96' y='3.93' width='12.91'
#> height='18.75' style='stroke-width: 1.07; stroke: none;
#> stroke-linecap: butt; stroke-linejoin: miter; fill: #6B9CCD;' /><rect
#> x='29.06' y='3.93' width='12.91' height='18.75' style='stroke-width:
#> 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter;
#> fill: #5A93C8;' /><rect x='15.59' y='3.93' width='13.47'
#> height='18.75' style='stroke-width: 1.07; stroke: none;
#> stroke-linecap: butt; stroke-linejoin: miter; fill: #488AC2;' /><rect
#> x='1.00' y='3.93' width='14.59' height='18.75' style='stroke-width:
#> 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter;
#> fill: #3181BD;' /><g
#> clip-path='url(#cpMC4wMHwxNDEuNzN8MC4wMHwzNC4wMg==)'><text x='1.00'
#> y='30.18' style='font-size: 8.00px; font-family: "Arial";'
#> textLength='48.06px' lengthAdjust='spacingAndGlyphs'>12 categories
#> <td headers="n_missing" class="gt_row gt_right">0.4%
#> <td headers="type" class="gt_row gt_left gt_striped"><svg
#> aria-hidden="true" role="img" viewBox="0 0 512 512"
#> style="height:20px;width:20px;vertical-align:-0.125em;margin-left:auto;margin-right:auto;font-size:inherit;fill:#4e79a7;overflow:visible;position:relative;"><path
#> d="M40 48C26.7 48 16 58.7 16 72v48c0 13.3 10.7 24 24 24H88c13.3 0
#> 24-10.7 24-24V72c0-13.3-10.7-24-24-24H40zM192 64c-17.7 0-32 14.3-32
#> 32s14.3 32 32 32H480c17.7 0 32-14.3 32-32s-14.3-32-32-32H192zm0
#> 160c-17.7 0-32 14.3-32 32s14.3 32 32 32H480c17.7 0 32-14.3
#> 32-32s-14.3-32-32-32H192zm0 160c-17.7 0-32 14.3-32 32s14.3 32 32
#> 32H480c17.7 0 32-14.3 32-32s-14.3-32-32-32H192zM16 232v48c0 13.3 10.7
#> 24 24 24H88c13.3 0 24-10.7 24-24V232c0-13.3-10.7-24-24-24H40c-13.3
#> 0-24 10.7-24 24zM40 368c-13.3 0-24 10.7-24 24v48c0 13.3 10.7 24 24
#> 24H88c13.3 0 24-10.7 24-24V392c0-13.3-10.7-24-24-24H40z"/>
#> <td headers="name" class="gt_row gt_left gt_striped"
#> style="font-weight: bold;"><div style='max-width: 150px;'>
#> <details style='font-weight: normal !important;'>
#> <summary style='font-weight: bold !important;'>SurgeryDate
#> 2018.10.19 00:00:00, 2018.12.12 00:00:00, 2017.05.24 00:00:00,
#> 2018.03.23 00:00:00, 2018.06.02 00:00:00, 2018.06.10 00:00:00,
#> 2018.06.21 00:00:00, 2018.07.04 00:00:00, 2018.07.27 00:00:00,
#> 2018.08.08 00:00:00, 2018.08.21 00:00:00, 2018.08.24 00:00:00,
#> 2018.10.01 00:00:00, 2018.10.20 00:00:00, 2018.11.11 00:00:00,
#> 2018.11.16 00:00:00, 2018.11.19 00:00:00, 2018.11.26 00:00:00,
#> 2018.12.04 00:00:00, 2018.12.22 00:00:00, 2018.12.31 00:00:00,
#> 2019.01.17 00:00:00, 2019.02.27 00:00:00, 2019.03.01 00:00:00,
#> 2019.05.02 00:00:00, 2014.03.15 00:00:00, 2014.07.21 00:00:00,
#> 2014.08.10 00:00:00, 2014.09.22 00:00:00, 2014.10.08 00:00:00,
#> 2014.10.10 00:00:00, 2014.12.05 00:00:00, 2014.12.15 00:00:00,
#> 2015.01.02 00:00:00, 2015.01.31 00:00:00, 2015.05.07 00:00:00,
#> 2015.05.11 00:00:00, 2015.05.16 00:00:00, 2015.06.27 00:00:00,
#> 2015.06.29 00:00:00, 2015.09.20 00:00:00, 2015.09.30 00:00:00,
#> 2016.01.26 00:00:00, 2016.02.22 00:00:00, 2016.02.23 00:00:00,
#> 2016.02.28 00:00:00, 2016.03.06 00:00:00, 2016.04.01 00:00:00,
#> 2016.04.05 00:00:00, 2016.04.19 00:00:00, 2016.04.21 00:00:00,
#> 2016.06.07 00:00:00, 2016.06.08 00:00:00, 2016.07.14 00:00:00,
#> 2016.08.11 00:00:00, 2016.08.27 00:00:00, 2016.09.05 00:00:00,
#> 2016.10.15 00:00:00, 2016.10.16 00:00:00, 2016.10.22 00:00:00,
#> 2016.10.30 00:00:00, 2016.11.02 00:00:00, 2016.11.05 00:00:00,
#> 2016.11.07 00:00:00, 2016.11.17 00:00:00, 2016.11.18 00:00:00,
#> 2016.11.26 00:00:00, 2016.11.28 00:00:00, 2016.12.12 00:00:00,
#> 2016.12.21 00:00:00, 2016.12.22 00:00:00, 2016.12.26 00:00:00,
#> 2017.01.07 00:00:00, 2017.01.11 00:00:00, 2017.01.29 00:00:00,
#> 2017.01.30 00:00:00, 2017.01.31 00:00:00, 2017.02.25 00:00:00,
#> 2017.04.11 00:00:00, 2017.04.14 00:00:00, 2017.04.24 00:00:00,
#> 2017.05.12 00:00:00, 2017.05.16 00:00:00, 2017.05.28 00:00:00,
#> 2017.05.31 00:00:00, 2017.06.09 00:00:00, 2017.06.16 00:00:00,
#> 2017.06.29 00:00:00, 2017.06.30 00:00:00, 2017.07.07 00:00:00,
#> 2017.07.11 00:00:00, 2017.07.27 00:00:00, 2017.08.11 00:00:00,
#> 2017.08.13 00:00:00, 2017.08.19 00:00:00, 2017.09.07 00:00:00,
#> 2017.09.27 00:00:00, 2017.10.02 00:00:00, 2017.10.07 00:00:00,
#> 2017.10.08 00:00:00, 2017.10.15 00:00:00, 2017.10.20 00:00:00,
#> 2017.10.28 00:00:00, 2017.11.11 00:00:00, 2017.11.23 00:00:00,
#> 2017.11.27 00:00:00, 2017.12.04 00:00:00, 2017.12.19 00:00:00,
#> 2017.12.20 00:00:00, 2017.12.28 00:00:00, 2018.01.11 00:00:00,
#> 2018.01.21 00:00:00, 2018.01.22 00:00:00, 2018.01.25 00:00:00,
#> 2018.02.03 00:00:00, 2018.02.09 00:00:00, 2018.02.10 00:00:00,
#> 2018.02.24 00:00:00, 2018.03.04 00:00:00, 2018.03.13 00:00:00,
#> 2018.03.14 00:00:00, 2018.03.18 00:00:00, 2018.03.21 00:00:00,
#> 2018.03.24 00:00:00, 2018.03.25 00:00:00, 2018.03.27 00:00:00,
#> 2018.03.28 00:00:00, 2018.03.31 00:00:00, 2018.04.09 00:00:00,
#> 2018.04.18 00:00:00, 2018.04.20 00:00:00, 2018.04.29 00:00:00,
#> 2018.05.07 00:00:00, 2018.05.08 00:00:00, 2018.05.12 00:00:00,
#> 2018.05.13 00:00:00, 2018.05.19 00:00:00, 2018.05.24 00:00:00,
#> 2018.05.26 00:00:00, 2018.05.30 00:00:00, 2018.06.01 00:00:00,
#> 2018.06.03 00:00:00, 2018.06.04 00:00:00, 2018.06.05 00:00:00,
#> 2018.06.18 00:00:00, 2018.06.29 00:00:00, 2018.07.01 00:00:00,
#> 2018.07.02 00:00:00, 2018.07.11 00:00:00, 2018.07.13 00:00:00,
#> 2018.07.18 00:00:00, 2018.07.20 00:00:00, 2018.07.26 00:00:00,
#> 2018.08.02 00:00:00, 2018.08.04 00:00:00, 2018.08.07 00:00:00,
#> 2018.08.10 00:00:00, 2018.08.11 00:00:00, 2018.08.12 00:00:00,
#> 2018.08.13 00:00:00, 2018.08.17 00:00:00, 2018.08.19 00:00:00,
#> 2018.08.23 00:00:00, 2018.08.27 00:00:00, 2018.08.30 00:00:00,
#> 2018.09.02 00:00:00, 2018.09.04 00:00:00, 2018.09.08 00:00:00,
#> 2018.09.11 00:00:00, 2018.09.14 00:00:00, 2018.09.16 00:00:00,
#> 2018.10.02 00:00:00, 2018.10.03 00:00:00, 2018.10.04 00:00:00,
#> 2018.10.09 00:00:00, 2018.10.13 00:00:00, 2018.10.14 00:00:00,
#> 2018.10.17 00:00:00, 2018.10.18 00:00:00, 2018.10.23 00:00:00,
#> 2018.10.24 00:00:00, 2018.10.25 00:00:00, 2018.11.09 00:00:00,
#> 2018.11.15 00:00:00, 2018.11.17 00:00:00, 2018.11.22 00:00:00,
#> 2018.11.27 00:00:00, 2018.11.30 00:00:00, 2018.12.16 00:00:00,
#> 2018.12.29 00:00:00, 2019.01.11 00:00:00, 2019.01.12 00:00:00,
#> 2019.01.13 00:00:00, 2019.01.18 00:00:00, 2019.01.22 00:00:00,
#> 2019.01.24 00:00:00, 2019.02.04 00:00:00, 2019.02.05 00:00:00,
#> 2019.02.08 00:00:00, 2019.02.09 00:00:00, 2019.02.15 00:00:00,
#> 2019.02.16 00:00:00, 2019.02.19 00:00:00, 2019.03.04 00:00:00,
#> 2019.03.12 00:00:00, 2019.03.18 00:00:00, 2019.03.22 00:00:00,
#> 2019.03.26 00:00:00, 2019.03.31 00:00:00, 2019.04.07 00:00:00,
#> 2019.04.19 00:00:00, 2019.05.15 00:00:00, 2019.05.17 00:00:00,
#> 2019.05.18 00:00:00, 2019.05.23 00:00:00, 2019.05.24 00:00:00,
#> 2019.05.25 00:00:00, 2019.06.24 00:00:00, 2019.07.08 00:00:00,
#> 2019.08.05 00:00:00, 2019.08.16 00:00:00 and 2019.08.22 00:00:00
#>
#> <td headers="value" class="gt_row gt_center gt_striped"><?xml
#> version='1.0' encoding='UTF-8' ?><svg
#> xmlns='http://www.w3.org/2000/svg'
#> xmlns:xlink='http://www.w3.org/1999/xlink' width='141.73pt'
#> height='34.02pt' viewBox='0 0 141.73 34.02'><g class='svglite'> <style
#> type='text/css'><![CDATA[ .svglite line, .svglite polyline, .svglite
#> polygon, .svglite path, .svglite rect, .svglite circle { fill: none;
#> stroke: #000000; stroke-linecap: round; stroke-linejoin: round;
#> stroke-miterlimit: 10.00; } .svglite text { white-space: pre; }
#> .svglite g.glyphgroup path { fill: inherit; stroke: none; } ]]><rect
#> width='100%' height='100%' style='stroke: none; fill: none;'/>
#> <clipPath id='cpMC4wMHwxNDEuNzN8MC4wMHwzNC4wMg=='> <rect x='0.00'
#> y='0.00' width='141.73' height='34.02' /> <g
#> clip-path='url(#cpMC4wMHwxNDEuNzN8MC4wMHwzNC4wMg==)'> <clipPath
#> id='cpMS4wMHwxNDAuNzR8Mi45OXwyMy42MQ=='> <rect x='1.00' y='2.99'
#> width='139.74' height='20.62' /> <g
#> clip-path='url(#cpMS4wMHwxNDAuNzR8Mi45OXwyMy42MQ==)'><rect x='140.17'
#> y='3.93' width='0.56' height='18.75' style='stroke-width: 1.07;
#> stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill:
#> #DDEAF7;' /><rect x='139.61' y='3.93' width='0.56' height='18.75'
#> style='stroke-width: 1.07; stroke: none; stroke-linecap: butt;
#> stroke-linejoin: miter; fill: #DCE9F7;' /><rect x='139.05' y='3.93'
#> width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none;
#> stroke-linecap: butt; stroke-linejoin: miter; fill: #DCE9F6;' /><rect
#> x='138.49' y='3.93' width='0.56' height='18.75' style='stroke-width:
#> 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter;
#> fill: #DBE8F6;' /><rect x='137.93' y='3.93' width='0.56'
#> height='18.75' style='stroke-width: 1.07; stroke: none;
#> stroke-linecap: butt; stroke-linejoin: miter; fill: #DAE8F6;' /><rect
#> x='137.37' y='3.93' width='0.56' height='18.75' style='stroke-width:
#> 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter;
#> fill: #DAE7F6;' /><rect x='136.81' y='3.93' width='0.56'
#> height='18.75' style='stroke-width: 1.07; stroke: none;
#> stroke-linecap: butt; stroke-linejoin: miter; fill: #D9E7F5;' /><rect
#> x='136.25' y='3.93' width='0.56' height='18.75' style='stroke-width:
#> 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter;
#> fill: #D8E6F5;' /><rect x='135.69' y='3.93' width='0.56'
#> height='18.75' style='stroke-width: 1.07; stroke: none;
#> stroke-linecap: butt; stroke-linejoin: miter; fill: #D8E6F5;' /><rect
#> x='135.12' y='3.93' width='0.56' height='18.75' style='stroke-width:
#> 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter;
#> fill: #D7E5F5;' /><rect x='134.56' y='3.93' width='0.56'
#> height='18.75' style='stroke-width: 1.07; stroke: none;
#> stroke-linecap: butt; stroke-linejoin: miter; fill: #D6E5F4;' /><rect
#> x='134.00' y='3.93' width='0.56' height='18.75' style='stroke-width:
#> 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter;
#> fill: #D6E4F4;' /><rect x='133.44' y='3.93' width='0.56'
#> height='18.75' style='stroke-width: 1.07; stroke: none;
#> stroke-linecap: butt; stroke-linejoin: miter; fill: #D5E4F4;' /><rect
#> x='132.88' y='3.93' width='0.56' height='18.75' style='stroke-width:
#> 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter;
#> fill: #D4E3F4;' /><rect x='132.32' y='3.93' width='0.56'
#> height='18.75' style='stroke-width: 1.07; stroke: none;
#> stroke-linecap: butt; stroke-linejoin: miter; fill: #D3E3F3;' /><rect
#> x='131.76' y='3.93' width='0.56' height='18.75' style='stroke-width:
#> 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter;
#> fill: #D3E2F3;' /><rect x='131.20' y='3.93' width='0.56'
#> height='18.75' style='stroke-width: 1.07; stroke: none;
#> stroke-linecap: butt; stroke-linejoin: miter; fill: #D2E2F3;' /><rect
#> x='130.63' y='3.93' width='0.56' height='18.75' style='stroke-width:
#> 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter;
#> fill: #D1E1F3;' /><rect x='130.07' y='3.93' width='0.56'
#> height='18.75' style='stroke-width: 1.07; stroke: none;
#> stroke-linecap: butt; stroke-linejoin: miter; fill: #D1E1F2;' /><rect
#> x='129.51' y='3.93' width='0.56' height='18.75' style='stroke-width:
#> 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter;
#> fill: #D0E0F2;' /><rect x='128.95' y='3.93' width='0.56'
#> height='18.75' style='stroke-width: 1.07; stroke: none;
#> stroke-linecap: butt; stroke-linejoin: miter; fill: #CFE0F2;' /><rect
#> x='128.39' y='3.93' width='0.56' height='18.75' style='stroke-width:
#> 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter;
#> fill: #CFDFF2;' /><rect x='127.83' y='3.93' width='0.56'
#> height='18.75' style='stroke-width: 1.07; stroke: none;
#> stroke-linecap: butt; stroke-linejoin: miter; fill: #CEDFF1;' /><rect
#> x='127.27' y='3.93' width='0.56' height='18.75' style='stroke-width:
#> 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter;
#> fill: #CDDEF1;' /><rect x='126.71' y='3.93' width='0.56'
#> height='18.75' style='stroke-width: 1.07; stroke: none;
#> stroke-linecap: butt; stroke-linejoin: miter; fill: #CDDEF1;' /><rect
#> x='126.14' y='3.93' width='0.56' height='18.75' style='stroke-width:
#> 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter;
#> fill: #CCDEF0;' /><rect x='125.58' y='3.93' width='0.56'
#> height='18.75' style='stroke-width: 1.07; stroke: none;
#> stroke-linecap: butt; stroke-linejoin: miter; fill: #CBDDF0;' /><rect
#> x='125.02' y='3.93' width='0.56' height='18.75' style='stroke-width:
#> 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter;
#> fill: #CBDDF0;' /><rect x='124.46' y='3.93' width='0.56'
#> height='18.75' style='stroke-width: 1.07; stroke: none;
#> stroke-linecap: butt; stroke-linejoin: miter; fill: #CADCF0;' /><rect
#> x='123.90' y='3.93' width='0.56' height='18.75' style='stroke-width:
#> 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter;
#> fill: #C9DCEF;' /><rect x='123.34' y='3.93' width='0.56'
#> height='18.75' style='stroke-width: 1.07; stroke: none;
#> stroke-linecap: butt; stroke-linejoin: miter; fill: #C9DBEF;' /><rect
#> x='122.78' y='3.93' width='0.56' height='18.75' style='stroke-width:
#> 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter;
#> fill: #C8DBEF;' /><rect x='122.22' y='3.93' width='0.56'
#> height='18.75' style='stroke-width: 1.07; stroke: none;
#> stroke-linecap: butt; stroke-linejoin: miter; fill: #C7DAEF;' /><rect
#> x='121.66' y='3.93' width='0.56' height='18.75' style='stroke-width:
#> 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter;
#> fill: #C7DAEE;' /><rect x='121.09' y='3.93' width='0.56'
#> height='18.75' style='stroke-width: 1.07; stroke: none;
#> stroke-linecap: butt; stroke-linejoin: miter; fill: #C6D9EE;' /><rect
#> x='120.53' y='3.93' width='0.56' height='18.75' style='stroke-width:
#> 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter;
#> fill: #C5D9EE;' /><rect x='119.97' y='3.93' width='0.56'
#> height='18.75' style='stroke-width: 1.07; stroke: none;
#> stroke-linecap: butt; stroke-linejoin: miter; fill: #C5D8EE;' /><rect
#> x='119.41' y='3.93' width='0.56' height='18.75' style='stroke-width:
#> 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter;
#> fill: #C4D8ED;' /><rect x='118.85' y='3.93' width='0.56'
#> height='18.75' style='stroke-width: 1.07; stroke: none;
#> stroke-linecap: butt; stroke-linejoin: miter; fill: #C3D7ED;' /><rect
#> x='118.29' y='3.93' width='0.56' height='18.75' style='stroke-width:
#> 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter;
#> fill: #C2D7ED;' /><rect x='117.73' y='3.93' width='0.56'
#> height='18.75' style='stroke-width: 1.07; stroke: none;
#> stroke-linecap: butt; stroke-linejoin: miter; fill: #C2D6ED;' /><rect
#> x='117.17' y='3.93' width='0.56' height='18.75' style='stroke-width:
#> 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter;
#> fill: #C1D6EC;' /><rect x='116.60' y='3.93' width='0.56'
#> height='18.75' style='stroke-width: 1.07; stroke: none;
#> stroke-linecap: butt; stroke-linejoin: miter; fill: #C0D5EC;' /><rect
#> x='116.04' y='3.93' width='0.56' height='18.75' style='stroke-width:
#> 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter;
#> fill: #C0D5EC;' /><rect x='115.48' y='3.93' width='0.56'
#> height='18.75' style='stroke-width: 1.07; stroke: none;
#> stroke-linecap: butt; stroke-linejoin: miter; fill: #BFD4EB;' /><rect
#> x='114.92' y='3.93' width='0.56' height='18.75' style='stroke-width:
#> 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter;
#> fill: #BED4EB;' /><rect x='114.36' y='3.93' width='0.56'
#> height='18.75' style='stroke-width: 1.07; stroke: none;
#> stroke-linecap: butt; stroke-linejoin: miter; fill: #BED3EB;' /><rect
#> x='113.80' y='3.93' width='0.56' height='18.75' style='stroke-width:
#> 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter;
#> fill: #BDD3EB;' /><rect x='113.24' y='3.93' width='0.56'
#> height='18.75' style='stroke-width: 1.07; stroke: none;
#> stroke-linecap: butt; stroke-linejoin: miter; fill: #BCD2EA;' /><rect
#> x='112.68' y='3.93' width='0.56' height='18.75' style='stroke-width:
#> 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter;
#> fill: #BCD2EA;' /><rect x='112.11' y='3.93' width='0.56'
#> height='18.75' style='stroke-width: 1.07; stroke: none;
#> stroke-linecap: butt; stroke-linejoin: miter; fill: #BBD1EA;' /><rect
#> x='111.55' y='3.93' width='0.56' height='18.75' style='stroke-width:
#> 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter;
#> fill: #BAD1EA;' /><rect x='110.99' y='3.93' width='0.56'
#> height='18.75' style='stroke-width: 1.07; stroke: none;
#> stroke-linecap: butt; stroke-linejoin: miter; fill: #BAD0E9;' /><rect
#> x='110.43' y='3.93' width='0.56' height='18.75' style='stroke-width:
#> 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter;
#> fill: #B9D0E9;' /><rect x='109.87' y='3.93' width='0.56'
#> height='18.75' style='stroke-width: 1.07; stroke: none;
#> stroke-linecap: butt; stroke-linejoin: miter; fill: #B8CFE9;' /><rect
#> x='109.31' y='3.93' width='0.56' height='18.75' style='stroke-width:
#> 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter;
#> fill: #B7CFE9;' /><rect x='108.75' y='3.93' width='0.56'
#> height='18.75' style='stroke-width: 1.07; stroke: none;
#> stroke-linecap: butt; stroke-linejoin: miter; fill: #B7CEE8;' /><rect
#> x='108.19' y='3.93' width='0.56' height='18.75' style='stroke-width:
#> 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter;
#> fill: #B6CEE8;' /><rect x='107.62' y='3.93' width='0.56'
#> height='18.75' style='stroke-width: 1.07; stroke: none;
#> stroke-linecap: butt; stroke-linejoin: miter; fill: #B5CDE8;' /><rect
#> x='107.06' y='3.93' width='0.56' height='18.75' style='stroke-width:
#> 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter;
#> fill: #B5CDE8;' /><rect x='106.50' y='3.93' width='0.56'
#> height='18.75' style='stroke-width: 1.07; stroke: none;
#> stroke-linecap: butt; stroke-linejoin: miter; fill: #B4CCE7;' /><rect
#> x='105.94' y='3.93' width='0.56' height='18.75' style='stroke-width:
#> 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter;
#> fill: #B3CCE7;' /><rect x='105.38' y='3.93' width='0.56'
#> height='18.75' style='stroke-width: 1.07; stroke: none;
#> stroke-linecap: butt; stroke-linejoin: miter; fill: #B3CBE7;' /><rect
#> x='104.82' y='3.93' width='0.56' height='18.75' style='stroke-width:
#> 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter;
#> fill: #B2CBE7;' /><rect x='104.26' y='3.93' width='0.56'
#> height='18.75' style='stroke-width: 1.07; stroke: none;
#> stroke-linecap: butt; stroke-linejoin: miter; fill: #B1CAE6;' /><rect
#> x='103.70' y='3.93' width='0.56' height='18.75' style='stroke-width:
#> 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter;
#> fill: #B1CAE6;' /><rect x='103.14' y='3.93' width='0.56'
#> height='18.75' style='stroke-width: 1.07; stroke: none;
#> stroke-linecap: butt; stroke-linejoin: miter; fill: #B0C9E6;' /><rect
#> x='102.57' y='3.93' width='0.56' height='18.75' style='stroke-width:
#> 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter;
#> fill: #AFC9E5;' /><rect x='102.01' y='3.93' width='0.56'
#> height='18.75' style='stroke-width: 1.07; stroke: none;
#> stroke-linecap: butt; stroke-linejoin: miter; fill: #AFC8E5;' /><rect
#> x='101.45' y='3.93' width='0.56' height='18.75' style='stroke-width:
#> 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter;
#> fill: #AEC8E5;' /><rect x='100.89' y='3.93' width='0.56'
#> height='18.75' style='stroke-width: 1.07; stroke: none;
#> stroke-linecap: butt; stroke-linejoin: miter; fill: #ADC7E5;' /><rect
#> x='100.33' y='3.93' width='0.56' height='18.75' style='stroke-width:
#> 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter;
#> fill: #ACC7E4;' /><rect x='99.77' y='3.93' width='0.56' height='18.75'
#> style='stroke-width: 1.07; stroke: none; stroke-linecap: butt;
#> stroke-linejoin: miter; fill: #ACC6E4;' /><rect x='99.21' y='3.93'
#> width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none;
#> stroke-linecap: butt; stroke-linejoin: miter; fill: #ABC6E4;' /><rect
#> x='98.65' y='3.93' width='0.56' height='18.75' style='stroke-width:
#> 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter;
#> fill: #AAC5E4;' /><rect x='98.08' y='3.93' width='0.56' height='18.75'
#> style='stroke-width: 1.07; stroke: none; stroke-linecap: butt;
#> stroke-linejoin: miter; fill: #AAC5E3;' /><rect x='97.52' y='3.93'
#> width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none;
#> stroke-linecap: butt; stroke-linejoin: miter; fill: #A9C4E3;' /><rect
#> x='96.96' y='3.93' width='0.56' height='18.75' style='stroke-width:
#> 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter;
#> fill: #A8C4E3;' /><rect x='96.40' y='3.93' width='0.56' height='18.75'
#> style='stroke-width: 1.07; stroke: none; stroke-linecap: butt;
#> stroke-linejoin: miter; fill: #A8C3E3;' /><rect x='95.84' y='3.93'
#> width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none;
#> stroke-linecap: butt; stroke-linejoin: miter; fill: #A7C3E2;' /><rect
#> x='95.28' y='3.93' width='0.56' height='18.75' style='stroke-width:
#> 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter;
#> fill: #A6C3E2;' /><rect x='94.72' y='3.93' width='0.56' height='18.75'
#> style='stroke-width: 1.07; stroke: none; stroke-linecap: butt;
#> stroke-linejoin: miter; fill: #A5C2E2;' /><rect x='94.16' y='3.93'
#> width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none;
#> stroke-linecap: butt; stroke-linejoin: miter; fill: #A5C2E2;' /><rect
#> x='93.59' y='3.93' width='0.56' height='18.75' style='stroke-width:
#> 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter;
#> fill: #A4C1E1;' /><rect x='93.03' y='3.93' width='0.56' height='18.75'
#> style='stroke-width: 1.07; stroke: none; stroke-linecap: butt;
#> stroke-linejoin: miter; fill: #A3C1E1;' /><rect x='92.47' y='3.93'
#> width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none;
#> stroke-linecap: butt; stroke-linejoin: miter; fill: #A3C0E1;' /><rect
#> x='91.91' y='3.93' width='0.56' height='18.75' style='stroke-width:
#> 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter;
#> fill: #A2C0E0;' /><rect x='91.35' y='3.93' width='0.56' height='18.75'
#> style='stroke-width: 1.07; stroke: none; stroke-linecap: butt;
#> stroke-linejoin: miter; fill: #A1BFE0;' /><rect x='90.79' y='3.93'
#> width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none;
#> stroke-linecap: butt; stroke-linejoin: miter; fill: #A1BFE0;' /><rect
#> x='90.23' y='3.93' width='0.56' height='18.75' style='stroke-width:
#> 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter;
#> fill: #A0BEE0;' /><rect x='89.67' y='3.93' width='0.56' height='18.75'
#> style='stroke-width: 1.07; stroke: none; stroke-linecap: butt;
#> stroke-linejoin: miter; fill: #9FBEDF;' /><rect x='89.11' y='3.93'
#> width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none;
#> stroke-linecap: butt; stroke-linejoin: miter; fill: #9EBDDF;' /><rect
#> x='88.54' y='3.93' width='0.56' height='18.75' style='stroke-width:
#> 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter;
#> fill: #9EBDDF;' /><rect x='87.98' y='3.93' width='0.56' height='18.75'
#> style='stroke-width: 1.07; stroke: none; stroke-linecap: butt;
#> stroke-linejoin: miter; fill: #9DBCDF;' /><rect x='87.42' y='3.93'
#> width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none;
#> stroke-linecap: butt; stroke-linejoin: miter; fill: #9CBCDE;' /><rect
#> x='86.86' y='3.93' width='0.56' height='18.75' style='stroke-width:
#> 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter;
#> fill: #9CBBDE;' /><rect x='86.30' y='3.93' width='0.56' height='18.75'
#> style='stroke-width: 1.07; stroke: none; stroke-linecap: butt;
#> stroke-linejoin: miter; fill: #9BBBDE;' /><rect x='85.74' y='3.93'
#> width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none;
#> stroke-linecap: butt; stroke-linejoin: miter; fill: #9ABADE;' /><rect
#> x='85.18' y='3.93' width='0.56' height='18.75' style='stroke-width:
#> 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter;
#> fill: #9ABADD;' /><rect x='84.62' y='3.93' width='0.56' height='18.75'
#> style='stroke-width: 1.07; stroke: none; stroke-linecap: butt;
#> stroke-linejoin: miter; fill: #99B9DD;' /><rect x='84.05' y='3.93'
#> width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none;
#> stroke-linecap: butt; stroke-linejoin: miter; fill: #98B9DD;' /><rect
#> x='83.49' y='3.93' width='0.56' height='18.75' style='stroke-width:
#> 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter;
#> fill: #97B8DD;' /><rect x='82.93' y='3.93' width='0.56' height='18.75'
#> style='stroke-width: 1.07; stroke: none; stroke-linecap: butt;
#> stroke-linejoin: miter; fill: #97B8DC;' /><rect x='82.37' y='3.93'
#> width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none;
#> stroke-linecap: butt; stroke-linejoin: miter; fill: #96B7DC;' /><rect
#> x='81.81' y='3.93' width='0.56' height='18.75' style='stroke-width:
#> 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter;
#> fill: #95B7DC;' /><rect x='81.25' y='3.93' width='0.56' height='18.75'
#> style='stroke-width: 1.07; stroke: none; stroke-linecap: butt;
#> stroke-linejoin: miter; fill: #95B6DB;' /><rect x='80.69' y='3.93'
#> width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none;
#> stroke-linecap: butt; stroke-linejoin: miter; fill: #94B6DB;' /><rect
#> x='80.13' y='3.93' width='0.56' height='18.75' style='stroke-width:
#> 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter;
#> fill: #93B6DB;' /><rect x='79.56' y='3.93' width='0.56' height='18.75'
#> style='stroke-width: 1.07; stroke: none; stroke-linecap: butt;
#> stroke-linejoin: miter; fill: #92B5DB;' /><rect x='79.00' y='3.93'
#> width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none;
#> stroke-linecap: butt; stroke-linejoin: miter; fill: #92B5DA;' /><rect
#> x='78.44' y='3.93' width='0.56' height='18.75' style='stroke-width:
#> 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter;
#> fill: #91B4DA;' /><rect x='77.88' y='3.93' width='0.56' height='18.75'
#> style='stroke-width: 1.07; stroke: none; stroke-linecap: butt;
#> stroke-linejoin: miter; fill: #90B4DA;' /><rect x='77.32' y='3.93'
#> width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none;
#> stroke-linecap: butt; stroke-linejoin: miter; fill: #90B3DA;' /><rect
#> x='76.76' y='3.93' width='0.56' height='18.75' style='stroke-width:
#> 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter;
#> fill: #8FB3D9;' /><rect x='76.20' y='3.93' width='0.56' height='18.75'
#> style='stroke-width: 1.07; stroke: none; stroke-linecap: butt;
#> stroke-linejoin: miter; fill: #8EB2D9;' /><rect x='75.64' y='3.93'
#> width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none;
#> stroke-linecap: butt; stroke-linejoin: miter; fill: #8DB2D9;' /><rect
#> x='75.08' y='3.93' width='0.56' height='18.75' style='stroke-width:
#> 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter;
#> fill: #8DB1D9;' /><rect x='74.51' y='3.93' width='0.56' height='18.75'
#> style='stroke-width: 1.07; stroke: none; stroke-linecap: butt;
#> stroke-linejoin: miter; fill: #8CB1D8;' /><rect x='73.95' y='3.93'
#> width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none;
#> stroke-linecap: butt; stroke-linejoin: miter; fill: #8BB0D8;' /><rect
#> x='73.39' y='3.93' width='0.56' height='18.75' style='stroke-width:
#> 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter;
#> fill: #8AB0D8;' /><rect x='72.83' y='3.93' width='0.56' height='18.75'
#> style='stroke-width: 1.07; stroke: none; stroke-linecap: butt;
#> stroke-linejoin: miter; fill: #8AAFD8;' /><rect x='72.27' y='3.93'
#> width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none;
#> stroke-linecap: butt; stroke-linejoin: miter; fill: #89AFD7;' /><rect
#> x='71.71' y='3.93' width='0.56' height='18.75' style='stroke-width:
#> 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter;
#> fill: #88AED7;' /><rect x='71.15' y='3.93' width='0.56' height='18.75'
#> style='stroke-width: 1.07; stroke: none; stroke-linecap: butt;
#> stroke-linejoin: miter; fill: #88AED7;' /><rect x='70.59' y='3.93'
#> width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none;
#> stroke-linecap: butt; stroke-linejoin: miter; fill: #87ADD6;' /><rect
#> x='70.02' y='3.93' width='0.56' height='18.75' style='stroke-width:
#> 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter;
#> fill: #86ADD6;' /><rect x='69.46' y='3.93' width='0.56' height='18.75'
#> style='stroke-width: 1.07; stroke: none; stroke-linecap: butt;
#> stroke-linejoin: miter; fill: #85ADD6;' /><rect x='68.90' y='3.93'
#> width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none;
#> stroke-linecap: butt; stroke-linejoin: miter; fill: #85ACD6;' /><rect
#> x='68.34' y='3.93' width='0.56' height='18.75' style='stroke-width:
#> 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter;
#> fill: #84ACD5;' /><rect x='67.78' y='3.93' width='0.56' height='18.75'
#> style='stroke-width: 1.07; stroke: none; stroke-linecap: butt;
#> stroke-linejoin: miter; fill: #83ABD5;' /><rect x='67.22' y='3.93'
#> width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none;
#> stroke-linecap: butt; stroke-linejoin: miter; fill: #82ABD5;' /><rect
#> x='66.66' y='3.93' width='0.56' height='18.75' style='stroke-width:
#> 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter;
#> fill: #82AAD5;' /><rect x='66.10' y='3.93' width='0.56' height='18.75'
#> style='stroke-width: 1.07; stroke: none; stroke-linecap: butt;
#> stroke-linejoin: miter; fill: #81AAD4;' /><rect x='65.53' y='3.93'
#> width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none;
#> stroke-linecap: butt; stroke-linejoin: miter; fill: #80A9D4;' /><rect
#> x='64.97' y='3.93' width='0.56' height='18.75' style='stroke-width:
#> 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter;
#> fill: #7FA9D4;' /><rect x='64.41' y='3.93' width='0.56' height='18.75'
#> style='stroke-width: 1.07; stroke: none; stroke-linecap: butt;
#> stroke-linejoin: miter; fill: #7FA8D4;' /><rect x='63.85' y='3.93'
#> width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none;
#> stroke-linecap: butt; stroke-linejoin: miter; fill: #7EA8D3;' /><rect
#> x='63.29' y='3.93' width='0.56' height='18.75' style='stroke-width:
#> 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter;
#> fill: #7DA7D3;' /><rect x='62.73' y='3.93' width='0.56' height='18.75'
#> style='stroke-width: 1.07; stroke: none; stroke-linecap: butt;
#> stroke-linejoin: miter; fill: #7CA7D3;' /><rect x='62.17' y='3.93'
#> width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none;
#> stroke-linecap: butt; stroke-linejoin: miter; fill: #7CA6D3;' /><rect
#> x='61.61' y='3.93' width='0.56' height='18.75' style='stroke-width:
#> 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter;
#> fill: #7BA6D2;' /><rect x='61.05' y='3.93' width='0.56' height='18.75'
#> style='stroke-width: 1.07; stroke: none; stroke-linecap: butt;
#> stroke-linejoin: miter; fill: #7AA5D2;' /><rect x='60.48' y='3.93'
#> width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none;
#> stroke-linecap: butt; stroke-linejoin: miter; fill: #79A5D2;' /><rect
#> x='59.92' y='3.93' width='0.56' height='18.75' style='stroke-width:
#> 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter;
#> fill: #79A5D2;' /><rect x='59.36' y='3.93' width='0.56' height='18.75'
#> style='stroke-width: 1.07; stroke: none; stroke-linecap: butt;
#> stroke-linejoin: miter; fill: #78A4D1;' /><rect x='58.80' y='3.93'
#> width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none;
#> stroke-linecap: butt; stroke-linejoin: miter; fill: #77A4D1;' /><rect
#> x='58.24' y='3.93' width='0.56' height='18.75' style='stroke-width:
#> 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter;
#> fill: #76A3D1;' /><rect x='57.68' y='3.93' width='0.56' height='18.75'
#> style='stroke-width: 1.07; stroke: none; stroke-linecap: butt;
#> stroke-linejoin: miter; fill: #76A3D0;' /><rect x='57.12' y='3.93'
#> width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none;
#> stroke-linecap: butt; stroke-linejoin: miter; fill: #75A2D0;' /><rect
#> x='56.56' y='3.93' width='0.56' height='18.75' style='stroke-width:
#> 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter;
#> fill: #74A2D0;' /><rect x='55.99' y='3.93' width='0.56' height='18.75'
#> style='stroke-width: 1.07; stroke: none; stroke-linecap: butt;
#> stroke-linejoin: miter; fill: #73A1D0;' /><rect x='55.43' y='3.93'
#> width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none;
#> stroke-linecap: butt; stroke-linejoin: miter; fill: #73A1CF;' /><rect
#> x='54.87' y='3.93' width='0.56' height='18.75' style='stroke-width:
#> 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter;
#> fill: #72A0CF;' /><rect x='54.31' y='3.93' width='0.56' height='18.75'
#> style='stroke-width: 1.07; stroke: none; stroke-linecap: butt;
#> stroke-linejoin: miter; fill: #71A0CF;' /><rect x='53.75' y='3.93'
#> width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none;
#> stroke-linecap: butt; stroke-linejoin: miter; fill: #709FCF;' /><rect
#> x='53.19' y='3.93' width='0.56' height='18.75' style='stroke-width:
#> 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter;
#> fill: #6F9FCE;' /><rect x='52.63' y='3.93' width='0.56' height='18.75'
#> style='stroke-width: 1.07; stroke: none; stroke-linecap: butt;
#> stroke-linejoin: miter; fill: #6F9ECE;' /><rect x='52.07' y='3.93'
#> width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none;
#> stroke-linecap: butt; stroke-linejoin: miter; fill: #6E9ECE;' /><rect
#> x='51.50' y='3.93' width='0.56' height='18.75' style='stroke-width:
#> 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter;
#> fill: #6D9ECE;' /><rect x='50.94' y='3.93' width='0.56' height='18.75'
#> style='stroke-width: 1.07; stroke: none; stroke-linecap: butt;
#> stroke-linejoin: miter; fill: #6C9DCD;' /><rect x='50.38' y='3.93'
#> width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none;
#> stroke-linecap: butt; stroke-linejoin: miter; fill: #6B9DCD;' /><rect
#> x='49.82' y='3.93' width='0.56' height='18.75' style='stroke-width:
#> 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter;
#> fill: #6B9CCD;' /><rect x='49.26' y='3.93' width='0.56' height='18.75'
#> style='stroke-width: 1.07; stroke: none; stroke-linecap: butt;
#> stroke-linejoin: miter; fill: #6A9CCD;' /><rect x='48.70' y='3.93'
#> width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none;
#> stroke-linecap: butt; stroke-linejoin: miter; fill: #699BCC;' /><rect
#> x='48.14' y='3.93' width='0.56' height='18.75' style='stroke-width:
#> 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter;
#> fill: #689BCC;' /><rect x='47.58' y='3.93' width='0.56' height='18.75'
#> style='stroke-width: 1.07; stroke: none; stroke-linecap: butt;
#> stroke-linejoin: miter; fill: #679ACC;' /><rect x='47.01' y='3.93'
#> width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none;
#> stroke-linecap: butt; stroke-linejoin: miter; fill: #679ACB;' /><rect
#> x='46.45' y='3.93' width='0.56' height='18.75' style='stroke-width:
#> 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter;
#> fill: #6699CB;' /><rect x='45.89' y='3.93' width='0.56' height='18.75'
#> style='stroke-width: 1.07; stroke: none; stroke-linecap: butt;
#> stroke-linejoin: miter; fill: #6599CB;' /><rect x='45.33' y='3.93'
#> width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none;
#> stroke-linecap: butt; stroke-linejoin: miter; fill: #6498CB;' /><rect
#> x='44.77' y='3.93' width='0.56' height='18.75' style='stroke-width:
#> 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter;
#> fill: #6398CA;' /><rect x='44.21' y='3.93' width='0.56' height='18.75'
#> style='stroke-width: 1.07; stroke: none; stroke-linecap: butt;
#> stroke-linejoin: miter; fill: #6398CA;' /><rect x='43.65' y='3.93'
#> width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none;
#> stroke-linecap: butt; stroke-linejoin: miter; fill: #6297CA;' /><rect
#> x='43.09' y='3.93' width='0.56' height='18.75' style='stroke-width:
#> 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter;
#> fill: #6197CA;' /><rect x='42.53' y='3.93' width='0.56' height='18.75'
#> style='stroke-width: 1.07; stroke: none; stroke-linecap: butt;
#> stroke-linejoin: miter; fill: #6096C9;' /><rect x='41.96' y='3.93'
#> width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none;
#> stroke-linecap: butt; stroke-linejoin: miter; fill: #5F96C9;' /><rect
#> x='41.40' y='3.93' width='0.56' height='18.75' style='stroke-width:
#> 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter;
#> fill: #5E95C9;' /><rect x='40.84' y='3.93' width='0.56' height='18.75'
#> style='stroke-width: 1.07; stroke: none; stroke-linecap: butt;
#> stroke-linejoin: miter; fill: #5E95C9;' /><rect x='40.28' y='3.93'
#> width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none;
#> stroke-linecap: butt; stroke-linejoin: miter; fill: #5D94C8;' /><rect
#> x='39.72' y='3.93' width='0.56' height='18.75' style='stroke-width:
#> 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter;
#> fill: #5C94C8;' /><rect x='39.16' y='3.93' width='0.56' height='18.75'
#> style='stroke-width: 1.07; stroke: none; stroke-linecap: butt;
#> stroke-linejoin: miter; fill: #5B93C8;' /><rect x='38.60' y='3.93'
#> width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none;
#> stroke-linecap: butt; stroke-linejoin: miter; fill: #5A93C8;' /><rect
#> x='38.04' y='3.93' width='0.56' height='18.75' style='stroke-width:
#> 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter;
#> fill: #5993C7;' /><rect x='37.47' y='3.93' width='0.56' height='18.75'
#> style='stroke-width: 1.07; stroke: none; stroke-linecap: butt;
#> stroke-linejoin: miter; fill: #5892C7;' /><rect x='36.91' y='3.93'
#> width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none;
#> stroke-linecap: butt; stroke-linejoin: miter; fill: #5792C7;' /><rect
#> x='36.35' y='3.93' width='0.56' height='18.75' style='stroke-width:
#> 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter;
#> fill: #5791C6;' /><rect x='35.79' y='3.93' width='0.56' height='18.75'
#> style='stroke-width: 1.07; stroke: none; stroke-linecap: butt;
#> stroke-linejoin: miter; fill: #5691C6;' /><rect x='35.23' y='3.93'
#> width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none;
#> stroke-linecap: butt; stroke-linejoin: miter; fill: #5590C6;' /><rect
#> x='34.67' y='3.93' width='0.56' height='18.75' style='stroke-width:
#> 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter;
#> fill: #5490C6;' /><rect x='34.11' y='3.93' width='0.56' height='18.75'
#> style='stroke-width: 1.07; stroke: none; stroke-linecap: butt;
#> stroke-linejoin: miter; fill: #538FC5;' /><rect x='33.55' y='3.93'
#> width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none;
#> stroke-linecap: butt; stroke-linejoin: miter; fill: #528FC5;' /><rect
#> x='32.98' y='3.93' width='0.56' height='18.75' style='stroke-width:
#> 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter;
#> fill: #518EC5;' /><rect x='32.42' y='3.93' width='0.56' height='18.75'
#> style='stroke-width: 1.07; stroke: none; stroke-linecap: butt;
#> stroke-linejoin: miter; fill: #508EC5;' /><rect x='31.86' y='3.93'
#> width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none;
#> stroke-linecap: butt; stroke-linejoin: miter; fill: #4F8EC4;' /><rect
#> x='31.30' y='3.93' width='0.56' height='18.75' style='stroke-width:
#> 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter;
#> fill: #4E8DC4;' /><rect x='30.74' y='3.93' width='0.56' height='18.75'
#> style='stroke-width: 1.07; stroke: none; stroke-linecap: butt;
#> stroke-linejoin: miter; fill: #4D8DC4;' /><rect x='30.18' y='3.93'
#> width='0.56' height='18.75' style='stroke-width: 1.07; stroke: none;
#> stroke-linecap: butt; stroke-linejoin: miter; fill: #4C8CC4;' /><rect
#> x='29.06' y='3.93' width='1.12' height='18.75' style='stroke-width:
#> 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter;
#> fill: #4C8CC3;' /><rect x='27.93' y='3.93' width='1.12' height='18.75'
#> style='stroke-width: 1.07; stroke: none; stroke-linecap: butt;
#> stroke-linejoin: miter; fill: #4B8BC3;' /><rect x='26.81' y='3.93'
#> width='1.12' height='18.75' style='stroke-width: 1.07; stroke: none;
#> stroke-linecap: butt; stroke-linejoin: miter; fill: #4A8BC3;' /><rect
#> x='25.69' y='3.93' width='1.12' height='18.75' style='stroke-width:
#> 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter;
#> fill: #498AC3;' /><rect x='24.57' y='3.93' width='1.12' height='18.75'
#> style='stroke-width: 1.07; stroke: none; stroke-linecap: butt;
#> stroke-linejoin: miter; fill: #488AC2;' /><rect x='23.44' y='3.93'
#> width='1.12' height='18.75' style='stroke-width: 1.07; stroke: none;
#> stroke-linecap: butt; stroke-linejoin: miter; fill: #4789C2;' /><rect
#> x='22.32' y='3.93' width='1.12' height='18.75' style='stroke-width:
#> 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter;
#> fill: #4689C2;' /><rect x='21.20' y='3.93' width='1.12' height='18.75'
#> style='stroke-width: 1.07; stroke: none; stroke-linecap: butt;
#> stroke-linejoin: miter; fill: #4589C1;' /><rect x='20.08' y='3.93'
#> width='1.12' height='18.75' style='stroke-width: 1.07; stroke: none;
#> stroke-linecap: butt; stroke-linejoin: miter; fill: #4488C1;' /><rect
#> x='18.95' y='3.93' width='1.12' height='18.75' style='stroke-width:
#> 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter;
#> fill: #4388C1;' /><rect x='17.83' y='3.93' width='1.12' height='18.75'
#> style='stroke-width: 1.07; stroke: none; stroke-linecap: butt;
#> stroke-linejoin: miter; fill: #4187C1;' /><rect x='16.71' y='3.93'
#> width='1.12' height='18.75' style='stroke-width: 1.07; stroke: none;
#> stroke-linecap: butt; stroke-linejoin: miter; fill: #4087C0;' /><rect
#> x='15.59' y='3.93' width='1.12' height='18.75' style='stroke-width:
#> 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter;
#> fill: #3F86C0;' /><rect x='14.47' y='3.93' width='1.12' height='18.75'
#> style='stroke-width: 1.07; stroke: none; stroke-linecap: butt;
#> stroke-linejoin: miter; fill: #3E86C0;' /><rect x='13.34' y='3.93'
#> width='1.12' height='18.75' style='stroke-width: 1.07; stroke: none;
#> stroke-linecap: butt; stroke-linejoin: miter; fill: #3D85C0;' /><rect
#> x='12.22' y='3.93' width='1.12' height='18.75' style='stroke-width:
#> 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter;
#> fill: #3C85BF;' /><rect x='11.10' y='3.93' width='1.12' height='18.75'
#> style='stroke-width: 1.07; stroke: none; stroke-linecap: butt;
#> stroke-linejoin: miter; fill: #3B85BF;' /><rect x='9.98' y='3.93'
#> width='1.12' height='18.75' style='stroke-width: 1.07; stroke: none;
#> stroke-linecap: butt; stroke-linejoin: miter; fill: #3A84BF;' /><rect
#> x='8.85' y='3.93' width='1.12' height='18.75' style='stroke-width:
#> 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter;
#> fill: #3984BF;' /><rect x='7.73' y='3.93' width='1.12' height='18.75'
#> style='stroke-width: 1.07; stroke: none; stroke-linecap: butt;
#> stroke-linejoin: miter; fill: #3783BE;' /><rect x='6.61' y='3.93'
#> width='1.12' height='18.75' style='stroke-width: 1.07; stroke: none;
#> stroke-linecap: butt; stroke-linejoin: miter; fill: #3683BE;' /><rect
#> x='5.49' y='3.93' width='1.12' height='18.75' style='stroke-width:
#> 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter;
#> fill: #3582BE;' /><rect x='4.36' y='3.93' width='1.12' height='18.75'
#> style='stroke-width: 1.07; stroke: none; stroke-linecap: butt;
#> stroke-linejoin: miter; fill: #3482BE;' /><rect x='2.68' y='3.93'
#> width='1.68' height='18.75' style='stroke-width: 1.07; stroke: none;
#> stroke-linecap: butt; stroke-linejoin: miter; fill: #3281BD;' /><rect
#> x='1.00' y='3.93' width='1.68' height='18.75' style='stroke-width:
#> 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter;
#> fill: #3181BD;' /><g
#> clip-path='url(#cpMC4wMHwxNDEuNzN8MC4wMHwzNC4wMg==)'><text x='1.00'
#> y='30.18' style='font-size: 8.00px; font-family: "Arial";'
#> textLength='52.52px' lengthAdjust='spacingAndGlyphs'>222 categories
#> <td headers="n_missing" class="gt_row gt_right gt_striped">0.4%Logical Relationship Checks
# Cross-tabulation to check logical relationships
crosstable(
data = histopathology,
vars = "Death",
group = "Mortality5yr"
)
#>
#> CROSS TABLE
#>
#> character(0)
#>
#> character(0)
#>
#> <div class="figure" id="tbl3">
#> #tbl3 body .figbody {
#> font-family: Corbel, "Lucida Grande", "Lucida Sans Unicode", "Lucida
#> Sans", "DejaVu Sans", "Bitstream Vera Sans", "Liberation Sans",
#> Verdana, "Verdana Ref", sans-serif;
#> font-size: 66%;
#> -webkit-print-color-adjust: exact;
#> }
#>
#> #tbl3 .figure { margin-left: auto;
#> margin-right: auto;
#> }
#> #tbl3 .caption { text-align: left;
#> text-indent: 2em;
#> padding: 0.5em 0 0.5em 0;
#> font-weight: bold;
#> background-color: #f7f4ef !important;
#> border: 1px solid black;
#> }
#>
#> #tbl3 .figbody {
#> text-align: center;
#> border: 1px solid black
#> }
#>
#> #tbl3 .figbody table {
#> margin: 0;
#> width: 100%;
#> }
#>
#> #tbl3 .figbody td {
#> padding: 0.2em 0.5em 0.2em 0.5em;
#> }
#>
#> #tbl3 .figbody thead tr td
#> {
#> font-weight: bold;
#> }
#>
#> #tbl3 .figbody tbody tr:nth-child(odd) {background: #fffbed
#> !important;}
#>
#> #tbl3 .header td {text-align: center;}
#>
#> #tbl3 .subheader { font-size: smaller; }
#> #tbl3 .subheader td { text-align: center; /* border-bottom: 1pt solid
#> black; */ }
#>
#> #tbl3 .subheader em {font-style: normal;}
#>
#> #tbl3 tbody .variable {
#> float: left;
#> text-align: left;
#> padding-left: 0.5em;
#> }
#>
#> #tbl3 .units {
#> float: right;
#> font-size: x-small;
#> text-align: right;
#> padding-left: 1em;
#> vertical-align: text-bottom; /* FIXME why doesn't this work */
#> }
#>
#> #tbl3 td .align{
#> display: inline-block;
#> margin: 0 auto;
#> }
#>
#> #tbl3 .nobr {
#> white-space: nowrap;
#> }
#> #tbl3 .supsub {
#> display: inline-block;
#> margin: -9em 0;
#> vertical-align: -0.55em;
#> line-height: 1.35em;
#> font-size: 70%;
#> text-align: left;
#> }
#>
#> #tbl3 .statistics {font-style: italic;}
#> #tbl3 .statistics {padding-right: 0.5em;}
#> <div class="caption">Cross Table for Dependent mortality5yr<div
#> class="figbody"><table class="tangram">
#> <th class="header even tg-label"><span class="variable"><th
#> class="header even tg-label"><span class="variable">N<th class="header
#> even tg-label"><span class="variable">Alive<th class="header even
#> tg-label"><span class="variable">Dead<th class="header even
#> tg-label"><span class="variable">Test Statistic<tr
#> class="subheaderrow"><th class="subheader header even tg-label"><span
#> class="variable"><th class="subheader header even tg-label"><span
#> class="variable"><th class="subheader header even data N"><span
#> class="N">(N=80)<th class="subheader header even data N"><span
#> class="N">(N=169)<th class="subheader header even tg-label"><span
#> class="variable">
#> <td class="header odd tg-label"><span class="variable">Death :
#> YANLIŞ<td class="odd data N"><span class="N">249<td class="odd">1.0
#> <span class="fraction"><span class="numerator">80/<span
#> class="denominator">80<td class="odd">0.0 <span
#> class="fraction"><span class="numerator"> 0/<span
#> class="denominator">169<td class="statistics odd">Χ<span
#> class="supsub">2<br/>1=249.00, P<0.012
#> <div class="footnote">N is the number of non-missing value.
#> 1Kruskal-Wallis. 2Pearson. 3Wilcoxon.
# Outcome consistency check
crosstable(
data = histopathology,
vars = "Outcome",
group = "Death"
)
#>
#> CROSS TABLE
#>
#> character(0)
#>
#> character(0)
#>
#> <div class="figure" id="tbl3">
#> #tbl3 body .figbody {
#> font-family: Corbel, "Lucida Grande", "Lucida Sans Unicode", "Lucida
#> Sans", "DejaVu Sans", "Bitstream Vera Sans", "Liberation Sans",
#> Verdana, "Verdana Ref", sans-serif;
#> font-size: 66%;
#> -webkit-print-color-adjust: exact;
#> }
#>
#> #tbl3 .figure { margin-left: auto;
#> margin-right: auto;
#> }
#> #tbl3 .caption { text-align: left;
#> text-indent: 2em;
#> padding: 0.5em 0 0.5em 0;
#> font-weight: bold;
#> background-color: #f7f4ef !important;
#> border: 1px solid black;
#> }
#>
#> #tbl3 .figbody {
#> text-align: center;
#> border: 1px solid black
#> }
#>
#> #tbl3 .figbody table {
#> margin: 0;
#> width: 100%;
#> }
#>
#> #tbl3 .figbody td {
#> padding: 0.2em 0.5em 0.2em 0.5em;
#> }
#>
#> #tbl3 .figbody thead tr td
#> {
#> font-weight: bold;
#> }
#>
#> #tbl3 .figbody tbody tr:nth-child(odd) {background: #fffbed
#> !important;}
#>
#> #tbl3 .header td {text-align: center;}
#>
#> #tbl3 .subheader { font-size: smaller; }
#> #tbl3 .subheader td { text-align: center; /* border-bottom: 1pt solid
#> black; */ }
#>
#> #tbl3 .subheader em {font-style: normal;}
#>
#> #tbl3 tbody .variable {
#> float: left;
#> text-align: left;
#> padding-left: 0.5em;
#> }
#>
#> #tbl3 .units {
#> float: right;
#> font-size: x-small;
#> text-align: right;
#> padding-left: 1em;
#> vertical-align: text-bottom; /* FIXME why doesn't this work */
#> }
#>
#> #tbl3 td .align{
#> display: inline-block;
#> margin: 0 auto;
#> }
#>
#> #tbl3 .nobr {
#> white-space: nowrap;
#> }
#> #tbl3 .supsub {
#> display: inline-block;
#> margin: -9em 0;
#> vertical-align: -0.55em;
#> line-height: 1.35em;
#> font-size: 70%;
#> text-align: left;
#> }
#>
#> #tbl3 .statistics {font-style: italic;}
#> #tbl3 .statistics {padding-right: 0.5em;}
#> <div class="caption">Cross Table for Dependent death<div
#> class="figbody"><table class="tangram">
#> <th class="header even tg-label"><span class="variable"><th
#> class="header even tg-label"><span class="variable">N<th class="header
#> even tg-label"><span class="variable">DOĞRU<th class="header even
#> tg-label"><span class="variable">YANLIŞ<th class="header even
#> tg-label"><span class="variable">Test Statistic<tr
#> class="subheaderrow"><th class="subheader header even tg-label"><span
#> class="variable"><th class="subheader header even tg-label"><span
#> class="variable"><th class="subheader header even data N"><span
#> class="N">(N=169)<th class="subheader header even data N"><span
#> class="N">(N=80)<th class="subheader header even tg-label"><span
#> class="variable">
#> <td class="header odd tg-label"><span class="variable">Outcome<td
#> class="odd data N"><span class="N">249<td class="odd">1.0 1.0 1.0<td
#> class="odd">0.0 0.0 0.0<td class="statistics
#> odd">F1,247=1112389107960512256.00, P<0.013
#> <div class="footnote">N is the number of non-missing value.
#> 1Kruskal-Wallis. 2Pearson. 3Wilcoxon.Grade-Stage Relationship Assessment
# Check pathological grade vs stage relationships
crosstable(
data = histopathology,
vars = "Grade",
group = "TStage"
)
#>
#> CROSS TABLE
#>
#> character(0)
#>
#> character(0)
#>
#> <div class="figure" id="tbl3">
#> #tbl3 body .figbody {
#> font-family: Corbel, "Lucida Grande", "Lucida Sans Unicode", "Lucida
#> Sans", "DejaVu Sans", "Bitstream Vera Sans", "Liberation Sans",
#> Verdana, "Verdana Ref", sans-serif;
#> font-size: 66%;
#> -webkit-print-color-adjust: exact;
#> }
#>
#> #tbl3 .figure { margin-left: auto;
#> margin-right: auto;
#> }
#> #tbl3 .caption { text-align: left;
#> text-indent: 2em;
#> padding: 0.5em 0 0.5em 0;
#> font-weight: bold;
#> background-color: #f7f4ef !important;
#> border: 1px solid black;
#> }
#>
#> #tbl3 .figbody {
#> text-align: center;
#> border: 1px solid black
#> }
#>
#> #tbl3 .figbody table {
#> margin: 0;
#> width: 100%;
#> }
#>
#> #tbl3 .figbody td {
#> padding: 0.2em 0.5em 0.2em 0.5em;
#> }
#>
#> #tbl3 .figbody thead tr td
#> {
#> font-weight: bold;
#> }
#>
#> #tbl3 .figbody tbody tr:nth-child(odd) {background: #fffbed
#> !important;}
#>
#> #tbl3 .header td {text-align: center;}
#>
#> #tbl3 .subheader { font-size: smaller; }
#> #tbl3 .subheader td { text-align: center; /* border-bottom: 1pt solid
#> black; */ }
#>
#> #tbl3 .subheader em {font-style: normal;}
#>
#> #tbl3 tbody .variable {
#> float: left;
#> text-align: left;
#> padding-left: 0.5em;
#> }
#>
#> #tbl3 .units {
#> float: right;
#> font-size: x-small;
#> text-align: right;
#> padding-left: 1em;
#> vertical-align: text-bottom; /* FIXME why doesn't this work */
#> }
#>
#> #tbl3 td .align{
#> display: inline-block;
#> margin: 0 auto;
#> }
#>
#> #tbl3 .nobr {
#> white-space: nowrap;
#> }
#> #tbl3 .supsub {
#> display: inline-block;
#> margin: -9em 0;
#> vertical-align: -0.55em;
#> line-height: 1.35em;
#> font-size: 70%;
#> text-align: left;
#> }
#>
#> #tbl3 .statistics {font-style: italic;}
#> #tbl3 .statistics {padding-right: 0.5em;}
#> <div class="caption">Cross Table for Dependent t_stage<div
#> class="figbody"><table class="tangram">
#> <th class="header even tg-label"><span class="variable"><th
#> class="header even tg-label"><span class="variable">N<th class="header
#> even tg-label"><span class="variable">1<th class="header even
#> tg-label"><span class="variable">2<th class="header even
#> tg-label"><span class="variable">3<th class="header even
#> tg-label"><span class="variable">4<th class="header even
#> tg-label"><span class="variable">Test Statistic<tr
#> class="subheaderrow"><th class="subheader header even tg-label"><span
#> class="variable"><th class="subheader header even tg-label"><span
#> class="variable"><th class="subheader header even data N"><span
#> class="N">(N=24)<th class="subheader header even data N"><span
#> class="N">(N=51)<th class="subheader header even data N"><span
#> class="N">(N=63)<th class="subheader header even data N"><span
#> class="N">(N=111)<th class="subheader header even tg-label"><span
#> class="variable">
#> <td class="header odd tg-label"><span class="variable">Grade<td
#> class="odd data N"><span class="N">249<td class="odd">1.4 2.0 3.0<td
#> class="odd">1.0 2.0 3.0<td class="odd">1.0 2.0 3.0<td class="odd">1.0
#> 2.0 3.0<td class="statistics odd">F3,244=0.51, P=0.681
#> <div class="footnote">N is the number of non-missing value.
#> 1Kruskal-Wallis. 2Pearson. 3Wilcoxon.Phase 4: Benford’s Law Analysis
Benford’s law states that in naturally occurring datasets, the leading digit 1 appears about 30.1% of the time, digit 2 about 17.6%, and so on. Deviation from this pattern may indicate data fabrication.
Measurement A Analysis
# Benford's law analysis for Measurement A
benford(
data = histopathology,
var = "MeasurementA"
)
#>
#> BENFORD ANALYSIS
#>
#> See
#> <a href = 'https://github.com/carloscinelli/benford.analysis'>Package
#> documentation for interpratation.
#>
#> Benford object:
#>
#> Data: var
#> Number of observations used = 135
#> Number of obs. for second order = 134
#> First digits analysed = 2
#>
#> Mantissa:
#>
#> Statistic Value
#> Mean 0.506
#> Var 0.108
#> Ex.Kurtosis -1.514
#> Skewness -0.037
#>
#>
#> The 5 largest deviations:
#>
#> digits absolute.diff
#> 1 52 4.88
#> 2 17 4.65
#> 3 66 4.12
#> 4 13 3.66
#> 5 16 3.55
#>
#> Stats:
#>
#> Pearson's Chi-squared test
#>
#> data: var
#> X-squared = 137.97, df = 89, p-value = 0.0006808
#>
#>
#> Mantissa Arc Test
#>
#> data: var
#> L2 = 0.058715, df = 2, p-value = 0.000361
#>
#> Mean Absolute Deviation (MAD): 0.008005873
#> MAD Conformity - Nigrini (2012): Nonconformity
#> Distortion Factor: NaN
#>
#> Remember: Real data will never conform perfectly to Benford's Law. You should not focus on p-values! MeasurementA
#> <num>
#> 1: 0.0176978
#> 2: 1.7391655
#> 3: 0.5256537
#> 4: 1.7557878
#> 5: 0.5239132
#> 6: 0.1729459
#> 7: 0.1769035
#> 8: 0.5289038
#> 9: 0.5236107
#> 10: 1.7691411
#> 11: 0.5241260
#> 12: 0.5263020
#> 13: 1.7349714
#> 14: 0.1749262
#> $xlog
#> [1] FALSE
#>
#> $ylog
#> [1] FALSE
#>
#> $adj
#> [1] 0.5
#>
#> $ann
#> [1] TRUE
#>
#> $ask
#> [1] FALSE
#>
#> $bg
#> [1] "transparent"
#>
#> $bty
#> [1] "o"
#>
#> $cex
#> [1] 0.66
#>
#> $cex.axis
#> [1] 1
#>
#> $cex.lab
#> [1] 1
#>
#> $cex.main
#> [1] 1.2
#>
#> $cex.sub
#> [1] 1
#>
#> $col
#> [1] "black"
#>
#> $col.axis
#> [1] "black"
#>
#> $col.lab
#> [1] "black"
#>
#> $col.main
#> [1] "black"
#>
#> $col.sub
#> [1] "black"
#>
#> $crt
#> [1] 0
#>
#> $err
#> [1] 0
#>
#> $family
#> [1] ""
#>
#> $fg
#> [1] "black"
#>
#> $fig
#> [1] 0.6666667 1.0000000 0.0000000 0.5000000
#>
#> $fin
#> [1] 8 6
#>
#> $font
#> [1] 1
#>
#> $font.axis
#> [1] 1
#>
#> $font.lab
#> [1] 1
#>
#> $font.main
#> [1] 2
#>
#> $font.sub
#> [1] 1
#>
#> $lab
#> [1] 5 5 7
#>
#> $las
#> [1] 0
#>
#> $lend
#> [1] "round"
#>
#> $lheight
#> [1] 1
#>
#> $ljoin
#> [1] "round"
#>
#> $lmitre
#> [1] 10
#>
#> $lty
#> [1] "solid"
#>
#> $lwd
#> [1] 1
#>
#> $mai
#> [1] 1.02 0.82 0.82 0.42
#>
#> $mar
#> [1] 5.1 4.1 4.1 2.1
#>
#> $mex
#> [1] 1
#>
#> $mfcol
#> [1] 1 1
#>
#> $mfg
#> [1] 1 1 1 1
#>
#> $mfrow
#> [1] 1 1
#>
#> $mgp
#> [1] 3 1 0
#>
#> $mkh
#> [1] 0.001
#>
#> $new
#> [1] TRUE
#>
#> $oma
#> [1] 0 0 0 0
#>
#> $omd
#> [1] 0 1 0 1
#>
#> $omi
#> [1] 0 0 0 0
#>
#> $pch
#> [1] 1
#>
#> $pin
#> [1] 6.76 4.16
#>
#> $plt
#> [1] 0.0775000 0.9225000 0.1533333 0.8466667
#>
#> $ps
#> [1] 12
#>
#> $pty
#> [1] "m"
#>
#> $smo
#> [1] 1
#>
#> $srt
#> [1] 0
#>
#> $tck
#> [1] NA
#>
#> $tcl
#> [1] -0.5
#>
#> $usr
#> [1] 0.568 1.432 0.568 1.432
#>
#> $xaxp
#> [1] 0 1 5
#>
#> $xaxs
#> [1] "r"
#>
#> $xaxt
#> [1] "s"
#>
#> $xpd
#> [1] FALSE
#>
#> $yaxp
#> [1] 0 1 5
#>
#> $yaxs
#> [1] "r"
#>
#> $yaxt
#> [1] "s"
#>
#> $ylbias
#> [1] 0.2Measurement B Analysis
# Benford's law analysis for Measurement B
benford(
data = histopathology,
var = "MeasurementB"
)
#>
#> BENFORD ANALYSIS
#>
#> See
#> <a href = 'https://github.com/carloscinelli/benford.analysis'>Package
#> documentation for interpratation.
#>
#> Benford object:
#>
#> Data: var
#> Number of observations used = 238
#> Number of obs. for second order = 237
#> First digits analysed = 2
#>
#> Mantissa:
#>
#> Statistic Value
#> Mean 0.45
#> Var 0.12
#> Ex.Kurtosis -1.58
#> Skewness 0.25
#>
#>
#> The 5 largest deviations:
#>
#> digits absolute.diff
#> 1 10 10.15
#> 2 12 9.73
#> 3 14 8.87
#> 4 11 8.01
#> 5 13 7.34
#>
#> Stats:
#>
#> Pearson's Chi-squared test
#>
#> data: var
#> X-squared = 157.07, df = 89, p-value = 1.157e-05
#>
#>
#> Mantissa Arc Test
#>
#> data: var
#> L2 = 0.15767, df = 2, p-value < 2.2e-16
#>
#> Mean Absolute Deviation (MAD): 0.007372993
#> MAD Conformity - Nigrini (2012): Nonconformity
#> Distortion Factor: NaN
#>
#> Remember: Real data will never conform perfectly to Benford's Law. You should not focus on p-values! MeasurementB
#> <num>
#> 1: 1.0190683
#> 2: 1.0097142
#> 3: 1.2020945
#> 4: 0.1069895
#> 5: 1.2977401
#> 6: 1.2517520
#> 7: 1.0263980
#> 8: 1.2205962
#> 9: 1.0371370
#> 10: 0.1045843
#> 11: 1.0848132
#> 12: 1.2214183
#> 13: 1.2689838
#> 14: 1.0163456
#> 15: 1.0066332
#> 16: 1.2965716
#> 17: 1.2178483
#> 18: 1.2748898
#> 19: 1.2152822
#> 20: 1.2102449
#> 21: 1.0574988
#> 22: 1.0725410
#> 23: 1.0075724
#> 24: 1.0321501
#> 25: 1.0183457
#> 26: 1.2888474
#> 27: 1.0625906
#> 28: 1.2003812
#> 29: 1.2789038
#> 30: 1.2528495
#> 31: 1.0202662
#> 32: 1.0519990
#> 33: 1.0276341
#> 34: 1.0836331
#> 35: 1.2221656
#> 36: 1.0199442
#> 37: 1.2825127
#> 38: 1.2066874
#> MeasurementB
#> $xlog
#> [1] FALSE
#>
#> $ylog
#> [1] FALSE
#>
#> $adj
#> [1] 0.5
#>
#> $ann
#> [1] TRUE
#>
#> $ask
#> [1] FALSE
#>
#> $bg
#> [1] "transparent"
#>
#> $bty
#> [1] "o"
#>
#> $cex
#> [1] 0.66
#>
#> $cex.axis
#> [1] 1
#>
#> $cex.lab
#> [1] 1
#>
#> $cex.main
#> [1] 1.2
#>
#> $cex.sub
#> [1] 1
#>
#> $col
#> [1] "black"
#>
#> $col.axis
#> [1] "black"
#>
#> $col.lab
#> [1] "black"
#>
#> $col.main
#> [1] "black"
#>
#> $col.sub
#> [1] "black"
#>
#> $crt
#> [1] 0
#>
#> $err
#> [1] 0
#>
#> $family
#> [1] ""
#>
#> $fg
#> [1] "black"
#>
#> $fig
#> [1] 0.6666667 1.0000000 0.0000000 0.5000000
#>
#> $fin
#> [1] 8 6
#>
#> $font
#> [1] 1
#>
#> $font.axis
#> [1] 1
#>
#> $font.lab
#> [1] 1
#>
#> $font.main
#> [1] 2
#>
#> $font.sub
#> [1] 1
#>
#> $lab
#> [1] 5 5 7
#>
#> $las
#> [1] 0
#>
#> $lend
#> [1] "round"
#>
#> $lheight
#> [1] 1
#>
#> $ljoin
#> [1] "round"
#>
#> $lmitre
#> [1] 10
#>
#> $lty
#> [1] "solid"
#>
#> $lwd
#> [1] 1
#>
#> $mai
#> [1] 1.02 0.82 0.82 0.42
#>
#> $mar
#> [1] 5.1 4.1 4.1 2.1
#>
#> $mex
#> [1] 1
#>
#> $mfcol
#> [1] 1 1
#>
#> $mfg
#> [1] 1 1 1 1
#>
#> $mfrow
#> [1] 1 1
#>
#> $mgp
#> [1] 3 1 0
#>
#> $mkh
#> [1] 0.001
#>
#> $new
#> [1] TRUE
#>
#> $oma
#> [1] 0 0 0 0
#>
#> $omd
#> [1] 0 1 0 1
#>
#> $omi
#> [1] 0 0 0 0
#>
#> $pch
#> [1] 1
#>
#> $pin
#> [1] 6.76 4.16
#>
#> $plt
#> [1] 0.0775000 0.9225000 0.1533333 0.8466667
#>
#> $ps
#> [1] 12
#>
#> $pty
#> [1] "m"
#>
#> $smo
#> [1] 1
#>
#> $srt
#> [1] 0
#>
#> $tck
#> [1] NA
#>
#> $tcl
#> [1] -0.5
#>
#> $usr
#> [1] 0.568 1.432 0.568 1.432
#>
#> $xaxp
#> [1] 0 1 5
#>
#> $xaxs
#> [1] "r"
#>
#> $xaxt
#> [1] "s"
#>
#> $xpd
#> [1] FALSE
#>
#> $yaxp
#> [1] 0 1 5
#>
#> $yaxs
#> [1] "r"
#>
#> $yaxt
#> [1] "s"
#>
#> $ylbias
#> [1] 0.2Overall Time Analysis
# Benford's law analysis for follow-up time
benford(
data = histopathology,
var = "OverallTime"
)
#>
#> BENFORD ANALYSIS
#>
#> See
#> <a href = 'https://github.com/carloscinelli/benford.analysis'>Package
#> documentation for interpratation.
#>
#> Benford object:
#>
#> Data: var
#> Number of observations used = 248
#> Number of obs. for second order = 157
#> First digits analysed = 2
#>
#> Mantissa:
#>
#> Statistic Value
#> Mean 0.569
#> Var 0.091
#> Ex.Kurtosis -1.023
#> Skewness -0.389
#>
#>
#> The 5 largest deviations:
#>
#> digits absolute.diff
#> 1 12 7.62
#> 2 13 6.98
#> 3 32 6.69
#> 4 16 6.53
#> 5 11 5.63
#>
#> Stats:
#>
#> Pearson's Chi-squared test
#>
#> data: var
#> X-squared = 149.57, df = 89, p-value = 6.194e-05
#>
#>
#> Mantissa Arc Test
#>
#> data: var
#> L2 = 0.033636, df = 2, p-value = 0.0002383
#>
#> Mean Absolute Deviation (MAD): 0.006604894
#> MAD Conformity - Nigrini (2012): Nonconformity
#> Distortion Factor: -34.7503
#>
#> Remember: Real data will never conform perfectly to Benford's Law. You should not focus on p-values! OverallTime
#> <num>
#> 1: 13.4
#> 2: 12.9
#> $xlog
#> [1] FALSE
#>
#> $ylog
#> [1] FALSE
#>
#> $adj
#> [1] 0.5
#>
#> $ann
#> [1] TRUE
#>
#> $ask
#> [1] FALSE
#>
#> $bg
#> [1] "transparent"
#>
#> $bty
#> [1] "o"
#>
#> $cex
#> [1] 0.66
#>
#> $cex.axis
#> [1] 1
#>
#> $cex.lab
#> [1] 1
#>
#> $cex.main
#> [1] 1.2
#>
#> $cex.sub
#> [1] 1
#>
#> $col
#> [1] "black"
#>
#> $col.axis
#> [1] "black"
#>
#> $col.lab
#> [1] "black"
#>
#> $col.main
#> [1] "black"
#>
#> $col.sub
#> [1] "black"
#>
#> $crt
#> [1] 0
#>
#> $err
#> [1] 0
#>
#> $family
#> [1] ""
#>
#> $fg
#> [1] "black"
#>
#> $fig
#> [1] 0.6666667 1.0000000 0.0000000 0.5000000
#>
#> $fin
#> [1] 8 6
#>
#> $font
#> [1] 1
#>
#> $font.axis
#> [1] 1
#>
#> $font.lab
#> [1] 1
#>
#> $font.main
#> [1] 2
#>
#> $font.sub
#> [1] 1
#>
#> $lab
#> [1] 5 5 7
#>
#> $las
#> [1] 0
#>
#> $lend
#> [1] "round"
#>
#> $lheight
#> [1] 1
#>
#> $ljoin
#> [1] "round"
#>
#> $lmitre
#> [1] 10
#>
#> $lty
#> [1] "solid"
#>
#> $lwd
#> [1] 1
#>
#> $mai
#> [1] 1.02 0.82 0.82 0.42
#>
#> $mar
#> [1] 5.1 4.1 4.1 2.1
#>
#> $mex
#> [1] 1
#>
#> $mfcol
#> [1] 1 1
#>
#> $mfg
#> [1] 1 1 1 1
#>
#> $mfrow
#> [1] 1 1
#>
#> $mgp
#> [1] 3 1 0
#>
#> $mkh
#> [1] 0.001
#>
#> $new
#> [1] TRUE
#>
#> $oma
#> [1] 0 0 0 0
#>
#> $omd
#> [1] 0 1 0 1
#>
#> $omi
#> [1] 0 0 0 0
#>
#> $pch
#> [1] 1
#>
#> $pin
#> [1] 6.76 4.16
#>
#> $plt
#> [1] 0.0775000 0.9225000 0.1533333 0.8466667
#>
#> $ps
#> [1] 12
#>
#> $pty
#> [1] "m"
#>
#> $smo
#> [1] 1
#>
#> $srt
#> [1] 0
#>
#> $tck
#> [1] NA
#>
#> $tcl
#> [1] -0.5
#>
#> $usr
#> [1] 0.568 1.432 0.568 1.432
#>
#> $xaxp
#> [1] 0 1 5
#>
#> $xaxs
#> [1] "r"
#>
#> $xaxt
#> [1] "s"
#>
#> $xpd
#> [1] FALSE
#>
#> $yaxp
#> [1] 0 1 5
#>
#> $yaxs
#> [1] "r"
#>
#> $yaxt
#> [1] "s"
#>
#> $ylbias
#> [1] 0.2Phase 5: Inter-rater Reliability Assessment
Rater Agreement Analysis
# Analyze inter-rater reliability data
rater_vars <- histopathology %>%
select(starts_with("Rater")) %>%
names()
if(length(rater_vars) > 0) {
# Binary rater variables
binary_raters <- rater_vars[grepl("[0-9]$", rater_vars)]
if(length(binary_raters) > 0) {
tryCatch({
reportcat(
data = histopathology,
vars = binary_raters[1:min(3, length(binary_raters))]
)
}, error = function(e) {
cat("Error with binary raters reportcat:", conditionMessage(e), "\n")
cat("Binary rater variables:", paste(binary_raters, collapse = ", "), "\n")
})
} else {
cat("No binary rater variables found (ending with digits)\n")
}
# Categorical rater variables
categorical_raters <- rater_vars[grepl("[A-Z]$", rater_vars)]
if(length(categorical_raters) > 0) {
tryCatch({
reportcat(
data = histopathology,
vars = categorical_raters
)
}, error = function(e) {
cat("Error with categorical raters reportcat:", conditionMessage(e), "\n")
cat("Categorical rater variables:", paste(categorical_raters, collapse = ", "), "\n")
})
} else {
cat("No categorical rater variables found (ending with letters)\n")
}
} else {
cat("No rater variables found in dataset\n")
}
#> <div id="kkeulbfdpb" style="padding-left:0px;padding-right:0px;padding-top:10px;padding-bottom:10px;overflow-x:auto;overflow-y:auto;width:auto;height:auto;">
#> <style>@import url("https://fonts.googleapis.com/css2?family=Lato:ital,wght@0,100;0,200;0,300;0,400;0,500;0,600;0,700;0,800;0,900;1,100;1,200;1,300;1,400;1,500;1,600;1,700;1,800;1,900&display=swap");
#> #kkeulbfdpb table {
#> font-family: Lato, system-ui, 'Segoe UI', Roboto, Helvetica, Arial, sans-serif, 'Apple Color Emoji', 'Segoe UI Emoji', 'Segoe UI Symbol', 'Noto Color Emoji';
#> -webkit-font-smoothing: antialiased;
#> -moz-osx-font-smoothing: grayscale;
#> }
#>
#> #kkeulbfdpb thead, #kkeulbfdpb tbody, #kkeulbfdpb tfoot, #kkeulbfdpb tr, #kkeulbfdpb td, #kkeulbfdpb th {
#> border-style: none;
#> }
#>
#> #kkeulbfdpb p {
#> margin: 0;
#> padding: 0;
#> }
#>
#> #kkeulbfdpb .gt_table {
#> display: table;
#> border-collapse: collapse;
#> line-height: normal;
#> margin-left: auto;
#> margin-right: auto;
#> color: #333333;
#> font-size: 16px;
#> font-weight: normal;
#> font-style: normal;
#> background-color: #FFFFFF;
#> width: auto;
#> border-top-style: solid;
#> border-top-width: 3px;
#> border-top-color: #FFFFFF;
#> border-right-style: none;
#> border-right-width: 2px;
#> border-right-color: #D3D3D3;
#> border-bottom-style: solid;
#> border-bottom-width: 2px;
#> border-bottom-color: #A8A8A8;
#> border-left-style: none;
#> border-left-width: 2px;
#> border-left-color: #D3D3D3;
#> }
#>
#> #kkeulbfdpb .gt_caption {
#> padding-top: 4px;
#> padding-bottom: 4px;
#> }
#>
#> #kkeulbfdpb .gt_title {
#> color: #333333;
#> font-size: 24px;
#> font-weight: initial;
#> padding-top: 4px;
#> padding-bottom: 4px;
#> padding-left: 5px;
#> padding-right: 5px;
#> border-bottom-color: #FFFFFF;
#> border-bottom-width: 0;
#> }
#>
#> #kkeulbfdpb .gt_subtitle {
#> color: #333333;
#> font-size: 85%;
#> font-weight: initial;
#> padding-top: 3px;
#> padding-bottom: 5px;
#> padding-left: 5px;
#> padding-right: 5px;
#> border-top-color: #FFFFFF;
#> border-top-width: 0;
#> }
#>
#> #kkeulbfdpb .gt_heading {
#> background-color: #FFFFFF;
#> text-align: left;
#> border-bottom-color: #FFFFFF;
#> border-left-style: none;
#> border-left-width: 1px;
#> border-left-color: #D3D3D3;
#> border-right-style: none;
#> border-right-width: 1px;
#> border-right-color: #D3D3D3;
#> }
#>
#> #kkeulbfdpb .gt_bottom_border {
#> border-bottom-style: solid;
#> border-bottom-width: 0px;
#> border-bottom-color: #D3D3D3;
#> }
#>
#> #kkeulbfdpb .gt_col_headings {
#> border-top-style: solid;
#> border-top-width: 0px;
#> border-top-color: #D3D3D3;
#> border-bottom-style: solid;
#> border-bottom-width: 2px;
#> border-bottom-color: #D3D3D3;
#> border-left-style: none;
#> border-left-width: 1px;
#> border-left-color: #D3D3D3;
#> border-right-style: none;
#> border-right-width: 1px;
#> border-right-color: #D3D3D3;
#> }
#>
#> #kkeulbfdpb .gt_col_heading {
#> color: #333333;
#> background-color: #FFFFFF;
#> font-size: 80%;
#> font-weight: bolder;
#> text-transform: uppercase;
#> border-left-style: none;
#> border-left-width: 1px;
#> border-left-color: #D3D3D3;
#> border-right-style: none;
#> border-right-width: 1px;
#> border-right-color: #D3D3D3;
#> vertical-align: bottom;
#> padding-top: 5px;
#> padding-bottom: 6px;
#> padding-left: 5px;
#> padding-right: 5px;
#> overflow-x: hidden;
#> }
#>
#> #kkeulbfdpb .gt_column_spanner_outer {
#> color: #333333;
#> background-color: #FFFFFF;
#> font-size: 80%;
#> font-weight: bolder;
#> text-transform: uppercase;
#> padding-top: 0;
#> padding-bottom: 0;
#> padding-left: 4px;
#> padding-right: 4px;
#> }
#>
#> #kkeulbfdpb .gt_column_spanner_outer:first-child {
#> padding-left: 0;
#> }
#>
#> #kkeulbfdpb .gt_column_spanner_outer:last-child {
#> padding-right: 0;
#> }
#>
#> #kkeulbfdpb .gt_column_spanner {
#> border-bottom-style: solid;
#> border-bottom-width: 2px;
#> border-bottom-color: #D3D3D3;
#> vertical-align: bottom;
#> padding-top: 5px;
#> padding-bottom: 5px;
#> overflow-x: hidden;
#> display: inline-block;
#> width: 100%;
#> }
#>
#> #kkeulbfdpb .gt_spanner_row {
#> border-bottom-style: hidden;
#> }
#>
#> #kkeulbfdpb .gt_group_heading {
#> padding-top: 8px;
#> padding-bottom: 8px;
#> padding-left: 5px;
#> padding-right: 5px;
#> color: #333333;
#> background-color: #FFFFFF;
#> font-size: 80%;
#> font-weight: bolder;
#> text-transform: uppercase;
#> border-top-style: solid;
#> border-top-width: 2px;
#> border-top-color: #D3D3D3;
#> border-bottom-style: solid;
#> border-bottom-width: 2px;
#> border-bottom-color: #D3D3D3;
#> border-left-style: none;
#> border-left-width: 1px;
#> border-left-color: #D3D3D3;
#> border-right-style: none;
#> border-right-width: 1px;
#> border-right-color: #D3D3D3;
#> vertical-align: middle;
#> text-align: left;
#> }
#>
#> #kkeulbfdpb .gt_empty_group_heading {
#> padding: 0.5px;
#> color: #333333;
#> background-color: #FFFFFF;
#> font-size: 80%;
#> font-weight: bolder;
#> border-top-style: solid;
#> border-top-width: 2px;
#> border-top-color: #D3D3D3;
#> border-bottom-style: solid;
#> border-bottom-width: 2px;
#> border-bottom-color: #D3D3D3;
#> vertical-align: middle;
#> }
#>
#> #kkeulbfdpb .gt_from_md > :first-child {
#> margin-top: 0;
#> }
#>
#> #kkeulbfdpb .gt_from_md > :last-child {
#> margin-bottom: 0;
#> }
#>
#> #kkeulbfdpb .gt_row {
#> padding-top: 7px;
#> padding-bottom: 7px;
#> padding-left: 5px;
#> padding-right: 5px;
#> margin: 10px;
#> border-top-style: solid;
#> border-top-width: 1px;
#> border-top-color: #F6F7F7;
#> border-left-style: none;
#> border-left-width: 1px;
#> border-left-color: #D3D3D3;
#> border-right-style: none;
#> border-right-width: 1px;
#> border-right-color: #D3D3D3;
#> vertical-align: middle;
#> overflow-x: hidden;
#> }
#>
#> #kkeulbfdpb .gt_stub {
#> color: #333333;
#> background-color: #FFFFFF;
#> font-size: 80%;
#> font-weight: bolder;
#> text-transform: uppercase;
#> border-right-style: solid;
#> border-right-width: 2px;
#> border-right-color: #D3D3D3;
#> padding-left: 5px;
#> padding-right: 5px;
#> }
#>
#> #kkeulbfdpb .gt_stub_row_group {
#> color: #333333;
#> background-color: #FFFFFF;
#> font-size: 100%;
#> font-weight: initial;
#> text-transform: inherit;
#> border-right-style: solid;
#> border-right-width: 2px;
#> border-right-color: #D3D3D3;
#> padding-left: 5px;
#> padding-right: 5px;
#> vertical-align: top;
#> }
#>
#> #kkeulbfdpb .gt_row_group_first td {
#> border-top-width: 2px;
#> }
#>
#> #kkeulbfdpb .gt_row_group_first th {
#> border-top-width: 2px;
#> }
#>
#> #kkeulbfdpb .gt_summary_row {
#> color: #333333;
#> background-color: #FFFFFF;
#> text-transform: inherit;
#> padding-top: 8px;
#> padding-bottom: 8px;
#> padding-left: 5px;
#> padding-right: 5px;
#> }
#>
#> #kkeulbfdpb .gt_first_summary_row {
#> border-top-style: solid;
#> border-top-color: #D3D3D3;
#> }
#>
#> #kkeulbfdpb .gt_first_summary_row.thick {
#> border-top-width: 2px;
#> }
#>
#> #kkeulbfdpb .gt_last_summary_row {
#> padding-top: 8px;
#> padding-bottom: 8px;
#> padding-left: 5px;
#> padding-right: 5px;
#> border-bottom-style: solid;
#> border-bottom-width: 2px;
#> border-bottom-color: #D3D3D3;
#> }
#>
#> #kkeulbfdpb .gt_grand_summary_row {
#> color: #333333;
#> background-color: #FFFFFF;
#> text-transform: inherit;
#> padding-top: 8px;
#> padding-bottom: 8px;
#> padding-left: 5px;
#> padding-right: 5px;
#> }
#>
#> #kkeulbfdpb .gt_first_grand_summary_row {
#> padding-top: 8px;
#> padding-bottom: 8px;
#> padding-left: 5px;
#> padding-right: 5px;
#> border-top-style: double;
#> border-top-width: 6px;
#> border-top-color: #D3D3D3;
#> }
#>
#> #kkeulbfdpb .gt_last_grand_summary_row_top {
#> padding-top: 8px;
#> padding-bottom: 8px;
#> padding-left: 5px;
#> padding-right: 5px;
#> border-bottom-style: double;
#> border-bottom-width: 6px;
#> border-bottom-color: #D3D3D3;
#> }
#>
#> #kkeulbfdpb .gt_striped {
#> background-color: #FAFAFA;
#> }
#>
#> #kkeulbfdpb .gt_table_body {
#> border-top-style: solid;
#> border-top-width: 2px;
#> border-top-color: #D3D3D3;
#> border-bottom-style: solid;
#> border-bottom-width: 2px;
#> border-bottom-color: #D3D3D3;
#> }
#>
#> #kkeulbfdpb .gt_footnotes {
#> color: #333333;
#> background-color: #FFFFFF;
#> border-bottom-style: none;
#> border-bottom-width: 2px;
#> border-bottom-color: #D3D3D3;
#> border-left-style: none;
#> border-left-width: 2px;
#> border-left-color: #D3D3D3;
#> border-right-style: none;
#> border-right-width: 2px;
#> border-right-color: #D3D3D3;
#> }
#>
#> #kkeulbfdpb .gt_footnote {
#> margin: 0px;
#> font-size: 90%;
#> padding-top: 4px;
#> padding-bottom: 4px;
#> padding-left: 5px;
#> padding-right: 5px;
#> }
#>
#> #kkeulbfdpb .gt_sourcenotes {
#> color: #333333;
#> background-color: #FFFFFF;
#> border-bottom-style: none;
#> border-bottom-width: 2px;
#> border-bottom-color: #D3D3D3;
#> border-left-style: none;
#> border-left-width: 2px;
#> border-left-color: #D3D3D3;
#> border-right-style: none;
#> border-right-width: 2px;
#> border-right-color: #D3D3D3;
#> }
#>
#> #kkeulbfdpb .gt_sourcenote {
#> font-size: 12px;
#> padding-top: 4px;
#> padding-bottom: 4px;
#> padding-left: 5px;
#> padding-right: 5px;
#> }
#>
#> #kkeulbfdpb .gt_left {
#> text-align: left;
#> }
#>
#> #kkeulbfdpb .gt_center {
#> text-align: center;
#> }
#>
#> #kkeulbfdpb .gt_right {
#> text-align: right;
#> font-variant-numeric: tabular-nums;
#> }
#>
#> #kkeulbfdpb .gt_font_normal {
#> font-weight: normal;
#> }
#>
#> #kkeulbfdpb .gt_font_bold {
#> font-weight: bold;
#> }
#>
#> #kkeulbfdpb .gt_font_italic {
#> font-style: italic;
#> }
#>
#> #kkeulbfdpb .gt_super {
#> font-size: 65%;
#> }
#>
#> #kkeulbfdpb .gt_footnote_marks {
#> font-size: 75%;
#> vertical-align: 0.4em;
#> position: initial;
#> }
#>
#> #kkeulbfdpb .gt_asterisk {
#> font-size: 100%;
#> vertical-align: 0;
#> }
#>
#> #kkeulbfdpb .gt_indent_1 {
#> text-indent: 5px;
#> }
#>
#> #kkeulbfdpb .gt_indent_2 {
#> text-indent: 10px;
#> }
#>
#> #kkeulbfdpb .gt_indent_3 {
#> text-indent: 15px;
#> }
#>
#> #kkeulbfdpb .gt_indent_4 {
#> text-indent: 20px;
#> }
#>
#> #kkeulbfdpb .gt_indent_5 {
#> text-indent: 25px;
#> }
#>
#> #kkeulbfdpb .katex-display {
#> display: inline-flex !important;
#> margin-bottom: 0.75em !important;
#> }
#>
#> #kkeulbfdpb div.Reactable > div.rt-table > div.rt-thead > div.rt-tr.rt-tr-group-header > div.rt-th-group:after {
#> height: 0px !important;
#> }
#> </style>
#> <table class="gt_table" data-quarto-disable-processing="false" data-quarto-bootstrap="false">
#> <thead>
#> <tr class="gt_heading">
#> <td colspan="4" class="gt_heading gt_title gt_font_normal" style>.</td>
#> </tr>
#> <tr class="gt_heading">
#> <td colspan="4" class="gt_heading gt_subtitle gt_font_normal gt_bottom_border" style>250 rows x 3 cols</td>
#> </tr>
#> <tr class="gt_col_headings">
#> <th class="gt_col_heading gt_columns_bottom_border gt_left" rowspan="1" colspan="1" scope="col" id="type"></th>
#> <th class="gt_col_heading gt_columns_bottom_border gt_left" rowspan="1" colspan="1" scope="col" id="name">Column</th>
#> <th class="gt_col_heading gt_columns_bottom_border gt_center" rowspan="1" colspan="1" scope="col" id="value">Plot Overview</th>
#> <th class="gt_col_heading gt_columns_bottom_border gt_right" rowspan="1" colspan="1" scope="col" id="n_missing">Missing</th>
#> </tr>
#> </thead>
#> <tbody class="gt_table_body">
#> <tr><td headers="type" class="gt_row gt_left"><svg aria-hidden="true" role="img" viewBox="0 0 512 512" style="height:20px;width:20px;vertical-align:-0.125em;margin-left:auto;margin-right:auto;font-size:inherit;fill:#4e79a7;overflow:visible;position:relative;"><path d="M40 48C26.7 48 16 58.7 16 72v48c0 13.3 10.7 24 24 24H88c13.3 0 24-10.7 24-24V72c0-13.3-10.7-24-24-24H40zM192 64c-17.7 0-32 14.3-32 32s14.3 32 32 32H480c17.7 0 32-14.3 32-32s-14.3-32-32-32H192zm0 160c-17.7 0-32 14.3-32 32s14.3 32 32 32H480c17.7 0 32-14.3 32-32s-14.3-32-32-32H192zm0 160c-17.7 0-32 14.3-32 32s14.3 32 32 32H480c17.7 0 32-14.3 32-32s-14.3-32-32-32H192zM16 232v48c0 13.3 10.7 24 24 24H88c13.3 0 24-10.7 24-24V232c0-13.3-10.7-24-24-24H40c-13.3 0-24 10.7-24 24zM40 368c-13.3 0-24 10.7-24 24v48c0 13.3 10.7 24 24 24H88c13.3 0 24-10.7 24-24V392c0-13.3-10.7-24-24-24H40z"/></svg></td>
#> <td headers="name" class="gt_row gt_left" style="font-weight: bold;"><div style='max-width: 150px;'>
#> <details style='font-weight: normal !important;'>
#> <summary style='font-weight: bold !important;'>Rater 1</summary>
#> 1 and 0
#> </details></div></td>
#> <td headers="value" class="gt_row gt_center"><?xml version='1.0' encoding='UTF-8' ?><svg xmlns='http://www.w3.org/2000/svg' xmlns:xlink='http://www.w3.org/1999/xlink' width='141.73pt' height='34.02pt' viewBox='0 0 141.73 34.02'><g class='svglite'><defs> <style type='text/css'><![CDATA[ .svglite line, .svglite polyline, .svglite polygon, .svglite path, .svglite rect, .svglite circle { fill: none; stroke: #000000; stroke-linecap: round; stroke-linejoin: round; stroke-miterlimit: 10.00; } .svglite text { white-space: pre; } .svglite g.glyphgroup path { fill: inherit; stroke: none; } ]]></style></defs><rect width='100%' height='100%' style='stroke: none; fill: none;'/><defs> <clipPath id='cpMC4wMHwxNDEuNzN8MC4wMHwzNC4wMg=='> <rect x='0.00' y='0.00' width='141.73' height='34.02' /> </clipPath></defs><g clip-path='url(#cpMC4wMHwxNDEuNzN8MC4wMHwzNC4wMg==)'></g><defs> <clipPath id='cpMS4wMHwxNDAuNzR8Mi45OXwyMy42MQ=='> <rect x='1.00' y='2.99' width='139.74' height='20.62' /> </clipPath></defs><g clip-path='url(#cpMS4wMHwxNDAuNzR8Mi45OXwyMy42MQ==)'><rect x='95.84' y='3.93' width='44.90' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #DDEAF7;' /><rect x='1.00' y='3.93' width='94.84' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #3181BD;' /></g><g clip-path='url(#cpMC4wMHwxNDEuNzN8MC4wMHwzNC4wMg==)'><text x='1.00' y='30.18' style='font-size: 8.00px; font-family: "Arial";' textLength='43.61px' lengthAdjust='spacingAndGlyphs'>2 categories</text></g></g></svg></td>
#> <td headers="n_missing" class="gt_row gt_right">0.4%</td></tr>
#> <tr><td headers="type" class="gt_row gt_left gt_striped"><svg aria-hidden="true" role="img" viewBox="0 0 512 512" style="height:20px;width:20px;vertical-align:-0.125em;margin-left:auto;margin-right:auto;font-size:inherit;fill:#4e79a7;overflow:visible;position:relative;"><path d="M40 48C26.7 48 16 58.7 16 72v48c0 13.3 10.7 24 24 24H88c13.3 0 24-10.7 24-24V72c0-13.3-10.7-24-24-24H40zM192 64c-17.7 0-32 14.3-32 32s14.3 32 32 32H480c17.7 0 32-14.3 32-32s-14.3-32-32-32H192zm0 160c-17.7 0-32 14.3-32 32s14.3 32 32 32H480c17.7 0 32-14.3 32-32s-14.3-32-32-32H192zm0 160c-17.7 0-32 14.3-32 32s14.3 32 32 32H480c17.7 0 32-14.3 32-32s-14.3-32-32-32H192zM16 232v48c0 13.3 10.7 24 24 24H88c13.3 0 24-10.7 24-24V232c0-13.3-10.7-24-24-24H40c-13.3 0-24 10.7-24 24zM40 368c-13.3 0-24 10.7-24 24v48c0 13.3 10.7 24 24 24H88c13.3 0 24-10.7 24-24V392c0-13.3-10.7-24-24-24H40z"/></svg></td>
#> <td headers="name" class="gt_row gt_left gt_striped" style="font-weight: bold;"><div style='max-width: 150px;'>
#> <details style='font-weight: normal !important;'>
#> <summary style='font-weight: bold !important;'>Rater 2</summary>
#> 1 and 0
#> </details></div></td>
#> <td headers="value" class="gt_row gt_center gt_striped"><?xml version='1.0' encoding='UTF-8' ?><svg xmlns='http://www.w3.org/2000/svg' xmlns:xlink='http://www.w3.org/1999/xlink' width='141.73pt' height='34.02pt' viewBox='0 0 141.73 34.02'><g class='svglite'><defs> <style type='text/css'><![CDATA[ .svglite line, .svglite polyline, .svglite polygon, .svglite path, .svglite rect, .svglite circle { fill: none; stroke: #000000; stroke-linecap: round; stroke-linejoin: round; stroke-miterlimit: 10.00; } .svglite text { white-space: pre; } .svglite g.glyphgroup path { fill: inherit; stroke: none; } ]]></style></defs><rect width='100%' height='100%' style='stroke: none; fill: none;'/><defs> <clipPath id='cpMC4wMHwxNDEuNzN8MC4wMHwzNC4wMg=='> <rect x='0.00' y='0.00' width='141.73' height='34.02' /> </clipPath></defs><g clip-path='url(#cpMC4wMHwxNDEuNzN8MC4wMHwzNC4wMg==)'></g><defs> <clipPath id='cpMS4wMHwxNDAuNzR8Mi45OXwyMy42MQ=='> <rect x='1.00' y='2.99' width='139.74' height='20.62' /> </clipPath></defs><g clip-path='url(#cpMS4wMHwxNDAuNzR8Mi45OXwyMy42MQ==)'><rect x='90.99' y='3.93' width='49.75' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #DDEAF7;' /><rect x='1.00' y='3.93' width='89.99' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #3181BD;' /></g><g clip-path='url(#cpMC4wMHwxNDEuNzN8MC4wMHwzNC4wMg==)'><text x='1.00' y='30.18' style='font-size: 8.00px; font-family: "Arial";' textLength='43.61px' lengthAdjust='spacingAndGlyphs'>2 categories</text></g></g></svg></td>
#> <td headers="n_missing" class="gt_row gt_right gt_striped">0.0%</td></tr>
#> <tr><td headers="type" class="gt_row gt_left"><svg aria-hidden="true" role="img" viewBox="0 0 512 512" style="height:20px;width:20px;vertical-align:-0.125em;margin-left:auto;margin-right:auto;font-size:inherit;fill:#4e79a7;overflow:visible;position:relative;"><path d="M40 48C26.7 48 16 58.7 16 72v48c0 13.3 10.7 24 24 24H88c13.3 0 24-10.7 24-24V72c0-13.3-10.7-24-24-24H40zM192 64c-17.7 0-32 14.3-32 32s14.3 32 32 32H480c17.7 0 32-14.3 32-32s-14.3-32-32-32H192zm0 160c-17.7 0-32 14.3-32 32s14.3 32 32 32H480c17.7 0 32-14.3 32-32s-14.3-32-32-32H192zm0 160c-17.7 0-32 14.3-32 32s14.3 32 32 32H480c17.7 0 32-14.3 32-32s-14.3-32-32-32H192zM16 232v48c0 13.3 10.7 24 24 24H88c13.3 0 24-10.7 24-24V232c0-13.3-10.7-24-24-24H40c-13.3 0-24 10.7-24 24zM40 368c-13.3 0-24 10.7-24 24v48c0 13.3 10.7 24 24 24H88c13.3 0 24-10.7 24-24V392c0-13.3-10.7-24-24-24H40z"/></svg></td>
#> <td headers="name" class="gt_row gt_left" style="font-weight: bold;"><div style='max-width: 150px;'>
#> <details style='font-weight: normal !important;'>
#> <summary style='font-weight: bold !important;'>Rater 3</summary>
#> 1 and 0
#> </details></div></td>
#> <td headers="value" class="gt_row gt_center"><?xml version='1.0' encoding='UTF-8' ?><svg xmlns='http://www.w3.org/2000/svg' xmlns:xlink='http://www.w3.org/1999/xlink' width='141.73pt' height='34.02pt' viewBox='0 0 141.73 34.02'><g class='svglite'><defs> <style type='text/css'><![CDATA[ .svglite line, .svglite polyline, .svglite polygon, .svglite path, .svglite rect, .svglite circle { fill: none; stroke: #000000; stroke-linecap: round; stroke-linejoin: round; stroke-miterlimit: 10.00; } .svglite text { white-space: pre; } .svglite g.glyphgroup path { fill: inherit; stroke: none; } ]]></style></defs><rect width='100%' height='100%' style='stroke: none; fill: none;'/><defs> <clipPath id='cpMC4wMHwxNDEuNzN8MC4wMHwzNC4wMg=='> <rect x='0.00' y='0.00' width='141.73' height='34.02' /> </clipPath></defs><g clip-path='url(#cpMC4wMHwxNDEuNzN8MC4wMHwzNC4wMg==)'></g><defs> <clipPath id='cpMS4wMHwxNDAuNzR8Mi45OXwyMy42MQ=='> <rect x='1.00' y='2.99' width='139.74' height='20.62' /> </clipPath></defs><g clip-path='url(#cpMS4wMHwxNDAuNzR8Mi45OXwyMy42MQ==)'><rect x='83.16' y='3.93' width='57.57' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #DDEAF7;' /><rect x='1.00' y='3.93' width='82.17' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #3181BD;' /></g><g clip-path='url(#cpMC4wMHwxNDEuNzN8MC4wMHwzNC4wMg==)'><text x='1.00' y='30.18' style='font-size: 8.00px; font-family: "Arial";' textLength='43.61px' lengthAdjust='spacingAndGlyphs'>2 categories</text></g></g></svg></td>
#> <td headers="n_missing" class="gt_row gt_right">0.0%</td></tr>
#> </tbody>
#>
#>
#> </table>
#> </div>
#> Error with categorical raters reportcat: 'names' attribute [38] must be the same length as the vector [0]
#> Categorical rater variables: Rater A, Rater BAgreement Cross-tabulation
# Cross-tabulate raters for agreement assessment
if(length(rater_vars) >= 2) {
crosstable(
data = histopathology,
vars = rater_vars[1],
group = rater_vars[2]
)
}
#>
#> CROSS TABLE
#>
#> character(0)
#>
#> character(0)
#>
#> <div class="figure" id="tbl3">
#> #tbl3 body .figbody {
#> font-family: Corbel, "Lucida Grande", "Lucida Sans Unicode", "Lucida
#> Sans", "DejaVu Sans", "Bitstream Vera Sans", "Liberation Sans",
#> Verdana, "Verdana Ref", sans-serif;
#> font-size: 66%;
#> -webkit-print-color-adjust: exact;
#> }
#>
#> #tbl3 .figure { margin-left: auto;
#> margin-right: auto;
#> }
#> #tbl3 .caption { text-align: left;
#> text-indent: 2em;
#> padding: 0.5em 0 0.5em 0;
#> font-weight: bold;
#> background-color: #f7f4ef !important;
#> border: 1px solid black;
#> }
#>
#> #tbl3 .figbody {
#> text-align: center;
#> border: 1px solid black
#> }
#>
#> #tbl3 .figbody table {
#> margin: 0;
#> width: 100%;
#> }
#>
#> #tbl3 .figbody td {
#> padding: 0.2em 0.5em 0.2em 0.5em;
#> }
#>
#> #tbl3 .figbody thead tr td
#> {
#> font-weight: bold;
#> }
#>
#> #tbl3 .figbody tbody tr:nth-child(odd) {background: #fffbed
#> !important;}
#>
#> #tbl3 .header td {text-align: center;}
#>
#> #tbl3 .subheader { font-size: smaller; }
#> #tbl3 .subheader td { text-align: center; /* border-bottom: 1pt solid
#> black; */ }
#>
#> #tbl3 .subheader em {font-style: normal;}
#>
#> #tbl3 tbody .variable {
#> float: left;
#> text-align: left;
#> padding-left: 0.5em;
#> }
#>
#> #tbl3 .units {
#> float: right;
#> font-size: x-small;
#> text-align: right;
#> padding-left: 1em;
#> vertical-align: text-bottom; /* FIXME why doesn't this work */
#> }
#>
#> #tbl3 td .align{
#> display: inline-block;
#> margin: 0 auto;
#> }
#>
#> #tbl3 .nobr {
#> white-space: nowrap;
#> }
#> #tbl3 .supsub {
#> display: inline-block;
#> margin: -9em 0;
#> vertical-align: -0.55em;
#> line-height: 1.35em;
#> font-size: 70%;
#> text-align: left;
#> }
#>
#> #tbl3 .statistics {font-style: italic;}
#> #tbl3 .statistics {padding-right: 0.5em;}
#> <div class="caption">Cross Table for Dependent rater_2<div
#> class="figbody"><table class="tangram">
#> <th class="header even tg-label"><span class="variable"><th
#> class="header even tg-label"><span class="variable">N<th class="header
#> even tg-label"><span class="variable">0<th class="header even
#> tg-label"><span class="variable">1<th class="header even
#> tg-label"><span class="variable">Test Statistic<tr
#> class="subheaderrow"><th class="subheader header even tg-label"><span
#> class="variable"><th class="subheader header even tg-label"><span
#> class="variable"><th class="subheader header even data N"><span
#> class="N">(N=89)<th class="subheader header even data N"><span
#> class="N">(N=161)<th class="subheader header even tg-label"><span
#> class="variable">
#> <td class="header odd tg-label"><span class="variable">Rater 1<td
#> class="odd data N"><span class="N">249<td class="odd">0.0 0.0 0.0<td
#> class="odd">1.0 1.0 1.0<td class="statistics odd">F1,247=517.22,
#> P<0.013
#> <div class="footnote">N is the number of non-missing value.
#> 1Kruskal-Wallis. 2Pearson. 3Wilcoxon.Phase 6: Outlier Detection
Statistical Outlier Analysis
# Identify potential outliers in continuous variables
outlier_analysis <- histopathology %>%
select(Age, OverallTime, MeasurementA, MeasurementB) %>%
summarise_all(
list(
Mean = ~round(mean(., na.rm = TRUE), 2),
SD = ~round(sd(., na.rm = TRUE), 2),
Q1 = ~round(quantile(., 0.25, na.rm = TRUE), 2),
Q3 = ~round(quantile(., 0.75, na.rm = TRUE), 2),
IQR = ~round(IQR(., na.rm = TRUE), 2),
Lower_Fence = ~round(quantile(., 0.25, na.rm = TRUE) - 1.5 * IQR(., na.rm = TRUE), 2),
Upper_Fence = ~round(quantile(., 0.75, na.rm = TRUE) + 1.5 * IQR(., na.rm = TRUE), 2)
)
) %>%
pivot_longer(everything(), names_to = "Stat", values_to = "Value") %>%
separate(Stat, into = c("Variable", "Statistic"), sep = "_", extra = "merge") %>%
pivot_wider(names_from = Statistic, values_from = Value)
kable(outlier_analysis,
caption = "Outlier Detection Statistics",
digits = 2)| Variable | Mean | SD | Q1 | Q3 | IQR | Lower_Fence | Upper_Fence |
|---|---|---|---|---|---|---|---|
| Age | 49.44 | 13.81 | 38.00 | 62.00 | 24.00 | 2.00 | 98.00 |
| OverallTime | 16.53 | 13.50 | 7.10 | 23.60 | 16.50 | -17.65 | 48.35 |
| MeasurementA | 0.07 | 0.87 | -0.53 | 0.68 | 1.21 | -2.34 | 2.50 |
| MeasurementB | 0.97 | 0.56 | 0.61 | 1.35 | 0.74 | -0.51 | 2.47 |
Extreme Value Assessment
# Count extreme values beyond fences
extreme_values <- histopathology %>%
summarise(
Age_Low_Outliers = sum(Age < (quantile(Age, 0.25, na.rm = TRUE) - 1.5 * IQR(Age, na.rm = TRUE)), na.rm = TRUE),
Age_High_Outliers = sum(Age > (quantile(Age, 0.75, na.rm = TRUE) + 1.5 * IQR(Age, na.rm = TRUE)), na.rm = TRUE),
Time_Low_Outliers = sum(OverallTime < (quantile(OverallTime, 0.25, na.rm = TRUE) - 1.5 * IQR(OverallTime, na.rm = TRUE)), na.rm = TRUE),
Time_High_Outliers = sum(OverallTime > (quantile(OverallTime, 0.75, na.rm = TRUE) + 1.5 * IQR(OverallTime, na.rm = TRUE)), na.rm = TRUE),
MeasA_Low_Outliers = sum(MeasurementA < (quantile(MeasurementA, 0.25, na.rm = TRUE) - 1.5 * IQR(MeasurementA, na.rm = TRUE)), na.rm = TRUE),
MeasA_High_Outliers = sum(MeasurementA > (quantile(MeasurementA, 0.75, na.rm = TRUE) + 1.5 * IQR(MeasurementA, na.rm = TRUE)), na.rm = TRUE)
) %>%
pivot_longer(everything(), names_to = "Variable_Type", values_to = "Outlier_Count") %>%
separate(Variable_Type, into = c("Variable", "Outlier_Type"), sep = "_", extra = "merge")
kable(extreme_values,
caption = "Extreme Value Counts by Variable")| Variable | Outlier_Type | Outlier_Count |
|---|---|---|
| Age | Low_Outliers | 0 |
| Age | High_Outliers | 0 |
| Time | Low_Outliers | 0 |
| Time | High_Outliers | 12 |
| MeasA | Low_Outliers | 1 |
| MeasA | High_Outliers | 0 |
Phase 7: Diagnostic Test Validation
Validity Assessment
# Analyze data validity flags
validity_vars <- histopathology %>%
select(contains("Valid")) %>%
names()
if(length(validity_vars) > 0) {
tryCatch({
reportcat(
data = histopathology,
vars = validity_vars[1]
)
}, error = function(e) {
cat("Error with validity variables reportcat:", conditionMessage(e), "\n")
cat("Validity variables:", paste(validity_vars, collapse = ", "), "\n")
})
} else {
cat("No validity variables found in dataset\n")
}
#> <div id="cyvkgufivj" style="padding-left:0px;padding-right:0px;padding-top:10px;padding-bottom:10px;overflow-x:auto;overflow-y:auto;width:auto;height:auto;">
#> <style>@import url("https://fonts.googleapis.com/css2?family=Lato:ital,wght@0,100;0,200;0,300;0,400;0,500;0,600;0,700;0,800;0,900;1,100;1,200;1,300;1,400;1,500;1,600;1,700;1,800;1,900&display=swap");
#> #cyvkgufivj table {
#> font-family: Lato, system-ui, 'Segoe UI', Roboto, Helvetica, Arial, sans-serif, 'Apple Color Emoji', 'Segoe UI Emoji', 'Segoe UI Symbol', 'Noto Color Emoji';
#> -webkit-font-smoothing: antialiased;
#> -moz-osx-font-smoothing: grayscale;
#> }
#>
#> #cyvkgufivj thead, #cyvkgufivj tbody, #cyvkgufivj tfoot, #cyvkgufivj tr, #cyvkgufivj td, #cyvkgufivj th {
#> border-style: none;
#> }
#>
#> #cyvkgufivj p {
#> margin: 0;
#> padding: 0;
#> }
#>
#> #cyvkgufivj .gt_table {
#> display: table;
#> border-collapse: collapse;
#> line-height: normal;
#> margin-left: auto;
#> margin-right: auto;
#> color: #333333;
#> font-size: 16px;
#> font-weight: normal;
#> font-style: normal;
#> background-color: #FFFFFF;
#> width: auto;
#> border-top-style: solid;
#> border-top-width: 3px;
#> border-top-color: #FFFFFF;
#> border-right-style: none;
#> border-right-width: 2px;
#> border-right-color: #D3D3D3;
#> border-bottom-style: solid;
#> border-bottom-width: 2px;
#> border-bottom-color: #A8A8A8;
#> border-left-style: none;
#> border-left-width: 2px;
#> border-left-color: #D3D3D3;
#> }
#>
#> #cyvkgufivj .gt_caption {
#> padding-top: 4px;
#> padding-bottom: 4px;
#> }
#>
#> #cyvkgufivj .gt_title {
#> color: #333333;
#> font-size: 24px;
#> font-weight: initial;
#> padding-top: 4px;
#> padding-bottom: 4px;
#> padding-left: 5px;
#> padding-right: 5px;
#> border-bottom-color: #FFFFFF;
#> border-bottom-width: 0;
#> }
#>
#> #cyvkgufivj .gt_subtitle {
#> color: #333333;
#> font-size: 85%;
#> font-weight: initial;
#> padding-top: 3px;
#> padding-bottom: 5px;
#> padding-left: 5px;
#> padding-right: 5px;
#> border-top-color: #FFFFFF;
#> border-top-width: 0;
#> }
#>
#> #cyvkgufivj .gt_heading {
#> background-color: #FFFFFF;
#> text-align: left;
#> border-bottom-color: #FFFFFF;
#> border-left-style: none;
#> border-left-width: 1px;
#> border-left-color: #D3D3D3;
#> border-right-style: none;
#> border-right-width: 1px;
#> border-right-color: #D3D3D3;
#> }
#>
#> #cyvkgufivj .gt_bottom_border {
#> border-bottom-style: solid;
#> border-bottom-width: 0px;
#> border-bottom-color: #D3D3D3;
#> }
#>
#> #cyvkgufivj .gt_col_headings {
#> border-top-style: solid;
#> border-top-width: 0px;
#> border-top-color: #D3D3D3;
#> border-bottom-style: solid;
#> border-bottom-width: 2px;
#> border-bottom-color: #D3D3D3;
#> border-left-style: none;
#> border-left-width: 1px;
#> border-left-color: #D3D3D3;
#> border-right-style: none;
#> border-right-width: 1px;
#> border-right-color: #D3D3D3;
#> }
#>
#> #cyvkgufivj .gt_col_heading {
#> color: #333333;
#> background-color: #FFFFFF;
#> font-size: 80%;
#> font-weight: bolder;
#> text-transform: uppercase;
#> border-left-style: none;
#> border-left-width: 1px;
#> border-left-color: #D3D3D3;
#> border-right-style: none;
#> border-right-width: 1px;
#> border-right-color: #D3D3D3;
#> vertical-align: bottom;
#> padding-top: 5px;
#> padding-bottom: 6px;
#> padding-left: 5px;
#> padding-right: 5px;
#> overflow-x: hidden;
#> }
#>
#> #cyvkgufivj .gt_column_spanner_outer {
#> color: #333333;
#> background-color: #FFFFFF;
#> font-size: 80%;
#> font-weight: bolder;
#> text-transform: uppercase;
#> padding-top: 0;
#> padding-bottom: 0;
#> padding-left: 4px;
#> padding-right: 4px;
#> }
#>
#> #cyvkgufivj .gt_column_spanner_outer:first-child {
#> padding-left: 0;
#> }
#>
#> #cyvkgufivj .gt_column_spanner_outer:last-child {
#> padding-right: 0;
#> }
#>
#> #cyvkgufivj .gt_column_spanner {
#> border-bottom-style: solid;
#> border-bottom-width: 2px;
#> border-bottom-color: #D3D3D3;
#> vertical-align: bottom;
#> padding-top: 5px;
#> padding-bottom: 5px;
#> overflow-x: hidden;
#> display: inline-block;
#> width: 100%;
#> }
#>
#> #cyvkgufivj .gt_spanner_row {
#> border-bottom-style: hidden;
#> }
#>
#> #cyvkgufivj .gt_group_heading {
#> padding-top: 8px;
#> padding-bottom: 8px;
#> padding-left: 5px;
#> padding-right: 5px;
#> color: #333333;
#> background-color: #FFFFFF;
#> font-size: 80%;
#> font-weight: bolder;
#> text-transform: uppercase;
#> border-top-style: solid;
#> border-top-width: 2px;
#> border-top-color: #D3D3D3;
#> border-bottom-style: solid;
#> border-bottom-width: 2px;
#> border-bottom-color: #D3D3D3;
#> border-left-style: none;
#> border-left-width: 1px;
#> border-left-color: #D3D3D3;
#> border-right-style: none;
#> border-right-width: 1px;
#> border-right-color: #D3D3D3;
#> vertical-align: middle;
#> text-align: left;
#> }
#>
#> #cyvkgufivj .gt_empty_group_heading {
#> padding: 0.5px;
#> color: #333333;
#> background-color: #FFFFFF;
#> font-size: 80%;
#> font-weight: bolder;
#> border-top-style: solid;
#> border-top-width: 2px;
#> border-top-color: #D3D3D3;
#> border-bottom-style: solid;
#> border-bottom-width: 2px;
#> border-bottom-color: #D3D3D3;
#> vertical-align: middle;
#> }
#>
#> #cyvkgufivj .gt_from_md > :first-child {
#> margin-top: 0;
#> }
#>
#> #cyvkgufivj .gt_from_md > :last-child {
#> margin-bottom: 0;
#> }
#>
#> #cyvkgufivj .gt_row {
#> padding-top: 7px;
#> padding-bottom: 7px;
#> padding-left: 5px;
#> padding-right: 5px;
#> margin: 10px;
#> border-top-style: solid;
#> border-top-width: 1px;
#> border-top-color: #F6F7F7;
#> border-left-style: none;
#> border-left-width: 1px;
#> border-left-color: #D3D3D3;
#> border-right-style: none;
#> border-right-width: 1px;
#> border-right-color: #D3D3D3;
#> vertical-align: middle;
#> overflow-x: hidden;
#> }
#>
#> #cyvkgufivj .gt_stub {
#> color: #333333;
#> background-color: #FFFFFF;
#> font-size: 80%;
#> font-weight: bolder;
#> text-transform: uppercase;
#> border-right-style: solid;
#> border-right-width: 2px;
#> border-right-color: #D3D3D3;
#> padding-left: 5px;
#> padding-right: 5px;
#> }
#>
#> #cyvkgufivj .gt_stub_row_group {
#> color: #333333;
#> background-color: #FFFFFF;
#> font-size: 100%;
#> font-weight: initial;
#> text-transform: inherit;
#> border-right-style: solid;
#> border-right-width: 2px;
#> border-right-color: #D3D3D3;
#> padding-left: 5px;
#> padding-right: 5px;
#> vertical-align: top;
#> }
#>
#> #cyvkgufivj .gt_row_group_first td {
#> border-top-width: 2px;
#> }
#>
#> #cyvkgufivj .gt_row_group_first th {
#> border-top-width: 2px;
#> }
#>
#> #cyvkgufivj .gt_summary_row {
#> color: #333333;
#> background-color: #FFFFFF;
#> text-transform: inherit;
#> padding-top: 8px;
#> padding-bottom: 8px;
#> padding-left: 5px;
#> padding-right: 5px;
#> }
#>
#> #cyvkgufivj .gt_first_summary_row {
#> border-top-style: solid;
#> border-top-color: #D3D3D3;
#> }
#>
#> #cyvkgufivj .gt_first_summary_row.thick {
#> border-top-width: 2px;
#> }
#>
#> #cyvkgufivj .gt_last_summary_row {
#> padding-top: 8px;
#> padding-bottom: 8px;
#> padding-left: 5px;
#> padding-right: 5px;
#> border-bottom-style: solid;
#> border-bottom-width: 2px;
#> border-bottom-color: #D3D3D3;
#> }
#>
#> #cyvkgufivj .gt_grand_summary_row {
#> color: #333333;
#> background-color: #FFFFFF;
#> text-transform: inherit;
#> padding-top: 8px;
#> padding-bottom: 8px;
#> padding-left: 5px;
#> padding-right: 5px;
#> }
#>
#> #cyvkgufivj .gt_first_grand_summary_row {
#> padding-top: 8px;
#> padding-bottom: 8px;
#> padding-left: 5px;
#> padding-right: 5px;
#> border-top-style: double;
#> border-top-width: 6px;
#> border-top-color: #D3D3D3;
#> }
#>
#> #cyvkgufivj .gt_last_grand_summary_row_top {
#> padding-top: 8px;
#> padding-bottom: 8px;
#> padding-left: 5px;
#> padding-right: 5px;
#> border-bottom-style: double;
#> border-bottom-width: 6px;
#> border-bottom-color: #D3D3D3;
#> }
#>
#> #cyvkgufivj .gt_striped {
#> background-color: #FAFAFA;
#> }
#>
#> #cyvkgufivj .gt_table_body {
#> border-top-style: solid;
#> border-top-width: 2px;
#> border-top-color: #D3D3D3;
#> border-bottom-style: solid;
#> border-bottom-width: 2px;
#> border-bottom-color: #D3D3D3;
#> }
#>
#> #cyvkgufivj .gt_footnotes {
#> color: #333333;
#> background-color: #FFFFFF;
#> border-bottom-style: none;
#> border-bottom-width: 2px;
#> border-bottom-color: #D3D3D3;
#> border-left-style: none;
#> border-left-width: 2px;
#> border-left-color: #D3D3D3;
#> border-right-style: none;
#> border-right-width: 2px;
#> border-right-color: #D3D3D3;
#> }
#>
#> #cyvkgufivj .gt_footnote {
#> margin: 0px;
#> font-size: 90%;
#> padding-top: 4px;
#> padding-bottom: 4px;
#> padding-left: 5px;
#> padding-right: 5px;
#> }
#>
#> #cyvkgufivj .gt_sourcenotes {
#> color: #333333;
#> background-color: #FFFFFF;
#> border-bottom-style: none;
#> border-bottom-width: 2px;
#> border-bottom-color: #D3D3D3;
#> border-left-style: none;
#> border-left-width: 2px;
#> border-left-color: #D3D3D3;
#> border-right-style: none;
#> border-right-width: 2px;
#> border-right-color: #D3D3D3;
#> }
#>
#> #cyvkgufivj .gt_sourcenote {
#> font-size: 12px;
#> padding-top: 4px;
#> padding-bottom: 4px;
#> padding-left: 5px;
#> padding-right: 5px;
#> }
#>
#> #cyvkgufivj .gt_left {
#> text-align: left;
#> }
#>
#> #cyvkgufivj .gt_center {
#> text-align: center;
#> }
#>
#> #cyvkgufivj .gt_right {
#> text-align: right;
#> font-variant-numeric: tabular-nums;
#> }
#>
#> #cyvkgufivj .gt_font_normal {
#> font-weight: normal;
#> }
#>
#> #cyvkgufivj .gt_font_bold {
#> font-weight: bold;
#> }
#>
#> #cyvkgufivj .gt_font_italic {
#> font-style: italic;
#> }
#>
#> #cyvkgufivj .gt_super {
#> font-size: 65%;
#> }
#>
#> #cyvkgufivj .gt_footnote_marks {
#> font-size: 75%;
#> vertical-align: 0.4em;
#> position: initial;
#> }
#>
#> #cyvkgufivj .gt_asterisk {
#> font-size: 100%;
#> vertical-align: 0;
#> }
#>
#> #cyvkgufivj .gt_indent_1 {
#> text-indent: 5px;
#> }
#>
#> #cyvkgufivj .gt_indent_2 {
#> text-indent: 10px;
#> }
#>
#> #cyvkgufivj .gt_indent_3 {
#> text-indent: 15px;
#> }
#>
#> #cyvkgufivj .gt_indent_4 {
#> text-indent: 20px;
#> }
#>
#> #cyvkgufivj .gt_indent_5 {
#> text-indent: 25px;
#> }
#>
#> #cyvkgufivj .katex-display {
#> display: inline-flex !important;
#> margin-bottom: 0.75em !important;
#> }
#>
#> #cyvkgufivj div.Reactable > div.rt-table > div.rt-thead > div.rt-tr.rt-tr-group-header > div.rt-th-group:after {
#> height: 0px !important;
#> }
#> </style>
#> <table class="gt_table" data-quarto-disable-processing="false" data-quarto-bootstrap="false">
#> <thead>
#> <tr class="gt_heading">
#> <td colspan="4" class="gt_heading gt_title gt_font_normal" style>.</td>
#> </tr>
#> <tr class="gt_heading">
#> <td colspan="4" class="gt_heading gt_subtitle gt_font_normal gt_bottom_border" style>250 rows x 1 cols</td>
#> </tr>
#> <tr class="gt_col_headings">
#> <th class="gt_col_heading gt_columns_bottom_border gt_left" rowspan="1" colspan="1" scope="col" id="type"></th>
#> <th class="gt_col_heading gt_columns_bottom_border gt_left" rowspan="1" colspan="1" scope="col" id="name">Column</th>
#> <th class="gt_col_heading gt_columns_bottom_border gt_center" rowspan="1" colspan="1" scope="col" id="value">Plot Overview</th>
#> <th class="gt_col_heading gt_columns_bottom_border gt_right" rowspan="1" colspan="1" scope="col" id="n_missing">Missing</th>
#> </tr>
#> </thead>
#> <tbody class="gt_table_body">
#> <tr><td headers="type" class="gt_row gt_left"><svg aria-hidden="true" role="img" viewBox="0 0 512 512" style="height:20px;width:20px;vertical-align:-0.125em;margin-left:auto;margin-right:auto;font-size:inherit;fill:#4e79a7;overflow:visible;position:relative;"><path d="M40 48C26.7 48 16 58.7 16 72v48c0 13.3 10.7 24 24 24H88c13.3 0 24-10.7 24-24V72c0-13.3-10.7-24-24-24H40zM192 64c-17.7 0-32 14.3-32 32s14.3 32 32 32H480c17.7 0 32-14.3 32-32s-14.3-32-32-32H192zm0 160c-17.7 0-32 14.3-32 32s14.3 32 32 32H480c17.7 0 32-14.3 32-32s-14.3-32-32-32H192zm0 160c-17.7 0-32 14.3-32 32s14.3 32 32 32H480c17.7 0 32-14.3 32-32s-14.3-32-32-32H192zM16 232v48c0 13.3 10.7 24 24 24H88c13.3 0 24-10.7 24-24V232c0-13.3-10.7-24-24-24H40c-13.3 0-24 10.7-24 24zM40 368c-13.3 0-24 10.7-24 24v48c0 13.3 10.7 24 24 24H88c13.3 0 24-10.7 24-24V392c0-13.3-10.7-24-24-24H40z"/></svg></td>
#> <td headers="name" class="gt_row gt_left" style="font-weight: bold;"><div style='max-width: 150px;'>
#> <details style='font-weight: normal !important;'>
#> <summary style='font-weight: bold !important;'>Valid</summary>
#> DOĞRU and YANLIŞ
#> </details></div></td>
#> <td headers="value" class="gt_row gt_center"><?xml version='1.0' encoding='UTF-8' ?><svg xmlns='http://www.w3.org/2000/svg' xmlns:xlink='http://www.w3.org/1999/xlink' width='141.73pt' height='34.02pt' viewBox='0 0 141.73 34.02'><g class='svglite'><defs> <style type='text/css'><![CDATA[ .svglite line, .svglite polyline, .svglite polygon, .svglite path, .svglite rect, .svglite circle { fill: none; stroke: #000000; stroke-linecap: round; stroke-linejoin: round; stroke-miterlimit: 10.00; } .svglite text { white-space: pre; } .svglite g.glyphgroup path { fill: inherit; stroke: none; } ]]></style></defs><rect width='100%' height='100%' style='stroke: none; fill: none;'/><defs> <clipPath id='cpMC4wMHwxNDEuNzN8MC4wMHwzNC4wMg=='> <rect x='0.00' y='0.00' width='141.73' height='34.02' /> </clipPath></defs><g clip-path='url(#cpMC4wMHwxNDEuNzN8MC4wMHwzNC4wMg==)'></g><defs> <clipPath id='cpMS4wMHwxNDAuNzR8Mi45OXwyMy42MQ=='> <rect x='1.00' y='2.99' width='139.74' height='20.62' /> </clipPath></defs><g clip-path='url(#cpMS4wMHwxNDAuNzR8Mi45OXwyMy42MQ==)'><rect x='72.83' y='3.93' width='67.91' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #DDEAF7;' /><rect x='1.00' y='3.93' width='71.83' height='18.75' style='stroke-width: 1.07; stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill: #3181BD;' /></g><g clip-path='url(#cpMC4wMHwxNDEuNzN8MC4wMHwzNC4wMg==)'><text x='1.00' y='30.18' style='font-size: 8.00px; font-family: "Arial";' textLength='43.61px' lengthAdjust='spacingAndGlyphs'>2 categories</text></g></g></svg></td>
#> <td headers="n_missing" class="gt_row gt_right">0.4%</td></tr>
#> </tbody>
#>
#>
#> </table>
#> </div>
#>
#> SUMMARY OF CATEGORICAL VARIABLES
#>
#> character(0)
#>
#> Valid has 250 observations and 2 levels.
#> DOĞRU: n = 128, 51.4% of valid cases.
#> YANLIŞ: n = 121, 48.6% of valid cases.
#> Missing values: 1.
#>
#> <table class="gt_table" data-quarto-disable-processing="false"
#> data-quarto-bootstrap="false">
#>
#> <tr class="gt_heading">
#> <td colspan="4" class="gt_heading gt_title gt_font_normal" style>.
#>
#> <tr class="gt_heading">
#> <td colspan="4" class="gt_heading gt_subtitle gt_font_normal
#> gt_bottom_border" style>250 rows x 1 cols
#>
#> <tr class="gt_col_headings">
#> <th class="gt_col_heading gt_columns_bottom_border gt_left"
#> rowspan="1" colspan="1" scope="col" id="type">
#> <th class="gt_col_heading gt_columns_bottom_border gt_left"
#> rowspan="1" colspan="1" scope="col" id="name">Column
#> <th class="gt_col_heading gt_columns_bottom_border gt_center"
#> rowspan="1" colspan="1" scope="col" id="value">Plot Overview
#> <th class="gt_col_heading gt_columns_bottom_border gt_right"
#> rowspan="1" colspan="1" scope="col" id="n_missing">Missing
#>
#>
#> <tbody class="gt_table_body">
#> <td headers="type" class="gt_row gt_left"><svg aria-hidden="true"
#> role="img" viewBox="0 0 512 512"
#> style="height:20px;width:20px;vertical-align:-0.125em;margin-left:auto;margin-right:auto;font-size:inherit;fill:#4e79a7;overflow:visible;position:relative;"><path
#> d="M40 48C26.7 48 16 58.7 16 72v48c0 13.3 10.7 24 24 24H88c13.3 0
#> 24-10.7 24-24V72c0-13.3-10.7-24-24-24H40zM192 64c-17.7 0-32 14.3-32
#> 32s14.3 32 32 32H480c17.7 0 32-14.3 32-32s-14.3-32-32-32H192zm0
#> 160c-17.7 0-32 14.3-32 32s14.3 32 32 32H480c17.7 0 32-14.3
#> 32-32s-14.3-32-32-32H192zm0 160c-17.7 0-32 14.3-32 32s14.3 32 32
#> 32H480c17.7 0 32-14.3 32-32s-14.3-32-32-32H192zM16 232v48c0 13.3 10.7
#> 24 24 24H88c13.3 0 24-10.7 24-24V232c0-13.3-10.7-24-24-24H40c-13.3
#> 0-24 10.7-24 24zM40 368c-13.3 0-24 10.7-24 24v48c0 13.3 10.7 24 24
#> 24H88c13.3 0 24-10.7 24-24V392c0-13.3-10.7-24-24-24H40z"/>
#> <td headers="name" class="gt_row gt_left" style="font-weight:
#> bold;"><div style='max-width: 150px;'>
#> <details style='font-weight: normal !important;'>
#> <summary style='font-weight: bold !important;'>Valid
#> DOĞRU and YANLIŞ
#>
#> <td headers="value" class="gt_row gt_center"><?xml version='1.0'
#> encoding='UTF-8' ?><svg xmlns='http://www.w3.org/2000/svg'
#> xmlns:xlink='http://www.w3.org/1999/xlink' width='141.73pt'
#> height='34.02pt' viewBox='0 0 141.73 34.02'><g class='svglite'> <style
#> type='text/css'><![CDATA[ .svglite line, .svglite polyline, .svglite
#> polygon, .svglite path, .svglite rect, .svglite circle { fill: none;
#> stroke: #000000; stroke-linecap: round; stroke-linejoin: round;
#> stroke-miterlimit: 10.00; } .svglite text { white-space: pre; }
#> .svglite g.glyphgroup path { fill: inherit; stroke: none; } ]]><rect
#> width='100%' height='100%' style='stroke: none; fill: none;'/>
#> <clipPath id='cpMC4wMHwxNDEuNzN8MC4wMHwzNC4wMg=='> <rect x='0.00'
#> y='0.00' width='141.73' height='34.02' /> <g
#> clip-path='url(#cpMC4wMHwxNDEuNzN8MC4wMHwzNC4wMg==)'> <clipPath
#> id='cpMS4wMHwxNDAuNzR8Mi45OXwyMy42MQ=='> <rect x='1.00' y='2.99'
#> width='139.74' height='20.62' /> <g
#> clip-path='url(#cpMS4wMHwxNDAuNzR8Mi45OXwyMy42MQ==)'><rect x='72.83'
#> y='3.93' width='67.91' height='18.75' style='stroke-width: 1.07;
#> stroke: none; stroke-linecap: butt; stroke-linejoin: miter; fill:
#> #DDEAF7;' /><rect x='1.00' y='3.93' width='71.83' height='18.75'
#> style='stroke-width: 1.07; stroke: none; stroke-linecap: butt;
#> stroke-linejoin: miter; fill: #3181BD;' /><g
#> clip-path='url(#cpMC4wMHwxNDEuNzN8MC4wMHwzNC4wMg==)'><text x='1.00'
#> y='30.18' style='font-size: 8.00px; font-family: "Arial";'
#> textLength='43.61px' lengthAdjust='spacingAndGlyphs'>2 categories
#> <td headers="n_missing" class="gt_row gt_right">0.4%Phase 8: Data Quality Dashboard
Overall Quality Metrics
# Create comprehensive quality summary
quality_metrics <- data.frame(
Metric = c(
"Total Observations",
"Total Variables",
"Complete Cases",
"Variables with No Missing Data",
"Variables with <5% Missing",
"Variables with >20% Missing",
"Mean Completeness Rate"
),
Value = c(
nrow(histopathology),
ncol(histopathology),
sum(complete.cases(histopathology)),
sum(missing_summary$Missing_Count == 0),
sum(missing_summary$Missing_Percentage <= 5),
sum(missing_summary$Missing_Percentage > 20),
paste0(round(mean(100 - missing_summary$Missing_Percentage), 1), "%")
)
)
kable(quality_metrics,
caption = "Data Quality Dashboard")| Metric | Value |
|---|---|
| Total Observations | 250 |
| Total Variables | 38 |
| Complete Cases | 231 |
| Variables with No Missing Data | 15 |
| Variables with <5% Missing | 38 |
| Variables with >20% Missing | 0 |
| Mean Completeness Rate | 99.7% |
Quality Recommendations
# Generate quality recommendations
high_missing <- missing_summary %>%
filter(Missing_Percentage > 20) %>%
pull(Variable)
moderate_missing <- missing_summary %>%
filter(Missing_Percentage > 5 & Missing_Percentage <= 20) %>%
pull(Variable)
recommendations <- data.frame(
Priority = c("High", "Medium", "Low"),
Action = c(
ifelse(length(high_missing) > 0,
paste("Investigate high missing data in:", paste(high_missing, collapse = ", ")),
"No high-priority missing data issues"),
ifelse(length(moderate_missing) > 0,
paste("Consider imputation for:", paste(moderate_missing, collapse = ", ")),
"No moderate missing data issues"),
"Continue routine quality monitoring"
)
)
kable(recommendations,
caption = "Data Quality Recommendations")| Priority | Action |
|---|---|
| High | No high-priority missing data issues |
| Medium | No moderate missing data issues |
| Low | Continue routine quality monitoring |
Phase 9: Reporting Quality Issues
Missing Data Patterns
# Analyze missing data patterns
if(any(missing_summary$Missing_Count > 0)) {
# Create missing data profile
missing_profile <- histopathology %>%
summarise_all(~ifelse(is.na(.), "Missing", "Present")) %>%
pivot_longer(everything(), names_to = "Variable", values_to = "Status") %>%
count(Variable, Status) %>%
pivot_wider(names_from = Status, values_from = n, values_fill = 0) %>%
mutate(
Total = Missing + Present,
Missing_Rate = round(Missing / Total * 100, 1)
) %>%
filter(Missing > 0) %>%
arrange(desc(Missing_Rate))
kable(missing_profile,
caption = "Missing Data Profile")
}| Variable | Missing | Present | Total | Missing_Rate |
|---|---|---|---|---|
| OverallTime | 2 | 248 | 250 | 0.8 |
| Age | 1 | 249 | 250 | 0.4 |
| Anti-X-intensity | 1 | 249 | 250 | 0.4 |
| Anti-Y-intensity | 1 | 249 | 250 | 0.4 |
| Death | 1 | 249 | 250 | 0.4 |
| Grade | 1 | 249 | 250 | 0.4 |
| Grade_Level | 1 | 249 | 250 | 0.4 |
| Group | 1 | 249 | 250 | 0.4 |
| LVI | 1 | 249 | 250 | 0.4 |
| LastFollowUpDate | 1 | 249 | 250 | 0.4 |
| LymphNodeMetastasis | 1 | 249 | 250 | 0.4 |
| Mortality5yr | 1 | 249 | 250 | 0.4 |
| Name | 1 | 249 | 250 | 0.4 |
| Outcome | 1 | 249 | 250 | 0.4 |
| PNI | 1 | 249 | 250 | 0.4 |
| PreinvasiveComponent | 1 | 249 | 250 | 0.4 |
| Race | 1 | 249 | 250 | 0.4 |
| Rater 1 | 1 | 249 | 250 | 0.4 |
| Sex | 1 | 249 | 250 | 0.4 |
| Smoker | 1 | 249 | 250 | 0.4 |
| SurgeryDate | 1 | 249 | 250 | 0.4 |
| TStage | 1 | 249 | 250 | 0.4 |
| Valid | 1 | 249 | 250 | 0.4 |
Benford’s Law Compliance Summary
# Summary of Benford's law results
benford_summary <- data.frame(
Variable = c("MeasurementA", "MeasurementB", "OverallTime"),
Expected_Pattern = "Natural logarithmic distribution",
Assessment = c(
"Evaluate first digit distribution",
"Evaluate first digit distribution",
"Evaluate first digit distribution"
),
Recommendation = "Review any significant deviations from expected pattern"
)
kable(benford_summary,
caption = "Benford's Law Assessment Summary")| Variable | Expected_Pattern | Assessment | Recommendation |
|---|---|---|---|
| MeasurementA | Natural logarithmic distribution | Evaluate first digit distribution | Review any significant deviations from expected pattern |
| MeasurementB | Natural logarithmic distribution | Evaluate first digit distribution | Review any significant deviations from expected pattern |
| OverallTime | Natural logarithmic distribution | Evaluate first digit distribution | Review any significant deviations from expected pattern |
Implementation in jamovi
Data quality assessment functions are available in jamovi:
-
Benford’s Law:
Exploration > ClinicoPath Descriptives > Benford Analysis -
Variable Summary:
Exploration > ClinicoPath Descriptives > Summary of Continuous/Categorical Variables -
Cross-tabulations:
Exploration > ClinicoPath Comparisons > Cross Tables -
Variable Tree:
Exploration > ClinicoPath Descriptive Plots > Variable Tree
Conclusions
This comprehensive data quality assessment provides:
- Completeness Evaluation: Systematic missing data analysis
- Consistency Checks: Logical relationship validation
- Accuracy Assessment: Statistical distribution analysis and outlier detection
- Fraud Detection: Benford’s law analysis for data integrity
- Reliability Testing: Inter-rater agreement evaluation
Regular data quality assessment using these techniques ensures reliable and trustworthy clinical research results.
Best Practices
- Perform quality assessment before any statistical analysis
- Document and investigate any quality issues found
- Establish quality thresholds appropriate for your research context
- Implement ongoing quality monitoring throughout data collection
- Use multiple quality assessment methods for comprehensive evaluation
